4-2
4
中継ユニット
RELAY UNIT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 1-480-815-11
(S)
ﾃﾞﾝｼﾞﾍﾞﾝ
ASSY (VQZ115R)
RELAY ASSY, (S) (VQZ115R)
2
VQZ115R
2 1-480-830-11
(S)
ﾊﾞﾙﾌﾞ
ASSY (SYJ512)
VALVE ASSY, (S) (SYJ512)
2
SYJ512
3 2-022-773-01
ﾃｲﾄｳ
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(CBSS4-10)
BOLT, HEXAGON SOCKET (CBSS4-10
8
CBSS4-10
4 2-689-707-01
ｾｲﾐﾂ
ｹﾞﾝｱﾂﾍﾞﾝ
(IR-1000-01BG)
DECOMPRESSION (IR-1000-01BG)
1
IR-1000-01BG
5 2-689-708-01
ｹﾞﾝｱﾂﾍﾞﾝ
ﾌﾞﾗｹﾂﾄ
(1)
BRACKET (1), DECOMPRESSION
1
6 2-689-710-01
ﾊﾞﾙﾌﾞ
ﾌﾞﾗｹﾂﾄ
(2)
BRACKET (2), VALVE
1
7 2-689-711-02
Y
ｺﾃｲ
ﾁﾕｳｹｲ
ﾌﾟﾚ
-
ﾄ
(1)
PLATE (1), Y FIXED RELAY
2
9 2-689-713-02
Y
ｺﾃｲ
ﾍﾞｱ
ｻﾎﾟ
-
ﾄ
(1)
SUPPORT (1), Y FIXED BARE
2
10 3-295-106-01
Y
ｺﾃｲ
ﾍﾞｱ
ｻﾎﾟ
-
ﾄ
(2)
SUPPORT (2), Y FIXED BARE
2
11 2-887-481-02
Y
ｹ
-
ﾌﾞﾙ
ｶﾞｲﾄﾞ
GUIDE, Y CABLE
2
12 2-887-482-02
Y
ｹ
-
ﾌﾞﾙ
ｼﾁﾕｳ
POST, Y CABLE
8
13 2-918-766-01
ﾕﾆｵﾝ
ﾜｲ
(KQ2U06-00)
UNION Y (KQ2U06-00),
1
KQ2U06-00, SMC
14 3-094-750-01
ﾚｷﾞﾕﾚ
-
ﾀ
-
ﾌﾞﾗｹﾂﾄ
BRACKET, REGULATOR
1
15 3-100-351-01
ｾｲﾐﾂ
ﾚｷﾞﾕﾚ
-
ﾀ
(IR1000-01-B)
REGULATOR (IR1000-01-B)
1
IR1000-01-B
16 3-100-352-01
ｱﾂﾘﾖｸｹｲ
(G33-2-01)
GAUGE (G33-2-01), PRESSUER
1
G33-2-01
17 3-213-232-01
Y
ｹ
-
ﾌﾞﾙ
ｵｻｴｲﾀ
(2)
RETAINER (2), Y CABLE
2
18 3-277-348-01
ﾊﾞﾙﾌﾞ
ﾌﾞﾗｹﾂﾄ
(F)
BRACKET (F), VALVE
1
19 4-701-253-01
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQL06-01S)
UNION (KQL06-01S), ELBOW
4
KQL06-01S, SMC
20 4-701-306-01
ｻｲﾚﾝｻ
- (AN120-M5)
SILENCER (AN120-M5)
4
AN120-M5, SMC
21 4-706-519-01
ﾊｰﾌ
ﾕﾆｵﾝ
(KQH06-M5)
UNION (KQH06-M5), HALF
2
KQH06-M5, SMC
22 4-706-724-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X5)
BOLT (M3X5), HEXAGON SOCKET
12
M3X5
23 4-706-725-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X8)
BOLT (M4X8), HEXAGON SOCKET
9
M4X8
24 4-706-725-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X10)
BOLT (M4X10), HEXAGON SOCKET
2
M4X10
25 4-706-725-51
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X6)
BOLT (M4X6), HEXAGON SOCKET
6
M4X6
26 4-706-725-81
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X18)
BOLT (M4X18), HEXAGON SOCKET
4
M4X18
27 4-706-726-31
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X10)
BOLT (M5X10), HEXAGON SOCKET
8
M5X10
4-3
4
中継ユニット
RELAY UNIT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
28 4-719-686-31
ﾂｷﾞﾃ
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L04-M5)
UNION, JOINT ELBOW(KQ2L04-M5)
2
KQ2L04-M5, SMC
29 4-719-686-41
ﾂｷﾞﾃ
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L06-M5)
UNION, JOINT ELBOW(KQ2L06-M5)
6
KQ2L06-M5, SMC
30 4-720-189-01
ﾂｷﾞﾃ
ﾁ
-
ｽﾞ
(KQ2T04-00)
JOINT, JOINT TEE (KQ2T04-00)
2
KQ2T04-00, SMC
31 4-720-189-11
ﾂｷﾞﾃ
ﾁ
-
ｽﾞ
(KQ2T06-00)
JOINT, JOINT TEE (KQ2T06-00)
1
KQ2T06-00, SMC
32 4-761-739-01
ｹ
-
ﾌﾞﾙ
ｵｻｴ
ｶﾗ
- (X
ｼﾞｸ
)
COLLAR, CABLE RETAINER(X AXIS)
4
33 4-761-755-01
ﾎﾞｳｼﾞﾝ
ｺﾞﾑ
(C-300-B-10X20)
RUBBER, DUST PROTECTION
4
C-300-B-10X20
34 4-761-758-01
ﾒｽ
ﾕﾆｵﾝ
(KQ2F12-03)
UNION, FEMALE (KQ2F12-03)
2
KQ2F12-03, SMC
35 4-761-761-01
ﾌﾞﾗﾝﾁ
(KQ2U08-03S)
BRANCH (KQ2U08-03S)
2
KQ2U08-03S, SMC
36 4-761-868-01
NOZZLE
ｼ
-
ﾙ
SEAL, NOZZLE
2
37 7-632-385-40
ﾎﾟﾘｳﾚﾀﾝﾁﾕ
-
ﾌﾞ
(TU0425B)2.5X4X12M
TUBE, POLYURETHAN (TU0425B)
7000
TU0425B, SMC
38 7-632-385-50
ﾎﾟﾘｳﾚﾀﾝ
ﾁﾕ
-
ﾌﾞ
(TU0604B) 4X6X3M
TUBE, POLYURETHAN (TU0604B)
4000
TU0604B, SMC
39 1-761-262-12
LS
ｷﾊﾞﾝ
ASSY
PC BOARD ASSY, LS
2
40 2-109-636-01
ｹ
-
ﾌﾞﾙ
ｵｻｴ
RETAINER, CABLE
1
41 2-693-602-01
ﾎﾞｳｼﾞﾝ
ｺﾞﾑ
RUBBER, DUST PROTECTION
2
42 2-693-603-02
ｲﾀ
ﾅﾂﾄ
NUT, PLATE
4
43 2-693-606-01
X
ｹ
-
ﾌﾞﾙ
ｵｻｴｲﾀ
RETAINER, X CABLE
2
44 2-693-610-01
ｺﾃｲ
ﾀﾝ
ｶﾅｸﾞ
(TKP 0450 KA)
BRACKET,FIXD (TKP 0450 KA)
1
TKP 0450 KA
45 2-693-611-01
ｲﾄﾞｳ
ﾀﾝ
ｶﾅｸﾞ
(TKP 0450 IA)
BRACKET,MOVE (TKP 0450 IA)
1
TKP 0450 IA
46 2-693-619-01
ﾃﾌﾛﾝ
ｼ
-
ﾄ
(A)
SHEET (A), TEFLON
1
47 2-693-619-11
ﾃﾌﾛﾝ
ｼ
-
ﾄ
(B)
SHEET (B), TEFLON
1
48 2-693-629-01
ｺﾈｸﾀ
-
ﾁﾕｳｹｲ
ﾌﾟﾚ
-
ﾄ
PLATE, CONNECTOR RELAY
1
49 2-693-633-01
ｹ
-
ﾌﾞﾙ
ﾍﾞﾔ
(TKP0450 58B 50R 14L
BARE (TKP0450 58B 50R 14L)
1
TKP0450 58B 50R 14L
50 2-693-634-01
ﾌｲ
-
ﾄﾞ
ｶﾊﾞ
-
COVER, FEED
1
51 2-693-635-01
ｹ
-
ﾌﾞﾙ
ﾍﾞｱ
ｶﾞｲﾄﾞ
GUIDE, CABLE BARE
1
52 2-693-661-01
ﾍﾂﾄﾞ
ｺﾈｸﾀ
-
ﾁﾕｳｹｲ
ﾌﾟﾚ
-
ﾄ
PLATE, HEAD CONNECTOR RELAY
1
53 2-693-665-04
ﾍﾂﾄﾞ
ｺﾈｸﾀ
-
ﾌﾟﾚ
-
ﾄ
PLATE, HEAD CONNECTOR
1
4-4
4
中継ユニット
RELAY UNIT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
54 2-698-399-02
ｺﾞｸ
ﾃｲﾄｳ
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(CBST*
CAP SCREW, EXTRA LOW HEAD
4
55 3-197-060-01
ﾃﾌﾛﾝ
ｼ
-
ﾄ
(C)
SHEET (C), TEFLON
1
56 3-213-369-01
Y
ｹ
-
ﾌﾞﾙ
ｵｻｴ
ﾍﾞ
-
ｽ
BASE, Y CABLE RETAINER
1
57 3-288-074-01
ﾍﾂﾄﾞ
ｺﾈｸﾀ
-
ｶﾊﾞ
-
COVER, HEAD CONNECTOR
1
58 3-288-092-01
ｹ
-
ﾌﾞﾙ
ﾁﾕｳｹｲ
ﾌﾟﾚ
-
ﾄ
PLATE, CABLE RELAY
1
59 4-706-724-02
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X4SUS)
BOLT (M3X4SUS), HEXAGON SOCKET
12
M3X4SUS
60 4-706-724-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X6)
BOLT (M3X6), HEXAGON SOCKET
4
M3X6
61 4-706-725-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X8)
BOLT (M4X8), HEXAGON SOCKET
8
M4X8
62 4-706-725-05
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X20SUS)
BOLT (M4X20SUS),HEXAGON SOCKET
2
M4X20SUS
63 4-706-725-31
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X30)
BOLT (M4X30), HEXAGON SOCKET
4
M4X30
64 4-706-725-51
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X6)
BOLT (M4X6), HEXAGON SOCKET
4
M4X6
65 4-706-726-31
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X10)
BOLT (M5X10), HEXAGON SOCKET
4
M5X10
66 4-706-740-21
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X8)
BOLT (M6X8), HEXAGON SOCKET
6
M6X8
67 4-720-755-01
ｲﾄﾞｳ
ﾔｼﾞﾙｼ
ｼ
-
ﾙ
(
ｼﾖｳ
)
SEAL, MOVE ARROW MARK (SMALL)
1
68 4-720-769-01
ｽﾄﾚ
-
ﾄ
(KQ2H06-00)
STRAIGHT (KQ2H06-00)
1
KQ2H06-00, SMC
69 4-720-769-21
ｽﾄﾚ
-
ﾄ
(KQ2H08-00)
STRAIGHT (KQ2H08-00)
2
KQ2H08-00, SMC
70 4-761-739-01
ｹ
-
ﾌﾞﾙ
ｵｻｴ
ｶﾗ
- (X
ｼﾞｸ
)
COLLAR, CABLE RETAINER(X AXIS)
2
71 4-761-747-01
ｹ
-
ﾌﾞﾙ
ｵｻｴ
ｶﾗ
- (Y
ｼﾞｸ
)
COLLAR, CABLE RETAINER(Y AXIS)
4
72 4-761-755-01
ﾎﾞｳｼﾞﾝ
ｺﾞﾑ
(C-300-B-10X20)
RUBBER, DUST PROTECTION
1
C-300-B-10X20
73 7-681-000-11
+K M4X6
SCREW +K M4X6
3
+K M4X6
74 7-682-950-01
+PSW 3X12
SCREW +PSW 3X12
8
+PSW 3X12
75 7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
4
W 4, MIDDLE
76 7-688-005-11
W 5, MIDDLE
W 5, MIDDLE
4
W 5, MIDDLE
