si-g200bb_doc_par_nothing_xx_3rd_20091207_level01.pdf - 第9页

2-2 2 Ｙ軸ユニット Y-AXIS UNIT ｲﾗｽﾄ番号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 1 2-108-571-01 ｲﾁｷﾞﾒ ﾌﾞﾂｼﾕ BUSHING, POSITIONING 2 2 2-697-044-06 G200 ﾒｲﾝ ﾌﾚ - ﾑ MAIN FRAME, G200 1 3 4-…

100%1 / 240
2-1
2
Ｙ軸ユニット
Y-AXIS UNIT
26
29
29
30
29
29
30
19
47
48
35
38
15
41
40
38
44
18
32
22
27
46
45
31
37
39
16
42
35
36
50
20
36
33
33
15
50
43
35
19
47
41
40
27
48
46
45
31
37
39
44
49
32
22
42
35
17
43
21
33
33
36
50
16
34
28
25
11
34
24
43
12
13
14
14
34
23
34
34
14
14
12
13
28
25
34
50
36
51
51
2-2
2
Ｙ軸ユニット
Y-AXIS UNIT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 2-108-571-01
ｲﾁｷﾞﾒ
ﾌﾞﾂｼﾕ
BUSHING, POSITIONING
2
2 2-697-044-06
G200
ﾒｲﾝ
ﾌﾚ
-
ﾑ
MAIN FRAME, G200
1
3 4-705-597-41
ﾍｲｺｳ
ﾋﾟﾝ
(
ﾌｱｲ
5)
PIN (DIA. 5), PARALLEL
2
DIA. 5
4 4-720-230-01
ｲﾁｷﾞﾒ
ﾋﾟﾝ
ﾖｳ
ﾌﾞﾂｼﾕ
(JBH16-20)
BUSHING (POSITIONING PIN)
2
JBH16-20
5 1-480-809-11
(S)
ﾌｵﾄｾﾝｻ
ASSY (EE-SX771A)
SENSOR ASSY, (S) PHOTO (EE-SX*
2
EE-SX771A, OMRON
6 1-480-810-11
(S)
ﾌｵﾄｾﾝｻ
ASSY (EE-SX871A)
SENSOR ASSY, (S) PHOTO (EE-SX*
4
EE-SX871A, OMRON
7 1-480-828-11
(S)
ﾃﾞﾝｼ
ﾌﾞｻﾞ
- ASSY (EB1124)
BUZZER ASSY, (S) ELECTRONIC
1
EB1124, National
8 1-480-812-11
(S)
ﾌﾞｻﾞ
- ASSY (EB2134)
BUZZER ASSY, (S) (EB2134)
1
EB2134, National
9 1-761-167-12
ﾊﾝﾃﾞｲ
ｺﾝｿ
-
ﾙ
ｾｲｷﾞﾖ
ｷﾊﾞﾝ
ASSY
PC BOARD ASSY, CONSOLE CONTROL
1
10 1-787-209-11
ｻ
-
ﾎﾞ
ﾓ
-
ﾀ
- (SGMAS-12ACA21)
MOTOR, SERVO (SGMAS-12ACA21)
2
SGMAS-12ACA21, YASUKAWA
11 1-789-495-11
IF2 LS
ｷﾊﾞﾝ
2 ASSY
IF2 LS BOARD 2 ASSY
2
12 1-789-652-11
SDIOS-IN 16
ｷﾊﾞﾝ
ASSY
SDIOS-IN 16 BOARD ASSY
2
13 1-789-652-21
SDIOS-IN 16
ｷﾊﾞﾝ
ASSY
SDIOS-IN 16 BOARD ASSY
-855 2
*1
14 1-789-653-11
SDIOS-OUT 16
ｷﾊﾞﾝ
ASSY
SDIOS-OUT 16 BOARD ASSY
-855 4
*1
14 1-789-653-11
SDIOS-OUT 16
ｷﾊﾞﾝ
ASSY
SDIOS-OUT 16 BOARD ASSY
856- 2
*2
15 2-319-552-01
LM
ｶﾞｲﾄﾞ
(SHS20V4UUC1E+1180LH*
GUIDE (SHS20V4UUC1E+1180LH*)
2
SHS20V4UUC1E+1180LH*
16 2-594-323-01
ｶﾂﾌﾟﾘﾝｸﾞ
(SFC-050DA2-12B-16B)
COUPLING (SFC-050DA2-12B-16B)
2
SFC-050DA2-12B-16B,
MIKI PULLEY
17 2-689-940-01
Y+
ｳﾚﾀﾝ
ｽﾄﾂﾊﾟ
(
ﾌﾛﾝﾄ
)
STOPPER (FRONT), Y+ URETHANE
1
18 2-689-941-01
Y+
ｳﾚﾀﾝ
ｽﾄﾂﾊﾟ
STOPPER, Y+ URETHANE
1
19 2-689-942-01
Y-
ｳﾚﾀﾝ
ｽﾄﾂﾊﾟ
STOPPER, Y- URETHANE
2
20 2-689-951-02
Y
ｹﾞﾝﾃﾝ
ｾﾝｻ
ﾌﾞﾗｹﾂﾄ
(
ﾌﾛﾝﾄ
ﾖｳ
)
BRACKET, Y ORIGIN SENSOR
1
21 2-689-954-03
Y
ｹﾞﾝﾃﾝ
ｾﾝｻ
ﾌﾞﾗｹﾂﾄ
(
ﾘｱ
-
ﾖｳ
)
BRACKET, Y ORIGIN SENSOR
1
22 2-689-956-01
Y
ﾎﾞ
-
ﾙ
ﾈｼﾞ
ﾅﾂﾄ
ﾌﾞﾗｹﾂﾄ
BRACKET, Y BALL SCREW NUT
2
23 2-689-957-01
ﾎﾞ
-
ﾄﾞ
ﾌﾞﾗｹﾂﾄ
(1)
BRACKET (1), BOARD
1
24 2-689-958-01
ﾎﾞ
-
ﾄﾞ
ﾌﾞﾗｹﾂﾄ
(2)
BRACKET (2), BOARD
1
25 2-689-959-01
I/O
ﾎﾞ
-
ﾄﾞ
ﾌﾞﾗｹﾂﾄ
BRACKET, I/O BOARD
2
2-3
2
Ｙ軸ユニット
Y-AXIS UNIT
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
26 2-693-623-01
ｳﾚﾀﾝ
ｽﾄﾂﾊﾟ
- (C)
STOPPER (C), URETHANE
1
27 2-697-045-01
ﾎﾞ
-
ﾙ
ﾈｼﾞ
(SBK2020YS-5.6RRGT+9*
SCREW (SBK2020YS-5.6RRGT+9*)
2
SBK2020YS-5.6RRGT+9*
28 2-698-404-01
ｽﾁ
-
ﾙ
ｽﾍﾟ
-
ｻ
(BSF-408E)
SPACER (BSF-408E), STEEL
4
BSF-408E, HIROSUGI
29 3-095-923-01
ﾀｶｻ
ﾁﾖｳｾｲ
ｼﾑ
(
ﾌﾚ
-
ﾑ
ﾖｳ
) A
SHIM (FRAME),HEIGHT ADJUSTMENT
8
30 3-095-923-11
ﾀｶｻ
ﾁﾖｳｾｲ
ｼﾑ
(
ﾌﾚ
-
ﾑ
ﾖｳ
) B
SHIM (FRAME),HEIGHT ADJUSTMENT
4
31 4-703-128-01
ﾌｱｲﾝ
U
ﾅﾂﾄ
(FU02SS)
NUT (FU02SS), FINE (U)
2
FU02SS, FUJI SEIMITSU
32 4-703-129-01
ﾌｶﾐｿﾞ
ﾀﾏ
ｼﾞｸｳｹ
(6002ZZ)
BEARING (6002ZZ), BALL
2
6002ZZ, NTN
33 4-706-724-21
ﾛﾂｶﾅ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X8)
BOLT (M3X8), HEXAGON SOCKET
16
M3X8
34 4-706-725-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X8)
BOLT (M4X8), HEXAGON SOCKET
20
M4X8
35 4-706-725-06
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X25SUS)
BOLT (M4X25SUS),HEXAGON SOCKET
16
M4X25SUS
36 4-706-725-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X10)
BOLT (M4X10), HEXAGON SOCKET
12
M4X10
37 4-706-725-61
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X15)
BOLT (M4X15), HEXAGON SOCKET
8
M4X15
38 4-706-726-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X20)
BOLT (M5X20), HEXAGON SOCKET
40
M5X20
39 4-706-740-07
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X20SUS)
BOLT (M6X20SUS),HEXAGON SOCKET
8
M6X20SUS
40 4-716-148-06
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M8X25 SUS)
BOLT (M8X25 SUS), SOCKET
4
M8X25 SUS
41 4-716-148-08
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M8X35 SUS)
BOLT (M8X35 SUS), SOCKET
4
M8X35 SUS
42 4-716-148-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M8X50 SUS)
BOLT (M8X50 SUS), SOCKET
8
M8X50 SUS
43 4-716-151-07
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M16X50 SUS)
BOLT (M16X50 SUS), SOCKET
20
M16X50 SUS
44 4-719-803-04
X
ﾎﾞ
-
ﾙﾈｼﾞ
ｼｼﾞ
ﾌﾞﾗｹﾂﾄ
BRACKET, X BALL SCREW SUPPORT
2
45 4-721-723-01
X
ﾍﾞｱﾘﾝｸﾞ
ｺﾃｲ
ﾌﾗﾝｼﾞ
FLANGE, X BEARING FIXED
2
46 4-721-724-01
X
ﾍﾞｱﾘﾝｸﾞ
ｺﾃｲ
ｶﾗ
-
COLLAR, X BEARING FIXED
2
47 4-721-725-03
X
ﾓ
-
ﾀ
-
ﾄﾘﾂｹ
ﾌﾞﾗｹﾂﾄ
BRACKET, X MOTOR FITTING
2
48 4-721-726-01
ｱﾝｷﾞﾕﾗ
ﾀﾏｼﾞｸｳｹ
(7302BTDFC8P5)
BALL BEARING, ANGULAR
2
7302BTDFC8P5
49 7-624-197-21
C
ｶﾞﾀ
ﾄﾒﾜ
15 (
ｼﾞｸﾖｳ
)
STOP RING 15, TYPE-C
2
50 7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
10
W 4, MIDDLE
51 2-689-953-01
ｼﾂﾋﾟﾝｸﾞｸﾗﾝﾌﾟ
SHIPPING CLAMP
2
