3-7-1 3-7 固定カメラユニット CAMERA UNIT, FIXED CAMERA RET AINER BASE (REAR) 11 33 26 8 21 27 5 4 9 22 8 27 21 26 33 5 23 14 14 23 15 6 21 32 29 17 25 13 23 13 23 16 29 24 18 7 27 20 7 19 19 23 12 15 25 17
3-6-4
3-6
Ｂヘッドユニット（４／４）
HEAD UNIT, B (4/4)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
3-7-1
3-7
固定カメラユニット
CAMERA UNIT, FIXED
CAMERA RETAINER BASE (REAR)
11
33
26
8
21
27
5
4
9
22
8
27
21
26
33
5
23
14
14
23
15
6
21
32
29
17
25
13
23
13
23
16
29
24
18
7
27
20
7
19
19
23
12
15
25
17
3-7-2
3-7
固定カメラユニット
CAMERA UNIT, FIXED
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
4 1-417-959-12
ｺﾃｲ
ｶﾒﾗ
(B) (QQJ-2180)
CAMERA, FIXED (B) (QQJ-2180)
2
QQJ-2180
5 1-418-769-11
ﾌｵﾄ
ｾﾝｻ
ﾌｱｲﾊﾞ
(E32-T24S)
FIBER, PHOTO SENSOR (E32-T24S)
2
E32-T24S
6 1-480-833-11
(S)
ﾌｱｲﾊﾞ
-
ｾﾝｻ
ｱﾝﾌﾟ
(E3X-DA11-S-4)
AMPLIFIER ASSY, (S) SENSOR
2
E3X-DA11-S-4
7 1-480-808-11
(S)
ﾌｱﾝ
ﾓ
-
ﾀ
- ASSY (MDS410-24-F34)
MOTOR ASSY, (S) FAN (MDS410-2*
4
MDS410-24-F34
8 3-278-519-02
ｱﾘ
ﾅｼ
ｾﾝｻ
ﾌﾞﾗｹﾂﾄ
BRACKET, NON SENSOR
4
9 A-1544-283-A
ｷｼﾞﾕﾝ
ﾏ
-
ｸ
ASSY
MARK ASSY, STANDARD
2
11 3-278-522-01
ｶﾒﾗ
ｵｻｴ
ﾍﾞ
-
ｽ
(
ﾘｱ
)
BASE (REAR), CAMERA RETAINER
1
12 3-278-523-02
ｲﾀﾊﾞﾈ
ﾍﾞ
-
ｽ
BASE, LEAF SPRING
2
13 3-278-524-01
ｻｲﾄﾞ
ﾌﾞﾛﾂｸ
BLOCK, SIDE
4
14 3-278-525-01
ｲﾀﾊﾞﾈ
SPRING, LEAF
4
15 3-278-526-01
ﾃﾞﾙﾘﾝ
ｲﾀ
PLATE, DELRIN
4
16 3-278-527-01
ｶﾒﾗ
ｵｻｴ
ﾍﾞ
-
ｽ
(
ﾌﾛﾝﾄ
)
BASE (FRONT), CAMERA RETAINER
1
17 3-278-970-01
ｷﾞｻﾞﾂｷ
ｻﾗ
ﾊﾞﾈ
ｻﾞｶﾞﾈ
(GTS6)
WASHER (GTS6), SPRING LOCK
8
GTS6
18 3-286-896-01
ﾌｱﾝ
ﾌﾞﾗｹﾂﾄ
BRACKET, FAN
2
19 3-286-897-02
ﾌｲﾝｶﾞ
-
ｶﾞ
-
ﾄﾞ
(FG4D-F1)
GUARD (FG4D-F1), FINGER
4
FG4D-F1
20 4-706-724-04
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X14SUS)
BOLT (M3X14SUS),HEXAGON SOCKET
8
M3X14SUS
21 4-706-724-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X6)
BOLT (M3X6), HEXAGON SOCKET
16
M3X6
22 4-706-724-21
ﾛﾂｶﾅ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X8)
BOLT (M3X8), HEXAGON SOCKET
4
M3X8
23 4-706-725-11
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X10)
BOLT (M4X10), HEXAGON SOCKET
16
M4X10
24 4-706-740-04
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X10SUS)
BOLT (M6X10SUS),HEXAGON SOCKET
4
M6X10SUS
25 4-706-740-05
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X14SUS)
BOLT (M6X14SUS),HEXAGON SOCKET
12
M6X14SUS
26 4-708-450-01
ｾﾂﾄ
ｼﾕ
-
SHOE, SET
4
27 4-716-152-03
ﾋﾗ
ｻﾞｶﾞﾈ
(M3
ﾁﾕｳ
SUS)
WASHER (M3 MIDDLE SUS), PLAIN
20
M3 MIDDLE SUS
- 4-716-152-04
ﾋﾗ
ｻﾞｶﾞﾈ
(M4
ﾁﾕｳ
SUS)
WASHER (M4 MIDDLE SUS), PLAIN
16
M4 MIDDLE SUS
29 4-716-152-06
ﾋﾗ
ｻﾞｶﾞﾈ
(M6
ﾁﾕｳ
SUS)
WASHER (M6 MIDDLE SUS), PLAIN
12
M6 MIDDLE SUS
- 4-716-153-03
ﾊﾞﾈ
ｻﾞｶﾞﾈ
(M3 SUS)
WASHER (M3 SUS), SPRING LOCK
4
M3 SUS
