5.2.2 Vacuum pump (Option for the factory setting)
This pump can suppress the air consumption of the compressor, so that the air supply stability
at component pickup can be improved.
5.2.3 Height measuring function (HMS, option for the factory setting)
When pickup data is prepared, the height of the component pickup position is automatically
measured by laser sensor.
Components with a transparent pickup surface such as glass (LED, etc.), components with a
mirror-like surface that reflects almost all of light, and components of blue color are excluded
from applicable components. This can also be used as a teaching spot. (JX-100: Option,
JX-100 LED: Standard.)
5.2.4 Leakage breaker (Option for the factory setting)
When a current flows (leaks) others than the intended electric circuit because the insulator
(coating) of cable or electric wire is broken or an electric connection is made between
conductors by external factor, this breaker can cut off the current automatically.
5.2.5 Rear bank (Option for the factory setting)
This is a fixed bank type. This is required to use a tape feeder (except ATF) and a tray holder.
5.2.6 Main line filter (Option)
This filter is provided ahead of 3 air sets, and removes oil, water, foreign substances in
compressed air to extend the element life of the precision filter and prevent device trouble.
5.2.7 HOD (Option)
This device is a hand held type that permits checking mark recognition images and performing
various teaching operations at places other than the operating panel while holding it by hand.
When the HOD is used for teaching operations and adjustment, the sphere of action can be
extended.
5.2.8 EPU (Option)
This is an abbreviation for External Programming Unit and permits programming on the PC.
* The EPU for JX-100 is not allowed to be used on the same PC with any other EPU for
different type of machine, or with the HLC.
5.2.9 Air compressor Assembly (Option )
This unit consists of a vacuum pump, air compressor (see Note 1), and power supply unit for
air compressor as a set.
Note 1: This unit cannot be exported to the USA, China, and Singapore by the each
safety standard. The air compressor must be procured locally. In the case of
local procurement, the recommended compressor specifications are as follows.
Compressor Air tank
Output
(Kw)
Max.
Pressure
(MPa)
Revolution
(rpm) (50/60Hz)
Discharge air volume
(L/Min) （50/60Hz）
Total Capacity
(L)
0.2 0.8 1,350/1,600 20/24 12
17
18
5.2.10 A simple Buffer (Option only for JX-100)
Attaches a stopper onto the conveyor entrance to make the simplified IN-buffer. It makes
the waiting time to load the next PWB shorter.
5.2.11 Lighting unit of solder recognition (Option for the factory setting only
for JX-100 LED)
A solder printed on a board can be used as a PWB reference mark.
Even if the PWB reference mark cannot be recognized around the edge of PWB due to
the feeds that are done by split clamping in a production of longer-sized PWB in X axis,
more than 410 mm in X direction, the solder printed on a board can be used as the
replacement of a PWB reference mark, and it enables a PWB production in placement.
*Satisfactory placement accuracy might not be obtained in the solder print because
shape as the mark is not clear.
19
6. OPTIONAL FEEDERS
6.1 Component supply method
Front bank fixing type (to be installed as standard)
Rear bank fixing type (option)
6.2 Maximum Number of Types
Description
A number of
available
places at the
front side
(Note 3)
A number of available
places at the rear
side (option)
(Note 1,2,3)
Total number of
units that can be
installed (at rear
option setting)
Number of
occupied
positions
8 mm tape feeder 30 30 60 2
12 mm tape feeder 20 20 40 3
16 mm tape feeder 20 20 40 3
24 mm tape feeder 15 15 30 4
32 mm tape feeder (Note 2) 12 12 24 5
44 mm tape feeder 7 7 14 8
56 mm tape feeder 7 7 14 8
72 mm tape feeder 6 6 12 10
Stick feeder type N 20 － 20 3
Stick feeder type W 10 － 10 6
Bulk feeder 30 － 30 2
Tray holder Type 1 (Note 4) － 1 1 40
Tray holder Type 2 (Note 4) － 2 2 20
Note 1: At the rear side ATF is not available.
Note 2: Not available 32mm adhesion feeder type.
Note 3: The simultaneous pickup and pickup rate are guaranteed by the CTF and ATF.
However, the pickup position must be obtained automatically (auto teaching) and
the teaching of the emboss tape must be carried out. Note 3
Note 4: The pick-up range of Y-direction of the tray holder is 230mm (120 mm for JX-100
LED) or less.
6.3 A List of Feeders
Feed unit
Tape feeder
8mm, 12mm
16mm, 24mm
32mm, 44mm
56mm, 72mm
Bulk feeder Condenser of 1005
Condenser of 1608
Resistance of 1608
Stick feeder
Type N
Type W
Tray holder
Type 1 (Note 1)
Type 2 (Note 1)
Note 1: Rear bank only
