6.4.5 Adjustment jig for th e feeder with a monitor This is a jig for checking a component pick po sition with a CCD camera to adjust it. If you check and adjust the pick position on a regular basis, you can maint ain th…

100%1 / 40
② FTFR (32 mm, 44 mm, and 56 mm)
Applicable Component
Product code Feed pitch
Pick position
(Y direction)
Emboss
width
Emboss
depth
FF323R 12mm
FF324R 16mm
FF32FR 8/12/16/20/24mm
132mm
FF32FR-OP 8/12/16/20/24/28/32mm 114mm
23.5mm or
less
FF443R 12mm
FF444R 16mm
FF44FR 8/12/16/20/24mm
128mm
FF44FR-OP 8/12/16/20/24/28/32/
36/40/44mm
114mm
33.8mm or
less
FF564R 12/16mm 128mm
FF568R 12/16/20/24/28/32mm 114mm
FF56FR 8/12/16/20/24mm 128mm
FF56FR-OP 8/12/16/20/24/28/32/
36/40/44/48/56mm
114mm
46.0mm or
less
25mm or less
Power supply/air None
Dimensions
L =693mm , H =472mm
W= FTFR32**:47.7mm , FTFR44**:61.6mm , FTFR56**:66.0mm
Mass
(Excluding a reel)
FTFR32**:3.2kg , FTFR44**:3.5kg , FTFR56**:3.8kg
Component
transport method
Ratchet drive system
* Use a tape feeder whose supported component sizes and tape specifications conform to
the JIS C0806-3:1999 and IEC 60286-3:2007.
2) Options
① Emboss spacer (FTFR only)
When the component width and length are large and the tape depth is small, the
posture stability at component pickup can be improved by placing the spacer at
the component pickup position of the tape feeder.
The usable emboss depth is 1.0 mm to 8.0 mm.
② Tape reel mounting platform
This is a platform that allows you to set a tape onto a tape feeder. Since you can
set a tape while holding a tape feeder correctly, this option improves the tape
setting capability and prevents a tape feeder from falling down.
Type Application
Tape reel mounting platform (no foot) A user is supposed to fix this option onto a table or similar
device with screws.
Tape reel mounting platform (with foot) This option is equipped with foot, so you can install this
option as desired.
25
6.4.5 Adjustment jig for the feeder with a monitor
This is a jig for checking a component pick position with a CCD camera to adjust it.
If you check and adjust the pick position on a regular basis, you can maintain the stable
pick-up capability.
1) Specifications
1 Power supply Select 100 V - 120 V or 200 V - 240 V.
2 Outer dimension L=290mm, H=480mm, W=157mm
3 Mass - Adjustment jig main unit: 12 kg or less
(including the CCD camera and lens section)
- Master feeder: 2 kg
- Monitor: 4 kg
2) Environment conditions
① During operation
- Temperature: 10 to 35°C
- Accuracy guaranty temperature:
20 to 25°C
- Humidity: 30 to 80%RH (No condensation)
- Altitude: 1,000m or less
② Transportation or storage
- Temperature: －15 to ＋70°C
- Humidity: 20 % to 95 %RH (No condensation)
3) Configuration
- Adjustment jig main unit
- Master feeder
- CCD camera (including a lens)
- Light
- Power supply
- Monitor
- Jig tape
- Adjustment tool
4) Applicable feeders
- ATF: 8 mm to 24mm
- CTF: 8 mm
- FTF: 12 mm to 72 mm、 FTFR: 32mm to 56mm
- NTF: 8 mm to 56 mm * See Note
- BF: BF10AS, BF11AS, BF12BS, BF12CS, BF25CS, BF28CS and BF28RS
* Note: Carrier tapes whose width are one of type of 8mm and 12 mm to 56 mm(NTF)
do not have the X-direction adjustment function.
26
6.5 Tray Holder
This tray holder is equipped with one tray, and can be installed on the rear bank so that the
head of the main unit can pick up a component directly from this holder.
When the tray size is small, several trays can be attached on the holder to allow this holder
to function as a multi-tray holder.
Full type Half type
Machine style JX-100 JX-100 LED JX-100 JX-100 LED
Longitudinal direction 65mm to 320mm 65mm to 155mm
Horizontal direction
65mm to
230mm
65mm to
120mm
65mm to
230mm
65mm to
120mm
Thickness
5 mm to 11 mm
(from the bottom of a tray to the top of an IC)
Number of occupied positions
(Note 1)
42 21
* The maximum number of tray holders at the rear-side bank is one of full type and two
of half type.
Note 1: Although the number of feeder positions actually occupied is 40 for the full type,
and 20 for the half type, the number of positions used during PWB production
(according to the feeder layout) is shown in the table above.
