6.4.3 ATF

For splicing of component feed tape (tape splicing), this tape feeder permits a component

feed during production.

1) Specifications

① 8mm

Tape type

Product code

Paper Embossed

Feeding

pitch

Number of pins

at the edge

Diameter

of a reel

Typical component

type

AF05HP

○ －

1005

AF08HE － ○

2mm

Two-terminal diode

AF081P ○ － 1608, 2012, 3216

AF081E － ○

4mm

Two

SOT

AN05HP ○ － 1005

AN08HE － ○

2mm

Two-terminal diode

AN081P ○ － 1608, 2012, 3216

AN081E － ○

4mm

One

Φ180mm

SOT

* For a tape feeder designed for both paper and embossed paper, contact our sales person.

* Use a tape feeder whose supported component sizes and tape specifications conform to the

JIS C0806-3:1999 and IEC 60286-3:2007.

② 12mm to 24mm

Applicable component

Product code Feed pitch Pick position (Y direction)

Emboss width Emboss depth

AF121S 4mm

AF122S 8mm

AF123S 12mm

AF12FS 4/8/12mm

AF12NS 4/8/12mm

8.3 mm

or less

AF161S 4mm

AF162S 8mm

AF163S 12mm

AF16FS 4/8/12/16mm

AF16NS 4/8/12mm

12.2 mm or less

AF242S 8mm

AF243S 12mm

AF244S 16mm

AF245S 20mm

AF246S 24mm

AF24FS 8/12/16/20/24mm

AF24NS 8/12mm

132mm

AF24FS-OP 8/12/16/20/24mm 114 mm

20.2 mm or less

17mm or less

* Use a tape feeder whose supported component sizes and tape specifications conform to the

JIS C0806-3:1999 and IEC 60286-3:2007.

2) Common specifications

8mm 12mm/16mm 24mm

1 Power supply/air supply None

2 Dimensions

L=645mm

H=213mm

W=16.8mm

L=693mm

H=472mm

W=31.5mm

L=693mm

H=472mm

W=40mm

3 Mass (Excluding a reel) 1.8 kg or less 2.45kg or less 2.6kg or less

4 Component transport method Ratchet drive system

3) Options

① Bar code tag (8mm only)

This tag is used to paste a bar code mark onto the rear edge of a tape feeder.

Even after you install a tape feeder on the feeder bank, the pasted bar code can

be read easily.

② Embossed tape spacer

To improve the feed and pickup stability of the carrier tape for the emboss

component made of a soft and fragile material, this spacer is installed in the

emboss groove of the feeder to support the bottom surface of the carrier tape.

A type for 8 mm feeder, type for both 12 mm and 16 mm feeders, and type for 24

mm feeder are available.

③ Tape reel mounting platform

This is a platform that allows you to set a tape onto a tape feeder. Since you can

set a tape while holding a tape feeder correctly, this option improves the tape

setting capability and prevents a tape feeder from falling down.

Type Application

Tape reel mounting platform (no foot) A user is supposed to fix this option onto a table or similar

device with screws.

Tape reel mounting platform (with foot) This option is equipped with foot, so you can install this

option as desired.

④ Joint tape splicing jig (8mm only)

When you use a JUKI designated joint tape, this jig allows you to paste a joint

tape with glue easily.

⑤ Joint tape

This is a tape that splices an old tape reel and a new tape reel.

A dedicated type for each tape width is available.

⑥ Scissors (Tape cutting jig A, and B)

A positional adjustment between the tape feeder used during the production and

a new tape feeder to be connected can be accurately and quickly made by cutting

the tapes with dedicated scissors when they are spliced.

・Tape cutting jig A: Available for feed pitch (4, 12, 20, 28, 36, 44, 52).

・Tape cutting jig B: Available for feed pitch (8, 16, 24, 32, 40, 48, 56).

6.4.4 FTF/FTFR

1) Specification table

① FTF (12 mm, 16 mm, 24 mm, and 72 mm)

Applicable component

Product code Feed pitch

Pick position

(Y direction)

Emboss

width

Emboss

depth

FF121S 4mm

FF122S 8mm

FF123S 12mm

FF12FS 4/8/12mm

FF12NS 4/8/12mm

8.3mm or

less

FF161S 4mm

FF162S 8mm

FF163S 12mm

FF16FS 4/8/12/16mm

FF16NS 4/8/12mm

12.2mm or

less

6.5mm or

less

FF242S 8mm

FF243S 12mm

FF244S 16mm

FF245S 20mm

FF246S 24mm

FF24FS 8/12/16/20/24mm

FF24NS 8/12mm

20.2mm or

less

FF724S 12/16mm

FF728S 12/16/20/24/28/32mm

132mm

62mm or

less

10.5mm or

less

Power supply/air None

FF12** L =693mm , H =472mm, W=31.5mm

FF16** L =693mm , H =472mm, W=31.5mm

FF24** L =693mm , H =472mm , W=40.0mm

Dimensions

FF72** L =693mm , H =472mm, W=89.2mm

Mass

(Excluding a reel)

FF12**: 2.45kg , FF16**: 2.45kg , FF24**: 2.6kg,

FF72**: 5.1kg

Component transport

method

Ratchet drive system

* Use a tape feeder whose supported component sizes and tape specifications conform to

the JIS C0806-3:1999 and IEC 60286-3:2007.
