6.5 Tray Holder
This tray holder is equipped with one tray, and can be installed on the rear bank so that the
head of the main unit can pick up a component directly from this holder.
When the tray size is small, several trays can be attached on the holder to allow this holder
to function as a multi-tray holder.
Full type Half type
Machine style JX-100 JX-100 LED JX-100 JX-100 LED
Longitudinal direction 65mm to 320mm 65mm to 155mm
Horizontal direction
65mm to
230mm
65mm to
120mm
65mm to
230mm
65mm to
120mm
Thickness
5 mm to 11 mm
(from the bottom of a tray to the top of an IC)
Number of occupied positions
(Note 1)
42 21
* The maximum number of tray holders at the rear-side bank is one of full type and two
of half type.
Note 1: Although the number of feeder positions actually occupied is 40 for the full type,
and 20 for the half type, the number of positions used during PWB production
(according to the feeder layout) is shown in the table above.
27
6.6 Stick Feeder
A stick feeder is driven by the belt without requiring any power supply nor air supply.
It feeds an ordinary SOP, SOJ and PLCC which are packed in a stick.
Call the JUKI head office or local distributor for special components packed in a stick.
SOP SOJ PLCC（QFJ）
Feeder
section type
(Manufacturer
code)
Lane width
(mm)
(Number of
lanes per
feeder)
Nominal
size
Compo
nent
width
(mm)
Compo
nent
height
(mm)
Nominal
size
Compo
nent
width
(mm)
Compo
nent
height
(mm)
Nominal
size
Compo
nent
width
(mm)
Compo
nent
height
(mm)
Number of
occupied
positions
225
mil
5.72 to
6.99
to 1.5 - - - - - -
N0
（SFN0AS）
Factory
setting: 6.9
Adjustable
range: 6.6
to 9.1
300
mil
7.62 to
8.89
2.0 - - - - - -
N1
（SFN1AS）
7.2mm
225
mil
5.72 to
6.99
1.5
- - - - - -
285×
425
mil
8.05 to
8.31
N2
（SFN2AS）
9.2mm
300
mil
7.62 to
8.89
2.0
300
mil
8.38 to
8.76
290×
490
mil
8.13 to
8.51
350
mil
N3
（SFN3AS）
11.2mm
375
mil
9.53 to
10.8
2.5
350
mil
9.65 to
10.03
350×
550
mil
9.78 to
10.03
400
mil
10.92 to
11.30
450
mil
N4
（SFN4AS）
13mm
450
mil
11.43 to
12.7
3.0
450
mil
12.19 to
12.57
3.25～
3.76
450×
550
mil
12.32 to
12.57
4.20 to
4.57
3
W1
（SFW1AS）
15mm
525
mil
13.34 to
14.61
3.5 - - - - - -
W2
（SFW2AS）
18.2mm
600
mil
15.24 to
16.51
4.0 - - -
650
mil
17.40 to
17.65
4.20 to
4.57
W3
（SFW3AS）
20.8mm - - - - - -
750
mil
19.94 to
20.19
W4
（SFW4AS）
26mm - - - - - -
950
mil
25.02 to
25.27
W5
（SFW5AS）
31.2mm - - - - - -
1150
mil
30.10 to
30.55
4.20 to
5.08
6
- The optional spacer kit, which allows a stick feeder to be changed to another type, is
provided for the Types N1 to N4 and W1 to W5.
- You can make the gap of the Type N0 narrower to secure the lane width most
appropriate to SOP 8-pin or 10-pin components.
28
7. CONTROL SYSTEM SPECIFICATIONS
7.1 Control
7.1.1 Program Selection
The production program is stored in SSD or a floppy disk (option).
When you use a USB port, you can store it on an external storage device also.
7.1.2 Limit of a production program
● Number of component placement steps: maximum 3,000 steps
● Maximum number of circuits per PWB: 1,200 for a matrix board
200 for a non-matrix board
● Maximum number of steps per PWB: 10,000 steps
● Maximum number of component data records: maximum number of component
types that can be attached on the machine
● Maximum number of component pick-up records: same as the above.
● Maximum number of registerable marks: 50sets for an IC mark, 1 set for a BOC
mark (2 to 3 marks)
7.2 Production mode
PWB production
- Specifies the number of PWBs you plan to produce and produces PWBs actually.
Trial
- Performs a trial PWB production.
You can select the PWB pick-up position tracking function or PWB placement position
tracking function that is to be performed after placement..
Dry run
- Checks the PWB pick-up/placement process without using any component.
29
