10. MAINTENANCE SPECIFICATIONS

10.1 Troubleshooting

Various help functions allow you to find the cause of an error and search the method for

recovering the error.

10.2 Calibration function

A change of vacuum pressure breakdown timing with the lapse of time is corrected by

itself. When the fixed value is exceeded, a warning for cleaning is displayed.

10.3 MTBA Display Function

This function calculates average interval time (MTBA: mean time between assists)

between consecutive instantaneous stops during PWB production.

11. RELIABILITY SPECIFICATIONS

11.1 Lifetime of devices

Five years: Note that expendable parts and the following periodical replacement parts

are excluded (see the Instruction Manual for details).

- Plastic rail

- Bear cable assembly

- Sensor

- Camera

- Air Solenoid valve

- Air cylinder

- Conveyor belt

- 1394 robot cable assembly

- LCD display

- Gas spring

- Filter element

- Ejector

- SSD

- HOD assembly

- Optical fiber cable assembly

Criteria for calculating the lifetime:

22 hours per day, 300 days per year, 22 x 300 x 5 = 33,000 hours/5 years

◆

Revision record

Rev. Date Revised locations Revision contents Remarks

00a Oct.2008 First edition

01 Dec.2008 P3,4,7,15,16

Revised

01a Feb.2009

P3,4,7,9

Revised

02 Jul.2009

P1～9,15～19,22,23,27,28

For the machine

Rev.A and added

environment condition

Revised

03 Nov.2009 P1,6,7,18,23

Added function

component 0603

Revised

04 Mar.2010 P1～4,6,7～12,16～26 Added JX-100 LED Revised

05 Jan.2011 P1～8,29,30,32,33 For EN machine Revised

06 Nov.2013 P32 Revised Spec. Revised
