32
9. SAFETY SPECIFICATIONS
9.1 Standards specifications
An emergency stop switch is provided in the front section. (However, when the rear bank
is selected as an option, another emergency stop switch is provided in the rear section.
When the emergency stop switch is pressed, each axis is stopped immediately and the
servo motor driving power supply is cut off (servo free status).
9.2 Safety covers
● A cover is provided at the front of the machine. When cover open/close status is
detected by cover open switch and the cover is opened, the machine is put in a servo
free status and stopped immediately. With the cover open, the machine cannot be
started.
● The EN machine has the "Switch key" used to switch between the two modes, the
"Maintenance mode" and the "Operation mode" on the operation panel, and the key is
used for the switching operation of the safety cover according to each mode.
・Operation mode
It usually controls the switching operation of the safety cover during the production.
The servomotor becomes free when the safety cover is opened.
・Maintenance mode
Low-speed operation becomes enabled when the safety cover is open. It is a mode
used for maintenance of the machine.
9.3 CE marking specifications (for EN machine)
This shall comply with the following EC (European committee) instructions
・EC Machinery Directive 2006/42/EC
・EC EMC Directive 2004/108/EC
Applicable standard
・Machinery Directive :
EN ISO12100-1:2010,
EN ISO14121-1:2007, EN ISO13849-1:2008, EN60204-1:2006+A1:2009
・EMC Directive：
EN61000-6-4:2007, EN55016-1-2:2004, EN55016-2-1:2004,EN55016-2-3:2004,
EN61000-6-2-1:2005, EN61000-4-2-1:2009, EN61000-4-3:2006/A1:2008,
EN61000-4-4:2004, EN61000-4-5:2006, EN61000-4-6:2009,
EN61000-4-8:1993/A1：2001, EN61000-4-11:2004,
33
10. MAINTENANCE SPECIFICATIONS
10.1 Troubleshooting
Various help functions allow you to find the cause of an error and search the method for
recovering the error.
10.2 Calibration function
A change of vacuum pressure breakdown timing with the lapse of time is corrected by
itself. When the fixed value is exceeded, a warning for cleaning is displayed.
10.3 MTBA Display Function
This function calculates average interval time (MTBA: mean time between assists)
between consecutive instantaneous stops during PWB production.
11. RELIABILITY SPECIFICATIONS
11.1 Lifetime of devices
Five years: Note that expendable parts and the following periodical replacement parts
are excluded (see the Instruction Manual for details).
- Plastic rail
- Bear cable assembly
- Sensor
- Camera
- Air Solenoid valve
- Air cylinder
- Conveyor belt
- 1394 robot cable assembly
- LCD display
- Gas spring
- Filter element
- Ejector
- SSD
- HOD assembly
- Optical fiber cable assembly
Criteria for calculating the lifetime:
22 hours per day, 300 days per year, 22 x 300 x 5 = 33,000 hours/5 years
◆
Revision record
Rev. Date Revised locations Revision contents Remarks
00a Oct.2008 First edition
01 Dec.2008 P3,4,7,15,16
Revised
01a Feb.2009
P3,4,7,9
Revised
02 Jul.2009
P1～9,15～19,22,23,27,28
For the machine
Rev.A and added
environment condition
Revised
03 Nov.2009 P1,6,7,18,23
Added function
component 0603
Revised
04 Mar.2010 P1～4,6,7～12,16～26 Added JX-100 LED Revised
05 Jan.2011 P1～8,29,30,32,33 For EN machine Revised
06 Nov.2013 P32 Revised Spec. Revised
