A24 はんだ供給ユニ ット ( オプシ ョン ) Solder supply unit (option) ｲﾗｽﾄ番 号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 60 EZ4- 457 - 152 - 01 ｷﾞｱ (GEFHBS 1.5 - 26 - 10 - 15 -W0- WD* ) GEAR(GEFH…
A24
はんだ供給ユニット
(
オプション
)
Solder supply unit (option)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
30 EZ4-455-421-01
ﾎﾟﾂﾄ ｵｻｴ ﾈｼﾞ
SCREW, POT RETAINER
1
31 EZ4-455-422-02
ｼﾘﾝﾀﾞ ﾛﾂｸ
LOCK, CYLINDER
1
32 EZ4-455-423-03
ﾍﾞ-ｽ ﾌﾞﾛﾂｸ
BLOCK, BASE
1
33 EZ4-455-424-01
ﾎﾟﾂﾄ ｵｻｴ ﾌﾟﾚ-ﾄ
PLATE, POT RETAINER
1
34 EZ4-455-425-01
ｽﾗｽﾄ ﾘﾝｸﾞ
RING, THRUST
1
35 EZ4-455-426-01
ｸﾗﾝﾌﾟ ﾌﾞﾛﾂｸ
BLOCK, CLAMP
2
36 EZ4-455-427-02
ｾﾝｻ ﾌﾞﾗｹﾂﾄ
BRACKET, SENSOR
1
37 EZ4-455-428-02
ﾀﾞｲｹｲ ﾈｼﾞ
SCREW, TRAPEZOIDAL
1
38 EZ4-455-429-01
ｶﾗ-
1
COLLAR (1)
1
39 EZ4-455-430-01
ｼﾔﾌﾄ ﾌﾟﾚ-ﾄ
PLATE, SHAFT
1
40 EZ4-455-431-02
ｸﾗﾝﾌﾟ ｶﾊﾞ-
COVER, CLAMP
1
41 EZ4-455-432-01
ｷﾞﾔ ｶﾊﾞ-
COVER, GEAR
1
42 EZ4-455-433-01
ｷﾞﾔ
(1)
GEAR (1)
1
43 EZ4-455-434-01
ｷﾞﾔ ｼﾔﾌﾄ
SHAFT, GEAR
1
44 EZ4-455-435-02
ﾓ-ﾀ ﾌﾞﾗｹﾂﾄ
BRACKET, MOTOR
1
45 EZ4-455-436-01
ｶﾗ-
2
COLLAR (2)
1
46 EZ4-455-437-01
ｶﾗ-
3
COLLAR (3)
1
47 EZ4-455-438-03
ｾﾝｻ ﾌﾞﾗｹﾂﾄ
BRACKET, SENSOR
1
48 EZ4-455-439-02
ﾍﾞ-ｽ ﾌﾟﾚ-ﾄ
PLATE, BASE
1
49 EZ4-455-440-01
ｼﾞﾖｲﾝﾄ ﾌﾞﾛﾂｸ
BLOCK, JOINT
1
50 EZ4-455-441-01
ｽﾗｲﾄﾞ ﾍﾞ-ｽ
BASE, SLIDE
1
51 EZ4-455-442-01
ｼﾘﾝﾀﾞ ﾌﾞﾗｹﾂﾄ
BRACKET, CYLINDER
1
52 EZ4-455-443-01
ｼﾘﾝﾀﾞ ｼﾞﾖｲﾝﾄ
JOINT, CYLINDER
1
53 EZ4-455-444-01
ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ
BRACKET, CABLE BARE
1
54 EZ4-455-446-01
ｾﾝｻ ｱﾝﾌﾟ ﾌﾞﾗｹﾂﾄ
BRACKET, SENSOR AMPLIFIER
1
55 EZ4-455-447-01
ﾘｱ ｶﾊﾞ-
COVER, REAR
1
56 EZ4-456-910-51
ｻﾎﾟ-ﾄ ﾕﾆﾂﾄ
(BUM-8)
SUPPORT UNIT (BUM-8)
1
57 EZ4-456-950-01
ｳﾚﾀﾝ ﾔｷﾂｹ ｸﾂｼﾖﾝ
(UHBKS12-10-M4)
CUSHION (UHBKS12-10-M4)
2
58 EZ4-457-146-01
ｽﾋﾟ-ﾄﾞ ｺﾝﾄﾛ-ﾗ-
(AS1201F-M5-04A)
CONTROLLER (AS1201F-M5-04A)
2
59 EZ4-457-148-02
ｾﾝｻ ﾌﾞﾗｹﾂﾄ
2
BRACKET (2), SENSOR
1
A-86
A24
はんだ供給ユニット
(
オプション
)
Solder supply unit (option)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
60 EZ4-457-152-01
ｷﾞｱ
(GEFHBS1.5-26-10-15-W0-WD*)
GEAR(GEFHBS1.5-26-10-15-W0-W*)
1
61 EZ4-457-152-11
ｷﾞｱ
(GEFKBS1.5-20-10-8N-W0)
GEAR (GEFKBS1.5-20-10-8N-W0)
1
62 EZ4-457-156-01
ﾍｲｺｳ ｷ-
(KEG5-20)
KEY (KEG5-20), PARALLEL
1
63 EZ4-457-168-01
ｶｲﾍｲ ｴｱ ﾁﾔﾂｸ
(MHY2-16D)
AIR ZIPPER (MHY2-16D)
1
64 EZ4-457-170-01
ﾘﾆｱ ｳｴｲ
(MXD20C1R175H/E30)
RAIL (MXD20C1R175H/E30),LINEAR
1
65 EZ4-457-173-01
ｺﾞｸｳｽ ｼﾞﾕｼ ﾜﾂｼﾔ
(SWSPT15-6-0.5)
WASHER (SWSPT15-6-0.5), RESIN
1
66 EZ4-457-176-01
ｸﾂｼﾖﾝ ｺﾞﾑ
(WRBNA60-25-5)
RUBBER (WRBNA60-25-5),
CUSHION
1
67 EZ4-466-341-01
ﾄﾘﾂｹ ﾊﾞﾝﾄﾞ ｾﾂﾄ
(BJ2-016)
BAND SET (BJ2-016), FITTING
2
68 EZ4-466-342-01
ｵ-ﾄ ｽｲﾂﾁ ﾎﾙﾀﾞ ｾﾂﾄ
(BJ3-1)
HOLDER SET (BJ3-1),AUTO SWITCH
2
69
EZ4-455-448-01
ﾎﾟﾂﾄ ﾘﾝｸﾞ (SE) 千住金属工業用
RING (SE), POT For Senjyu.JAPAN
1
左記タイプ以外、またはどのタ
イプかが不明な場合は代理店
または弊社にお問い合わせく
ださい。
If the part type is other than
those on the left or unknown,
please contact the dealer.
EZ4-455-448-11
ﾎﾟﾂﾄ ﾘﾝｸﾞ (TA) タムラ製作所用
RING (TA), POT For TAMURA.JAPAN
1
EZ4-455-448-21
ﾎﾟﾂﾄ ﾘﾝｸﾞ
(NI)
その他 日本製
RING (NI), POT For Other.JAPAN
1
70 EZ4-455-416-01
ｼﾘﾝﾀﾞ
CYLINDER
1
71 EZ4-455-417-01
ﾊﾟﾂｷﾝ ﾌﾟﾚ-ﾄ
PLATE, PACKING
1
72 EZ4-455-418-01
ﾅﾂﾄ
NUT
1
73
EZ4-183-335-01
ﾊﾟﾂｷﾝ
(
ﾌｱｲ
58)
PACKING (DIA. 58)
1
左記タイプ以外、またはどのタ
イプかが不明な場合は代理店
または弊社にお問い合わせく
ださい。
If the part type is other than
those on the left or unknown,
please contact the dealer.
EZ4-183-335-11
ﾊﾟﾂｷﾝ
(
ﾌｱｲ
57.5)
GASKET (DIA. 57.5)
1
EZ4-183-335-21
ﾊﾟﾂｷﾝ
(
ﾌｱｲ
57)
GASKET (DIA. 57)
1
EZ4-183-335-31
ﾊﾟﾂｷﾝ
(
ﾌｱｲ
56.5)
GASKET (DIA. 56.5)
1
EZ4-183-335-41
ﾊﾟﾂｷﾝ
(
ﾌｱｲ
56)
GASKET (DIA. 56)
1
74 EZ4-183-228-01
ﾁﾕ-ﾌﾞ
TUBE
1
EZ4-701-529-01
ﾀｲﾏｳﾝﾄ
(MB1)
TIE MOUNT (MB1)
2
EZ4-706-151-11
ﾊｲｾﾝﾄﾞﾒ
(KR5G5)
CLAMP (KR5G5)
1
EZ2-022-865-01
ﾍｲｺｳ ﾋﾟﾝ
(
ﾌｱｲ
3M6X10)
PIN, PARALLEL (DIA. 3M6X10)
1
EZ4-457-150-01
ﾀﾞﾝﾂｷ ﾎﾞﾙﾄ
(DBS4-5-6)
BOLT (DBS4-5-6), STEP
1
EZ7-627-452-38
ｾｲﾐﾂﾈｼﾞ
+K 2X5, TYPE 1
SCREW,PRECISION +K 2X5
4
EZ4-701-528-11
ﾄﾗｽ ｺﾈｼﾞ
(M4X6)
SCREW (M4X6)
7
EZ7-682-160-01
+P 4X6
SCREW +P 4X6
3
A-87
A24
はんだ供給ユニット
(
オプション
)
Solder supply unit (option)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
EZ7-682-247-09
+K 3X6
SCREW +K 3X6
2
EZ7-682-947-09
+PSW 3X6
SCREW +PSW 3X6
8
EZ4-700-043-51
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M3X15)
BOLT (M3X15), HEXAGON SOCKET
11
EZ4-700-042-41
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X15)
BOLT (M4X15), HEXAGON SOCKET
8
EZ4-700-040-31
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X15)
BOLT (M5X15), HEXAGON SOCKET
4
EZ4-700-045-71
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X15)
BOLT (M6X15), HEXAGON SOCKET
3
EZ4-706-740-12
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M6X45SUS)
BOLT (M6X45SUS),HEXAGON
SOCKET
1
EZ7-683-480-14
6
ｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
2X4
BOLT, HEXAGON SOCKET 2X4
4
EZ7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
6
EZ7-683-405-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X10
BOLT,HEXAGON SOCKET 3X10
10
EZ7-683-418-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X6
BOLT,HEXAGON SOCKET 4X6
4
EZ7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
2
EZ7-683-427-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X25
BOLT,HEXAGON SOCKET 4X25
2
EZ7-683-435-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X10
BOLT,HEXAGON SOCKET 5X10
4
EZ7-683-440-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X20
BOLT,HEXAGON SOCKET 5X20
4
EZ7-683-442-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X25
BOLT,HEXAGON SOCKET 5X25
3
EZ7-683-444-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X30
BOLT,HEXAGON SOCKET 5X30
4
EZ7-683-459-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
6X25
BOLT,HEXAGON SOCKET 6X25
2
EZ7-683-461-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
6X30
BOLT,HEXAGON SOCKET 6X30
5
