A5 カメラ Y 軸ユニッ ト Camera Y axis unit ｲﾗｽﾄ番 号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. EZ 4- 700 - 042 - 41 ﾛﾂｶｸ ｱﾅ ﾂｷ ﾎﾞﾙﾄ (M4X 15 ) BOL T (M4X15), HEXAGON SOCKET 4 EZ 4- 700 - 04…
A5
カメラ
Y
軸ユニット
Camera Y axis unit
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZ1-492-041-42
ｾﾝｻ-
ASSY (S7ORG)
SENSOR ASSY (S7ORG)
1
2 EZ1-492-043-72
ｾﾝｻ-
ASSY (S7CW)
SENSOR ASSY (S7CW)
1
3 EZ1-492-043-82
ｾﾝｻ-
ASSY (S7CCW)
SENSOR ASSY (S7CCW)
1
4 EZ4-454-886-02
ﾍﾞ-ｽ ﾌﾟﾚ-ﾄ
PLATE, BASE
1
5 EZ4-454-887-02
ｻﾎﾟ-ﾄ ﾌﾞﾛﾂｸ
1
BLOCK (1), SUPPORT
1
6 EZ4-454-888-01
ｻﾎﾟ-ﾄ ﾌﾞﾛﾂｸ
2
BLOCK (2), SUPPORT
1
7 EZ4-454-889-01
ﾅﾂﾄ ﾌﾞﾛﾂｸ
BLOCK, NUT
1
8 EZ4-454-905-01
ｽﾗｲﾄﾞ ﾌﾟﾚ-ﾄ
PLATE, SLIDE
1
9 EZ4-454-906-01
ﾄﾞｸﾞ
DOG
1
10 EZ4-456-910-11
ｻﾎﾟ-ﾄ ﾕﾆﾂﾄ
(BUM-12)
SUPPORT UNIT (BUM-12)
1
11 EZ4-456-915-01
ﾎﾞ-ﾙﾈｼ
(FK1520PS-HPNR-675X065*)
SCREW(FK1520PS-HPNR-
675X0653*)
1
12 EZ4-456-927-01
ﾘﾆｱ ｳｴｲ
(MES20C2R700T1PS1)
RAIL (MES20C2R700T1PS1),LINEAR
1
13 EZ4-456-953-01
ｶﾂﾌﾟﾘﾝｸﾞ
(XGS-25C-8X10)
COUPLING (XGS-25C-8X10)
1
14 EZ4-454-908-03
ｶﾊﾞ-
2
COVER (2)
1
15 EZ4-454-909-04
ｶﾊﾞ-
3
COVER (3)
1
16 EZ4-454-907-03
ｶﾊﾞ-
1
COVER (1)
1
17 EZ4-454-910-04
ｶﾊﾞ-
4
COVER (4)
1
18 EZ1-787-836-11
ｻ-ﾎﾞ ﾓ-ﾀ
(SGMJV-01ADA21)
MOTOR, SERVO (SGMJV-01ADA21)
1
19 EZA-1899-202-A
SC MOUNT
SC MOUNT
1
20 EZ2-990-379-01
ｼﾁﾕｳ
SUPPORT
4
21 EZ2-592-891-01
C
ｶﾞﾀ ﾄﾒﾜ
10 (
ｼﾞｸ ﾖｳ
)
STOP RING 10, TYPE C
1
22 EZ4-184-270-51
ｹ-ﾌﾞﾙ ﾍﾞｱ
(TKP0180W40R50-39L*)
BARE (TKP0180W40R50-39L+PIA*)
1
EZ4-701-529-01
ﾀｲﾏｳﾝﾄ
(MB1)
TIE MOUNT (MB1)
6
EZ7-682-248-02
+K M3X8
SCREW +K M3X8
6
EZ7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
6
EZ7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
3
EZ7-683-420-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X10
BOLT,HEXAGON SOCKET 4X10
4
EZ7-683-435-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X10
BOLT,HEXAGON SOCKET 5X10
10
EZ7-683-440-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X20
BOLT,HEXAGON SOCKET 5X20
6
A-20
A5
カメラ
Y
軸ユニット
Camera Y axis unit
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
EZ4-700-042-41
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M4X15)
BOLT (M4X15), HEXAGON SOCKET
4
EZ4-700-040-31
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M5X15)
BOLT (M5X15), HEXAGON SOCKET
12
EZ4-700-045-71
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M6X15)
BOLT (M6X15), HEXAGON SOCKET
2
A-21
