A10
コンベア奥側
Back side conveyor lane
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZ1-492-013-23
DC
ﾓ-ﾀ-
2 ASSY
ASSY, DC MOTOR
1
2 EZ1-492-258-12
ｾﾝｻ-
ASSY (IN3-9)
SENSOR ASSY (IN3-9)
1
3 EZ1-492-473-12
SENSOR ASSY (IN3-6)
SENSOR ASSY (IN3-6)
1
4 EZ2-022-865-21
ﾍｲｺｳ ﾋﾟﾝ
(
ﾌｱｲ
3M6X8)
PIN, PARALLEL (DIA. 3M6X8)
2
5 EZ2-022-865-41
ﾍｲｺｳ ﾋﾟﾝ
(
ﾌｱｲ
3M6X12)
PIN, PARALLEL (DIA. 3M6X12)
2
6 EZ3-298-338-11
ﾋﾂﾊﾟﾘ ﾊﾞﾈ
(AUY4-15)
SPRING (AUY4-15), TENSION
2
7 EZ4-297-420-01
ﾌﾟ-ﾘ-
(B)
PULLEY (B)
1
8 EZ4-447-108-01
ｴﾙﾎﾞ ﾕﾆｵﾝ
(KQ2L04-M3G)
UNION (KQ2L04-M3G), ELBOW
4
9 EZ4-454-504-01
ｱｲﾄﾞﾗ-
(AS-5A39A) A
IDLER (AS-5A39A) (A)
4
10 EZ4-454-511-01
ﾌﾟ-ﾘ
(P30-2GT) A
PULLEY (P30-2GT) (A)
3
11 EZ4-455-135-01
ﾌﾟﾚ-ﾄ
(2L)
PLATE (2L)
1
12 EZ4-455-135-11
ﾌﾟﾚ-ﾄ
(2R)
PLATE (2R)
1
13 EZ4-455-137-01
ﾍﾞﾙﾄ ｶﾞｲﾄﾞ
3
GUIDE (3), BELT
2
14 EZ4-455-138-02
ｽﾌﾟﾘﾝｸﾞ ﾌﾟﾚ-ﾄ
PLATE, SPRING
2
15 EZ4-455-143-02
ﾌﾞﾚ-ｷ ﾊﾟﾂﾄﾞ
(1)
PAD (1), BRAKE
1
16 EZ4-455-143-11
ﾌﾞﾚ-ｷ ﾊﾟﾂﾄﾞ
(2)
PAD (2), BRAKE
1
17 EZ4-455-144-01
ﾌﾞﾚ-ｷ ﾌﾞﾛﾂｸ
BLOCK, BRAKE
4
18 EZ4-455-145-01
ﾌﾞﾚ-ｷ ﾍﾞ-ｽ
BASE, BRAKE
2
19 EZ4-455-148-01
ﾛ-ﾗ ﾌﾞﾗｹﾂﾄ
1
BRACKET (1), ROLLER
1
20 EZ4-455-148-11
ﾛ-ﾗ ﾌﾞﾗｹﾂﾄ
2
BRACKET (2), ROLLER
1
21 EZ4-455-153-02
ﾌﾞﾚ-ｷ ﾌﾟﾚ-ﾄ
PLATE, BRAKE
2
22 EZ4-455-160-02
ｺﾝﾍﾞｱ ﾍﾞ-ｽ
BASE, CONVEYOR
1
23 EZ4-455-161-02
ﾍﾞﾙﾄ ｶﾞｲﾄﾞ
(1)
GUIDE (1), BELT
1
24 EZ4-455-161-12
ﾍﾞﾙﾄ ｶﾞｲﾄﾞ
(2)
GUIDE (2), BELT
1
25 EZ4-455-163-02
ﾓ-ﾀ ﾌﾞﾗｹﾂﾄ
BRACKET, MOTOR
1
26 EZ4-455-165-01
ｾﾝｻ ﾌﾞﾗｹﾂﾄ
3
BRACKET (3), SENSOR
2
27 EZ4-528-346-01
ﾌﾗﾝｼﾞ
FLANGE
4
A-36
A10
コンベア奥側
Back side conveyor lane
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
28
EZ4-528-345-01
ﾌﾟ
-
ﾘ
PULLEY
2
プーリーは左の 4 種の部品で
構成されました。
The pulley consists of four
parts on the left.
EZ4-142-189-01
ﾍﾞｱﾘﾝｸﾞ
(MF106ZZ)
BEARING (MF106ZZ)
4
EZ4-528-347-01
ｼﾔﾌﾄ
SHAFT
2
EZ4-528-348-01
ｶﾗ
-
COLLAR
2
29 EZ4-456-878-21
ｼﾘﾝﾀﾞ
(CUJB12-10S)
CYLINDER (CUJB12-10S)
2
30 EZ4-456-878-31
ｼﾘﾝﾀﾞ
(CUJB6-6S)
CYLINDER (CUJB6-6S)
1
31 EZ4-456-879-01
ｶﾑ ﾌｵﾛｱ
(CF5BUU)
FOLLOWER (CF5BUU), CAM
2
32 EZ4-456-895-01
ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ
(120-2GT-2)
BELT (120-2GT-2), TIMING
1
33 EZ4-456-895-11
ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ
(1320-2GT-2)
BELT (1320-2GT-2), TIMING
1
34 EZ4-456-895-21
ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ
(1434-2GT-2)
BELT (1434-2GT-2), TIMING
1
35 EZ4-456-911-01
ｽﾘﾂﾄ
(E39-S63)
SLIT (E39-S63)
2
36 EZ4-456-912-01
ｸﾗﾝﾌﾟ ﾓｼﾞﾕ-ﾙ
(EV-20-4)
MODULE (EV-20-4), CLAMP
2
37 EZ4-456-933-01
ﾘﾆｱ ｳｴｲ
(ML9C1R43E753)
LINEAR WAY (ML9C1R43E753)
2
38 EZ4-456-934-01
ﾘﾆｱ ｳｴｲ
(MLC9C1R29HS1)
LINEAR WAY (MLC9C1R29HS1)
4
39 EZ4-706-151-11
ﾊｲｾﾝﾄﾞﾒ
(KR5G5)
CLAMP (KR5G5)
8
40 EZ4-466-191-02
ｸﾗﾝﾌﾟ ﾌﾞﾛﾂｸ
BLOCK, CLAMP
1
41 EZ4-466-192-03
ﾌﾟﾂｼﾕ ﾌﾞﾚ-ﾄﾞ
BLADE, PUSH
1
42 EZ4-466-193-02
ﾌﾟﾂｼﾕ ﾍﾞ-ｽ
BASE, PUSH
1
43 EZ4-466-194-01
ﾛﾂﾄﾞ ﾌﾟﾚ-ﾄ
PLATE, ROD
1
44 EZ4-466-195-01
ｶﾞｲﾄﾞ ﾍﾞ-ｽ
BASE, GUIDE
2
45 EZ4-466-196-01
ｼﾘﾝﾀﾞ ﾍﾞ-ｽ
BASE, CYLINDER
1
46 EZ4-466-197-01
ﾄﾞｸﾞ
DOG
1
47 EZ4-466-206-01
ﾊﾞﾈ ﾎﾟｽﾄ
(SBSPOZ4-15)POST
(SBSPOZ4-15), SPRING
2
48 EZ4-716-843-01
ﾊﾞ-ﾌﾞ ｴﾙﾎﾞ
(M-3ALU-4)
ELBOW, BAMBOO (M-3AU-4)
1
49 EZ2-679-468-51
ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ
(CBSTS3-16)
BOLT (CBSTS3-16)
2
50 EZ3-282-481-01
ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ
(CBSA3-5)
BOLT (CBSA3-5)
10
51 EZ4-456-937-01
ﾘﾆｱ ｳｴｲ
(MLF30C1R60H)
LINEAR WAY (MLF30C1R60H)
2
52 EZ7-682-947-01
+PSW 3X6
SCREW +PSW 3X6
12
53 EZ7-682-960-01
+PSW 4X6
SCREW +PSW 4X6
8
54 EZ7-683-402-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X5
BOLT,HEXAGON SOCKET 3X5
8
A-37
A10
コンベア奥側
Back side conveyor lane
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
55 EZ7-683-403-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X6
BOLT,HEXAGON SOCKET 3X6
6
56 EZ7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
4
57 EZ7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
12
58 EZ7-683-420-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X10
BOLT,HEXAGON SOCKET 4X10
28
59 EZ2-593-797-01
U
ﾅﾂﾄ
(M4, 2
ｼﾕ
)
U NUT (M4, 2 MAIN)
1
60 EZ4-700-043-01
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M3X4)
BOLT (M3X4), HEXAGON SOCKET
4
61 EZ4-700-043-31
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M3X10)
BOLT (M3X10), HEXAGON SOCKET
10
62 EZ4-700-042-41
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M4X15)
BOLT (M4X15), HEXAGON SOCKET
18
63 EZ4-718-767-07
ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ
(M4X20 SUS)
SET-SCREW (M4X20 SUS), HEAD
2
64 EZ7-684-000-02
6
ｶｸﾅﾂﾄ
M4, TYPE2
NUT, HEXAGON M4, TYPE2
2
EZ7-627-451-28
ｾｲﾐﾂﾈｼﾞ
+K 1.4X3, TYPE 1
SCREW,PRECISION +K 1.4X3
10
EZ7-623-210-22
SW 4,TYPE 2
SW 4,TYPE 2
6
EZ7-684-000-01
6
ｶｸﾅﾂﾄ
M3, TYPE2
NUT, HEXAGON M3, TYPE2
2
EZ7-684-000-02
6
ｶｸﾅﾂﾄ
M4, TYPE2
NUT, HEXAGON M4, TYPE2
4
EZ4-718-767-01
ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ
(M4X5 SUS)
SET-SCREW (M4X5 SUS), HEAD
2
A-38
