A 10 コンベア奥側 Back side conv eyor lane 15 17 62 57 17 58 58 17 36 25 58 18 62 18 19 20 31 58 58 36 57 54 8 62 30 46 47 47 43 54 48 55 17 62 61 31 16 57 6 5 45 56 38 44 39 53 39 39 39 44 6 3 5 7 1 58 58 9 10 10 10 1 1 21 60…
A9
コンベア手前側
Front side conveyor lane
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
58 EZ7-682-960-01
+PSW 4X6
SCREW +PSW 4X6
11
59 EZ7-683-402-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X5
BOLT,HEXAGON SOCKET 3X5
10
60 EZ7-683-403-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X6
BOLT,HEXAGON SOCKET 3X6
10
61 EZ7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
10
62 EZ7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
12
63 EZ7-683-420-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X10
BOLT,HEXAGON SOCKET 4X10
38
64 EZ7-683-425-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X20
BOLT,HEXAGON SOCKET 4X20
4
65 EZ4-700-043-01
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M3X4)
BOLT (M3X4), HEXAGON SOCKET
4
66 EZ4-700-043-31
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M3X10)
BOLT (M3X10), HEXAGON SOCKET
12
67 EZ4-700-042-41
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M4X15)
BOLT (M4X15), HEXAGON SOCKET
24
68 EZ4-718-767-07
ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ
(M4X20 SUS)
SET-SCREW (M4X20 SUS), HEAD
2
69 EZ7-684-000-02
6
ｶｸﾅﾂﾄ
M4, TYPE2
NUT, HEXAGON M4, TYPE2
2
EZ4-718-767-01
ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ
(M4X5 SUS)
SET-SCREW (M4X5 SUS), HEAD
2
EZ7-684-000-02
6
ｶｸﾅﾂﾄ
M4, TYPE2
NUT, HEXAGON M4, TYPE2
8
EZ4-441-712-01
ﾊﾞﾈｻﾞｶﾞﾈ
SW3
SPRONG, WASHER 3
4
EZ7-623-210-22
SW 4,TYPE 2
SW 4,TYPE 2
10
EZ7-688-003-11
W 3, MIDDLE
W 3, MIDDLE
4
EZ7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
2
A-34
A10
コンベア奥側
Back side conveyor lane
15
17
62
57
17
58
58
17
36
25
58
18
62
18
19
20
31
58
58
36
57
54
8
62
30
46
47
47
43
54
48
55
17
62
61
31
16
57
6
5
45
56
38
44
39
53
39
39
39
44
6
3
5
7
1
58
58
9
10
10
10
1
1
21
60
54
57
8
58
21
9
34
9
9
13
13
22
42
59
28
27
27
23
40
41
63
64
39
53
53
39
51
62
55
55
55
4
56
38
58
58
62
61
62
37
61
60
37
24
52
50
14
52
50
14
26
58
2
29
62
58
8
38
12
38
29
8
62
26
58
35
2
35
49
62
63
64
51
39
39
32
33
62
53
53
53
53
53
A-35
A10
コンベア奥側
Back side conveyor lane
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZ1-492-013-23
DC
ﾓ-ﾀ-
2 ASSY
ASSY, DC MOTOR
1
2 EZ1-492-258-12
ｾﾝｻ-
ASSY (IN3-9)
SENSOR ASSY (IN3-9)
1
3 EZ1-492-473-12
SENSOR ASSY (IN3-6)
SENSOR ASSY (IN3-6)
1
4 EZ2-022-865-21
ﾍｲｺｳ ﾋﾟﾝ
(
ﾌｱｲ
3M6X8)
PIN, PARALLEL (DIA. 3M6X8)
2
5 EZ2-022-865-41
ﾍｲｺｳ ﾋﾟﾝ
(
ﾌｱｲ
3M6X12)
PIN, PARALLEL (DIA. 3M6X12)
2
6 EZ3-298-338-11
ﾋﾂﾊﾟﾘ ﾊﾞﾈ
(AUY4-15)
SPRING (AUY4-15), TENSION
2
7 EZ4-297-420-01
ﾌﾟ-ﾘ-
(B)
PULLEY (B)
1
8 EZ4-447-108-01
ｴﾙﾎﾞ ﾕﾆｵﾝ
(KQ2L04-M3G)
UNION (KQ2L04-M3G), ELBOW
4
9 EZ4-454-504-01
ｱｲﾄﾞﾗ-
(AS-5A39A) A
IDLER (AS-5A39A) (A)
4
10 EZ4-454-511-01
ﾌﾟ-ﾘ
(P30-2GT) A
PULLEY (P30-2GT) (A)
3
11 EZ4-455-135-01
ﾌﾟﾚ-ﾄ
(2L)
PLATE (2L)
1
12 EZ4-455-135-11
ﾌﾟﾚ-ﾄ
(2R)
PLATE (2R)
1
13 EZ4-455-137-01
ﾍﾞﾙﾄ ｶﾞｲﾄﾞ
3
GUIDE (3), BELT
2
14 EZ4-455-138-02
ｽﾌﾟﾘﾝｸﾞ ﾌﾟﾚ-ﾄ
PLATE, SPRING
2
15 EZ4-455-143-02
ﾌﾞﾚ-ｷ ﾊﾟﾂﾄﾞ
(1)
PAD (1), BRAKE
1
16 EZ4-455-143-11
ﾌﾞﾚ-ｷ ﾊﾟﾂﾄﾞ
(2)
PAD (2), BRAKE
1
17 EZ4-455-144-01
ﾌﾞﾚ-ｷ ﾌﾞﾛﾂｸ
BLOCK, BRAKE
4
18 EZ4-455-145-01
ﾌﾞﾚ-ｷ ﾍﾞ-ｽ
BASE, BRAKE
2
19 EZ4-455-148-01
ﾛ-ﾗ ﾌﾞﾗｹﾂﾄ
1
BRACKET (1), ROLLER
1
20 EZ4-455-148-11
ﾛ-ﾗ ﾌﾞﾗｹﾂﾄ
2
BRACKET (2), ROLLER
1
21 EZ4-455-153-02
ﾌﾞﾚ-ｷ ﾌﾟﾚ-ﾄ
PLATE, BRAKE
2
22 EZ4-455-160-02
ｺﾝﾍﾞｱ ﾍﾞ-ｽ
BASE, CONVEYOR
1
23 EZ4-455-161-02
ﾍﾞﾙﾄ ｶﾞｲﾄﾞ
(1)
GUIDE (1), BELT
1
24 EZ4-455-161-12
ﾍﾞﾙﾄ ｶﾞｲﾄﾞ
(2)
GUIDE (2), BELT
1
25 EZ4-455-163-02
ﾓ-ﾀ ﾌﾞﾗｹﾂﾄ
BRACKET, MOTOR
1
26 EZ4-455-165-01
ｾﾝｻ ﾌﾞﾗｹﾂﾄ
3
BRACKET (3), SENSOR
2
27 EZ4-528-346-01
ﾌﾗﾝｼﾞ
FLANGE
4
