A 6 カメラ X 軸 (F) ユニット Camera X axis unit (Front) 6 1 1 8 6 6 15 1 6 3 22 22 2 4 10 17 20 16 14 13 5 18 9 17 21 12 19 7 A- 22
A6
カメラ
X
軸
(F)
ユニット
Camera X axis unit (Front)
6
11
8
6
6
15
1
6
3
22
22
2
4
10
17
20
16
14
13
5
18
9
17
21
12
19
7
A-22
A6
カメラ
X
軸
(F)
ユニット
Camera X axis unit (Front)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZA-1899-202-A
SC MOUNT
SC MOUNT
1
2 EZ1-492-041-52
ｾﾝｻ-
ASSY (S8ORG)
SENSOR ASSY (S8ORG)
1
3 EZ1-492-044-12
ｾﾝｻ-
ASSY (S8CW)
SENSOR ASSY (S8CW)
1
4 EZ1-492-044-22
ｾﾝｻ-
ASSY (S8CCW)
SENSOR ASSY (S8CCW)
1
5 EZ1-787-836-11
ｻ-ﾎﾞ ﾓ-ﾀ
(SGMJV-01ADA21)
MOTOR, SERVO (SGMJV-01ADA21)
1
6 EZ2-990-379-01
ｼﾁﾕｳ
SUPPORT
4
7 EZ4-454-870-02
ﾍﾞ-ｽ ﾌﾟﾚ-ﾄ
PLATE, BASE
1
8 EZ4-454-871-01
ｻﾎﾟ-ﾄ ﾌﾞﾛﾂｸ
1
BLOCK (1), SUPPORT
1
9 EZ4-454-872-01
ｻﾎﾟ-ﾄ ﾌﾞﾛﾂｸ
2
BLOCK (2), SUPPORT
1
10 EZ4-454-873-03
ﾅﾂﾄ ﾌﾞﾛﾂｸ
BLOCK, NUT
1
11 EZ4-454-874-01
ﾄﾞｸﾞ
DOG
1
12 EZ4-454-875-01
ｶﾊﾞ-
1
COVER (1)
1
13 EZ4-454-877-01
ｽﾍﾟ-ｻ
SPACER
1
14 EZ4-454-878-01
ﾀ-ﾝ ｼﾔﾌﾄ
SHAFT, TURN
1
15 EZ4-454-876-01
ｶﾊﾞ-
2
COVER (2)
1
16 EZ4-456-896-01
ｸﾛｽ ﾛ-ﾗ- ﾘﾝｸﾞ
(CRBF2012ATUUT1)
RING (CRBF2012ATUUT1), ROLLER
1
17 EZ4-456-910-11
ｻﾎﾟ-ﾄ ﾕﾆﾂﾄ
(BUM-12)
SUPPORT UNIT (BUM-12)
1
18 EZ4-456-914-01
ﾎﾞ-ﾙﾈｼﾞ
(FK1520PS-HPNR-1100X1*)
SCREW(FK1520PS-HPNR-
1100X102*)
1
19 EZ4-456-925-01
ﾘﾆｱ ｳｴｲ
(MEG15C1R1060E014)
LINEAR WAY (MEG15C1R1060E014)
1
20 EZ4-456-953-01
ｶﾂﾌﾟﾘﾝｸﾞ
(XGS-25C-8X10)
COUPLING (XGS-25C-8X10)
1
21 EZ2-592-891-01
C
ｶﾞﾀ ﾄﾒﾜ
10 (
ｼﾞｸ
ﾖｳ
)
STOP RING 10, TYPE C
1
22 EZ4-705-546-41
ﾍｲｺｳ ﾋﾟﾝ
(
ﾌｱｲ
6)
PIN (DIA. 6), PARALLEL
2
EZ4-701-529-01
ﾀｲﾏｳﾝﾄ
(MB1)
TIE MOUNT (MB1)
6
EZ4-706-151-11
ﾊｲｾﾝﾄﾞﾒ
(KR5G5)
CLAMP (KR5G5)
2
EZ7-682-248-02
+K M3X8
SCREW +K M3X8
6
EZ7-682-160-09
+P 4X6
SCREW +P 4X6
1
EZ7-682-947-09
+PSW 3X6
SCREW +PSW 3X6
6
EZ7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
8
EZ7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
14
A-23
