A9
コンベア手前側
Front side conveyor lane
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
31 EZ4-528-346-01
ﾌﾗﾝｼﾞ
FLANGE
4
32
EZ4-528-345-01
ﾌﾟ
-
ﾘ
PULLEY
2
プーリーは左の 4 種の部品で
構成されました。
The pulley consists of four
parts on the left.
EZ4-142-189-01
ﾍﾞｱﾘﾝｸﾞ
(MF106ZZ)
BEARING (MF106ZZ)
4
EZ4-528-347-01
ｼﾔﾌﾄ
SHAFT
2
EZ4-528-348-01
ｶﾗ
-
COLLAR
2
33 EZ4-456-878-21
ｼﾘﾝﾀﾞ
(CUJB12-10S)
CYLINDER (CUJB12-10S)
2
34 EZ4-456-878-31
ｼﾘﾝﾀﾞ
(CUJB6-6S)
CYLINDER (CUJB6-6S)
1
35 EZ4-456-879-01
ｶﾑ ﾌｵﾛｱ
(CF5BUU)
FOLLOWER (CF5BUU), CAM
2
36 EZ4-456-895-01
ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ
(120-2GT-2)
BELT (120-2GT-2), TIMING
1
37 EZ4-456-895-11
ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ
(1320-2GT-2)
BELT (1320-2GT-2), TIMING
1
38 EZ4-456-895-21
ﾀｲﾐﾝｸﾞ ﾍﾞﾙﾄ
(1434-2GT-2)
BELT (1434-2GT-2), TIMING
1
39 EZ4-456-912-01
ｸﾗﾝﾌﾟ ﾓｼﾞﾕ-ﾙ
(EV-20-4)
MODULE (EV-20-4), CLAMP
2
40 EZ4-456-933-01
ﾘﾆｱ ｳｴｲ
(ML9C1R43E753)
LINEAR WAY (ML9C1R43E753)
2
41 EZ4-456-934-01
ﾘﾆｱ ｳｴｲ
(MLC9C1R29HS1)
LINEAR WAY (MLC9C1R29HS1)
4
42 EZ4-456-937-01
ﾘﾆｱ ｳｴｲ
(MLF30C1R60H)
LINEAR WAY (MLF30C1R60H)
2
43 EZ4-466-191-02
ｸﾗﾝﾌﾟ ﾌﾞﾛﾂｸ
BLOCK, CLAMP
1
44 EZ4-466-192-03
ﾌﾟﾂｼﾕ ﾌﾞﾚ-ﾄﾞ
BLADE, PUSH
1
45 EZ4-466-193-02
ﾌﾟﾂｼﾕ ﾍﾞ-ｽ
BASE, PUSH
1
46 EZ4-466-194-01
ﾛﾂﾄﾞ ﾌﾟﾚ-ﾄ
PLATE, ROD
1
47 EZ4-466-195-01
ｶﾞｲﾄﾞ ﾍﾞ-ｽ
BASE, GUIDE
2
48 EZ4-466-196-01
ｼﾘﾝﾀﾞ ﾍﾞ-ｽ
BASE, CYLINDER
1
49 EZ4-466-197-01
ﾄﾞｸﾞ
DOG
1
50 EZ4-466-206-01
ﾊﾞﾈ ﾎﾟｽﾄ
(SBSPOZ4-15)
POST (SBSPOZ4-15), SPRING
2
51 EZ4-716-843-01
ﾊﾞ-ﾌﾞ ｴﾙﾎﾞ
(M-3ALU-4)
ELBOW, BAMBOO (M-3AU-4)
1
52 EZ7-683-461-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
6X30
BOLT,HEXAGON SOCKET 6X30
53 EZ4-706-151-11
ﾊｲｾﾝﾄﾞﾒ
(KR5G5)
CLAMP (KR5G5)
12
54 EZ2-679-468-51
ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ
(CBSTS3-16)
BOLT (CBSTS3-16)
2
55 EZ3-282-481-01
ｺﾞｸ ﾃｲﾄｳ ﾎﾞﾙﾄ
(CBSA3-5)
BOLT (CBSA3-5)
10
56 EZ2-593-797-01
U
ﾅﾂﾄ
(M4, 2
ｼﾕ
)
U NUT (M4, 2 MAIN)
1
57 EZ7-682-947-01
+PSW 3X6
SCREW +PSW 3X6
12
A-33
A9
コンベア手前側
Front side conveyor lane
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
58 EZ7-682-960-01
+PSW 4X6
SCREW +PSW 4X6
11
59 EZ7-683-402-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X5
BOLT,HEXAGON SOCKET 3X5
10
60 EZ7-683-403-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X6
BOLT,HEXAGON SOCKET 3X6
10
61 EZ7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
10
62 EZ7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
12
63 EZ7-683-420-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X10
BOLT,HEXAGON SOCKET 4X10
38
64 EZ7-683-425-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X20
BOLT,HEXAGON SOCKET 4X20
4
65 EZ4-700-043-01
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M3X4)
BOLT (M3X4), HEXAGON SOCKET
4
66 EZ4-700-043-31
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M3X10)
BOLT (M3X10), HEXAGON SOCKET
12
67 EZ4-700-042-41
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M4X15)
BOLT (M4X15), HEXAGON SOCKET
24
68 EZ4-718-767-07
ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ
(M4X20 SUS)
SET-SCREW (M4X20 SUS), HEAD
2
69 EZ7-684-000-02
6
ｶｸﾅﾂﾄ
M4, TYPE2
NUT, HEXAGON M4, TYPE2
2
EZ4-718-767-01
ﾛﾂｶｸ ｱﾅﾂｷ ﾄﾒﾈｼﾞ
(M4X5 SUS)
SET-SCREW (M4X5 SUS), HEAD
2
EZ7-684-000-02
6
ｶｸﾅﾂﾄ
M4, TYPE2
NUT, HEXAGON M4, TYPE2
8
EZ4-441-712-01
ﾊﾞﾈｻﾞｶﾞﾈ
SW3
SPRONG, WASHER 3
4
EZ7-623-210-22
SW 4,TYPE 2
SW 4,TYPE 2
10
EZ7-688-003-11
W 3, MIDDLE
W 3, MIDDLE
4
EZ7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
2
A-34
A10
コンベア奥側
Back side conveyor lane
