A21 クリーニングユニット ( オプショ ン ) Cleaning unit ( option) ｲﾗｽﾄ番 号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 31 EZ4- 455 - 319 - 01 ｼﾞﾖｲﾝﾄ ﾄﾞｸﾞ CXR DOG (CXR), J OINT 1 32 EZ4- 455 - 321 -…
A21
クリーニングユニット
(
オプション
)
Cleaning unit (option)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZA-1899-202-A
SC MOUNT
SC MOUNT
2
2 EZ1-492-032-14
ｾﾝｻ-
ASSY (IN2-7)
SENSOR ASSY (IN2-7)
1
3 EZ1-492-032-24
ｾﾝｻ-
ASSY (IN2-8)
SENSOR ASSY (IN2-8)
1
4 EZ1-492-034-63
ｾﾝｻ-
ASSY (IN2-10)
SENSOR ASSY (IN2-10)
1
5 EZ1-492-041-83
ｾﾝｻ-
ASSY (IN2-11)
SENSOR ASSY (IN2-11)
1
6 EZ1-492-024-12
ｾﾝｻ-
ASSY (L11)
SENSOR ASSY (IN2-12)
1
7 EZ1-492-338-13
ｾﾝｻ-
ASSY (IN2-9)
SENSOR ASSY (IN2-9)
1
8 EZ1-787-838-11
ｻ-ﾎﾞ ﾓ-ﾀ
(SGMJV-01ADA61)
MOTOR, SERVO (SGMJV-01ADA61)
1
9 EZ4-459-003-01
ｱﾂｼﾕｸ
ｺｲﾙ
ﾊﾞﾈ
(#5558)
SPRING (#5558), COMPRESSION
1
10 EZ2-249-361-01
ﾍｲｺｳ
ﾋﾟﾝ
(
ｺｳｼﾂ
)
PIN, PARALLEL
1
11 EZ2-584-986-31
ﾛ-ﾚﾂﾄ ﾉﾌﾞ
(NKOSC6-10-22)
KNOB (NKOSC6-10-22), KNURL
2
12 EZ2-672-391-11
ｽﾄﾂﾌﾟ
ﾋﾟﾝ
(USTEH8)
PIN, STOP (USTEH8)
2
13 EZ2-672-449-31
ｱﾂｼﾕｸ
ｺｲﾙ
ﾊﾞﾈ
(1135)
SPRING, COMPRESSION COIL(1135)
2
14 EZ2-691-046-21
ﾜﾂｼﾔ
(WSSB20-8-1)
WASHER (WSSB20-8-1)
2
15 EZ2-693-716-01
ﾐﾆﾁﾕｱ
ﾀﾏ
ｼﾞｸｳｹ
(F688AZZ1)
BALL (BEARING (F688AZZ1))
2
16 EZ2-990-379-01
ｼﾁﾕｳ
SUPPORT
8
17 EZ4-141-605-01
ﾄﾙｸ
ﾘﾐﾂﾀ
(OTLV8-1500C)
LIMITER (OTLV8-1500C), TORQUE
1
18 EZ4-184-270-51
ｹ-ﾌﾞﾙ ﾍﾞｱ
(TKP0180W40R50-39L*)
BARE (TKP0180W40R50-39L+PIA*)
1
19 EZ4-447-109-01
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L04-M5A)
UNION (KQ2L04-M5A), ELBOW
2
20 EZ4-447-186-01
ﾕﾆｵﾝ
ﾜｲ
(KQ2U04-00A)
WYE (KQ2U04-00A), UNION
4
21 EZ4-455-307-01
ﾓ-ﾀ ｼﾞｸﾞ ｱﾀﾞﾌﾟﾀ
ADAPTOR, MOTOR SHAFT
1
22 EZ4-455-308-01
ﾘﾐﾂﾄ
ﾌﾞﾗｹﾂﾄ
BRACKET, LIMIT
1
23 EZ4-455-309-01
ｶﾗ-
S
COLLAR (S)
2
24 EZ4-455-310-01
ｶﾗ-
L
COLLAR (L)
1
25 EZ4-455-313-01
ﾍﾟ-ﾊﾟ- ｵｻｴ
RETAINER, PAPER
3
26 EZ4-455-314-01
ｼﾔﾌﾄ
R
SHAFT (R)
1
27 EZ4-455-315-01
ｼﾔﾌﾄ
F
SHAFT (F)
2
28 EZ4-455-317-02
ｷﾊﾞﾝ
ﾌﾞﾗｹﾂﾄ
BRACKET, PC BOARD
1
29 EZ4-455-318-02
ｼﾞﾖｲﾝﾄ
ﾌﾞﾗｹﾂﾄ
CXF
BRACKET (CXF), JOINT
1
30 EZ4-455-318-12
ｼﾞﾖｲﾝﾄ
ﾌﾞﾗｹﾂﾄ
CXR
BRACKET (CXR), JOINT
1
A-77
A21
クリーニングユニット
(
オプション
)
Cleaning unit (option)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
31 EZ4-455-319-01
ｼﾞﾖｲﾝﾄ
ﾄﾞｸﾞ
CXR
DOG (CXR), JOINT
1
32 EZ4-455-321-01
ｸﾘ-ﾆﾝｸﾞ ﾄﾞｸﾞ
DOG, CLEANING
1
33 EZ4-455-322-02
Z
ｼﾘﾝﾀﾞ
ﾌﾞﾗｹﾂﾄ
F
BRACKET (F), Z CYLINDER
1
34 EZ4-455-322-12
Z
ｼﾘﾝﾀﾞ
ﾌﾞﾗｹﾂﾄ
R
BRACKET (R), Z CYLINDER
1
35 EZ4-455-324-02
Z
ｼﾞｸ
ｼﾔﾌﾄ
ﾎﾙﾀﾞ
F
HOLDER (F), Z AXIS SHAFT
1
36 EZ4-455-325-02
Z
ｼﾞｸ
ﾋﾝｼﾞ
R
HINGE (R), Z AXIS
1
37 EZ4-455-326-02
Z
ｼﾞｸ
ﾋﾝｼﾞ
F
HINGE (F), Z AXIS
1
38 EZ4-455-327-02
Z
ｼﾞｸ
ｼﾔﾌﾄ
ﾎﾙﾀﾞ
R
HINGE (F), Z AXIS
1
39 EZ4-455-328-02
Z
ｼﾞｸ ﾌﾟﾚ-ﾄ
F
PLATE (F), Z AXIS
1
40 EZ4-455-329-01
ｹ-ﾌﾞﾙ ﾌﾞﾗｹﾂﾄ
BRACKET, CABLE
1
41 EZ4-455-331-01
ｸﾗﾝﾌﾟ
ﾌﾞﾗｹﾂﾄ
BRACKET, CLAMP
1
42 EZ4-455-336-02
ﾒｲﾝ ｻﾎﾟ-ﾄ
SUPPORT, MAIN
2
43 EZ4-455-337-01
ｶﾞｲﾄﾞ ﾍﾞ-ｽ
BASE, GUIDE
2
44 EZ4-455-338-01
ﾛﾂｸ
ﾌﾞﾗｹﾂﾄ
BRACKET, LOCK
2
45 EZ4-455-339-01
ｼﾔﾌﾄ
SHAFT
2
46 EZ4-455-340-01
ｺﾃｲ
ﾌﾞﾗｹﾂﾄ
F
BRACKET (F), FIXED
1
47 EZ4-455-341-01
ｺﾃｲ
ﾌﾞﾗｹﾂﾄ
R
BRACKET (R), FIXED
1
48 EZ4-455-355-02
ｾﾝｻ
ﾌﾞﾗｹﾂﾄ
BRACKET, SENSOR
1
49 EZ4-457-147-01
ﾋﾝｼﾞ
ﾋﾟﾝ
(CDGH10-50)
PIN (CDGH10-50), HINGE
2
51 EZ4-457-157-01
ｶｸﾍｷ
ﾕﾆｵﾝ
(KQ2E08-00A)
UNION (KQ2E08-00A), BULKHEAD
1
52 EZ4-457-163-01
ﾘﾆｱ
ｳｴｲ
(ML12C1R50T1H)
RAIL (ML12C1R50T1H), LINEAR
2
53 EZ4-457-164-01
ｼﾖﾂｸ ｱﾌﾞｿ-ﾊﾞ
(MAKC1005B)
ABSORBER (MAKC1005B), SHOCK
2
54 EZ4-457-165-01
ｽﾗｲﾄﾞ
ﾕﾆﾂﾄ
(MEG15C1T1PS1)
SLIDE UNIT (MEG15C1T1PS1)
2
55 EZ4-457-167-01
ｴｱ
ｼﾘﾝﾀﾞ
(MGPL12-20Z)
CYLINDER (MGPL12-20Z), AIR
2
56 EZ4-457-169-01
ﾌﾞﾂｼﾕ
(MPTZ8-25)
BUSHING (MPTZ8-25)
2
57 EZ4-460-740-01
ｼﾘﾝﾀﾞ
(CDQSWBS20-10-DCP419AP)
CYLINDER(CDQSWBS20-10-
DCP419*)
2
58 EZ4-700-042-41
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X15)
BOLT (M4X15), HEXAGON SOCKET
14
59 EZ4-701-529-01
ﾀｲﾏｳﾝﾄ
(MB1)
TIE MOUNT (MB1)
5
60 EZ4-706-151-11
ﾊｲｾﾝﾄﾞﾒ
(KR5G5)
CLAMP (KR5G5)
1
A-78
A21
クリーニングユニット
(
オプション
)
Cleaning unit (option)
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
61 EZ4-457-146-01
ｽﾋﾟ
-
ﾄﾞ
ｺﾝﾄﾛ
-
ﾗ
-(AS1201F-M5-04A)
CONTROLLER (AS1201F-M5-04A)
4
62 EZ4-447-053-01
ﾊ
-
ﾌ
ﾕﾆｵﾝ
(KQ2H04-M5N)
UNION (KQ2H04-M5N), HALF
14
63 EZ4-718-766-04
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾄﾒﾈｼﾞ
(M3X8 SUS)
SET-SCREW (M3X8 SUS), HEAD
1
64 EZ4-718-767-03
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾄﾒﾈｼﾞ
(M4X10 SUS)
SET-SCREW (M4X10 SUS), HEAD
2
65 EZ7-682-160-09
+P 4X6
SCREW +P 4X6
1
66 EZ7-682-247-09
+K 3X6
SCREW +K 3X6
5
67 EZ7-682-947-01
+PSW 3X6
SCREW +PSW 3X6
8
68 EZ7-683-402-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X5
BOLT,HEXAGON SOCKET 3X5
8
69 EZ7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
4
70 EZ7-683-405-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X10
BOLT,HEXAGON SOCKET 3X10
11
71 EZ7-683-411-04
6
ｶｸ
ｱﾅ
ﾂｷ
ﾎﾞﾙﾄ
3X25
BOLT,HEXAGON SOCKET 3X25
4
72 EZ7-683-418-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X6
BOLT,HEXAGON SOCKET 4X6
14
73 EZ7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
2
74 EZ7-683-420-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X10
BOLT,HEXAGON SOCKET 4X10
21
75 EZ7-683-425-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X20
BOLT,HEXAGON SOCKET 4X20
2
76 EZ7-683-435-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X10
BOLT,HEXAGON SOCKET 5X10
4
77 EZ7-683-444-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X30
BOLT,HEXAGON SOCKET 5X30
2
78 EZ7-683-450-04
6
ｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
5X45
BOLT, HEXAGON SOCKET 5X45
4
79 EZ7-688-004-11
W 4, MIDDLE
W 4, MIDDLE
10
EZ7-630-003-51
ﾌﾂｿ ｼﾞﾕｼ ﾁﾕ-ﾌﾞ
TUBE, FLUORPOLYMER
1720
