A12 バックア ップユニ ット Backup table unit ｲﾗｽﾄ番 号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 1 EZA- 1899 - 202 -A SC MOUNT SC MOUNT 1 2 EZ1- 492 - 041 - 22 ｾﾝｻ - ASSY (S 2 ORG) SENSOR AS…
A12
バックアップユニット
Backup table unit
10
54
55
65
13
53
17
17
19
19
16
16
18
14
47
45
18
14
47
45
21
45
11
45
48
46
12
12
20
52
70
71
22
5
53
54
10
55
65
13
8
8
74
74
74
74
71
71
71
71
63
71
67
67
8
8
8
8
8
7
7
39
40
15
23
33
34
44
44
44
44
28
42
43
41
28
27
51
29
6
26
25
32
35
50
36
50
37
50
24
31
30
1
9
38
49
74
74
57
57
73
73
73
73
72
72
72
72
56
69
69
71
71
71
71
71
71
71
71
57
57
57
73
73
57
71
71
75
3
2
4
75
69
69
75
75
69
69
73
73
73
73
73
63
66
64
64
64
62
76
68
60
60
61
61
61
58
59
A-45
A12
バックアップユニット
Backup table unit
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZA-1899-202-A
SC MOUNT
SC MOUNT
1
2 EZ1-492-041-22
ｾﾝｻ-
ASSY (S2ORG)
SENSOR ASSY (S2ORG)
1
3 EZ1-492-043-32
ｾﾝｻ-
ASSY (S2CW)
SENSOR ASSY (S2CW)
1
4 EZ1-492-043-42
ｾﾝｻ-
ASSY (S2CCW)
SENSOR ASSY (S2CCW)
1
5 EZ1-492-304-11
ｱﾂﾘﾖｸ ｽｲﾂﾁ
(ZSE30A-C6H-C)
SWITCH, PRESSURE(ZSE30A-C6H-
C)
1
6 EZ1-855-132-11
ｻ-ﾎﾞ ﾓ-ﾀ
(SGMAV-04ADA2C)
MOTOR, SERVO (SGMAV-04ADA2C)
1
7 EZ2-023-130-21
ｼﾞｸﾖｳ
C
ｶﾞﾀ ﾄﾒﾜ
(STWN4)
RING,SHAFT CTYPE RETAINING(S*)
2
8 EZ2-698-399-02
ｺﾞｸ ﾃｲﾄｳ ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(CBST*
CAP SCREW, EXTRA LOW HEAD
26
9 EZ2-990-379-01
ｼﾁﾕｳ
SUPPORT
4
10 EZ4-442-230-31
ﾏｸﾞﾈﾂﾄ
(NHXCC10-4)
MAGNET (NHXCC10-4)
12
11 EZ4-447-063-41
ｴﾙﾎﾞ
ﾕﾆｵﾝ
(KQ2L08-01AS)
UNION (KQ2L08-01AS), ELBOW
1
12 EZ4-447-063-71
ｴﾙﾎﾞ ﾕﾆｵﾝ
(KQ2L12-02AS)
UNION (KQ2L12-02AS), ELBOW
2
13 EZ4-456-958-01
ｴﾙﾎﾞ ﾕﾆｵﾝ
(KQ2L06-03AS)
UNION (KQ2L06-03AS), ELBOW
2
14 EZ4-447-248-61
ﾊ-ﾌ ﾕﾆｵﾝ
(KQ2H12-02AS)
UNION (KQ2H12-02AS), HALF
2
15 EZ4-455-000-04
ﾊﾞﾂｸ ｱﾂﾌﾟ ﾍﾞ-ｽ
BASE, BACK UP
1
16 EZ4-455-001-01
ｶﾑ ｶﾞｲﾄﾞ
GUIDE, CAM
2
17 EZ4-455-002-02
ﾍﾞ-ｽ ｶﾞｲﾄﾞ
1
GUIDE (1), BASE
2
18 EZ4-455-003-01
ﾏﾆﾎ-ﾙﾄﾞ
MANIFOLD
2
19 EZ4-455-004-02
ﾍﾞ-ｽ ｶﾞｲﾄﾞ
2
GUIDE (2), BASE
2
20 EZ4-455-005-01
ﾌﾟﾚ-ﾄ
PLATE
1
21 EZ4-455-006-01
ﾏﾆﾎ-ﾙﾄﾞ
E
MANIFOLD (E)
1
22 EZ4-455-007-01
ｾﾝｻ ﾌﾟﾚ-ﾄ
PLATE, SENSOR
1
23 EZ4-455-009-02
ﾒｲﾝ ﾌﾟﾚ-ﾄ
1
PLATE (1), MAIN
1
24 EZ4-455-010-02
ﾌﾟﾚ-ﾄ
PLATE
1
25 EZ4-455-011-02
ｽﾗｲﾄﾞ ﾌﾟﾚ-ﾄ
1
PLATE (1), SLIDE
1
26 EZ4-455-012-02
ｽﾗｲﾄﾞ ﾌﾟﾚ-ﾄ
2
PLATE (2), SLIDE
1
27 EZ4-455-013-02
ﾎﾞ-ﾙ ｽｸﾘﾕ- ﾌﾞﾗｹﾂﾄ
1
BRACKET (1), BALL SCREW
1
28 EZ4-455-014-02
ﾎﾞ-ﾙ ｽｸﾘﾕ- ﾌﾞﾗｹﾂﾄ
2
BRACKET (2), BALL SCREW
2
29 EZ4-455-015-01
ﾓ-ﾀ ﾌﾞﾗｹﾂﾄ
BRACKET, MOTOR
1
A-46
A12
バックアップユニット
Backup table unit
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
30 EZ4-455-016-02
ｾﾝｻ ﾌﾞﾗｹﾂﾄ
BRACKET, SENSOR
1
31 EZ4-455-017-02
ｾﾝｻ ﾌﾞﾗｹﾂﾄ
BRACKET, SENSOR
1
32 EZ4-455-018-02
ｽﾗｲﾄﾞ ﾍﾞ-ｽ
BASE, SLIDE
1
33 EZ4-455-019-02
ｶﾞｲﾄﾞ ﾍﾞ-ｽ
1
BASE (1), GUIDE
1
34 EZ4-455-020-02
ｶﾞｲﾄﾞ ﾍﾞ-ｽ
2
BASE (2), GUIDE
1
35 EZ4-455-021-01
ｽﾄﾂﾊﾟ
1
STOPPER (1)
1
36 EZ4-455-022-01
ｽﾄﾂﾊﾟ
2
STOPPER (2)
1
37 EZ4-455-023-01
ｽﾄﾂﾊﾟ
3
STOPPER (3)
1
38 EZ4-455-024-01
ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ
BRACKET, CABLE BARE
1
39 EZ4-455-267-02
ﾋﾟﾝ
1
PIN (1)
1
40 EZ4-455-268-02
ﾋﾟﾝ
2
PIN (2)
1
41 EZ4-456-910-21
ｻﾎﾟ-ﾄ ﾕﾆﾂﾄ
(BUM-10S)
SUPPORT UNIT (BUM-10S)
1
42 EZ4-456-910-31
ｻﾎﾟ-ﾄ ﾕﾆﾂﾄ
(BUM-12F)
SUPPORT UNIT (BUM-12F)
1
43 EZ4-456-917-01
ﾎﾞ-ﾙﾈｼﾞ
(GW1505DS-HULR-0200X0*)
SCREW(GW1505DS-HULR-
0200X013*)
1
44 EZ4-456-938-01
ﾘﾆｱ ｳｴｲ
(MXD20C2R360E138)
LINEAR WAY (MXD20C2R360E138)
4
45 EZ4-456-942-01
O
ﾘﾝｸﾞ
(NSA31.5)
O RING (NSA31.5)
4
46 EZ4-456-944-01
ﾒｽ ｵｽ ｴﾙﾎﾞ
(SGPELH20A)
ELBOW (SGPELH20A), FEMALE
MALE
1
47 EZ4-456-946-01
ｷﾔﾂﾁ ﾈﾂﾄ
(SNGCN1S-200)
NET (SNGCN1S-200), CATCHER
2
48 EZ2-672-029-01
3
ﾀﾞﾝ
ｲｼﾞｴｸﾀ
(TJ-20-SL)
EJECTOR (TJ-20-SL), 3 STEP
1
49 EZ4-456-949-02
ｹ-ﾌﾞﾙ ﾍﾞｱ
(TKP0250W20R50)
BARE (TKP0250W20R50)
1
50 EZ4-456-951-01
ｽﾄﾂﾊﾟ
(UST10-20)
STOPPER (UST10-20)
3
51 EZ4-456-955-01
ｶﾂﾌﾟﾘﾝｸﾞ
(XGT-39C-10X14)
COUPLING (XGT-39C-10X14)
1
52 EZ4-456-958-01
ｴﾙﾎﾞ ﾕﾆｵﾝ
(KQ2L06-03AS)
UNION (KQ2L06-03AS), ELBOW
1
53 EZ4-459-050-01
ﾏﾆﾎ-ﾙﾄﾞ
1
MANIFOLD (1)
2
54 EZ4-459-083-01
O
ﾘﾝｸﾞ
(NGA25)
O RING (NGA25)
2
55 EZ4-459-286-01
ﾏﾆﾎ-ﾙﾄﾞ
3
MANIFOLD (3)
2
56 EZ4-700-042-41
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M4X15)
BOLT (M4X15), HEXAGON SOCKET
4
57 EZ4-700-045-71
ﾛﾂｶｸ ｱﾅﾂｷ ﾎﾞﾙﾄ
(M6X15)BOLT
(M6X15), HEXAGON SOCKET
30
58 EZ4-706-151-11
ﾊｲｾﾝﾄﾞﾒ
(KR5G5)
CLAMP (KR5G5)
1
A-47
