A19 外装カバー Outer cover ｲﾗｽﾄ番 号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 33 EZ4- 459 - 634 - 01 ｻﾎﾟ - ﾄ ｶﾊﾞ - COVER, SUPPORT 1 34 EZ4- 469 - 185 - 01 ﾗﾂﾁ ﾌﾞﾗｹﾂﾄ BRACKET , LA TCH 2…
A19
外装カバー
Outer cover
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZ1-798-469-11
ｾﾚｸﾀ
ｽｲﾂﾁ
(CW4K-2BE21)
SWITCH, SELECTOR (CW4K-2BE21)
1
2 EZ1-846-553-11
EMG
ｹ-ﾌﾞﾙ
(ZY1C-SS3961-EMG)
CABLE, EMG
1
3 EZ1-846-554-11
SW
ｹ-ﾌﾞﾙ
(ZY1C-SS3961-P-ON)
CABLE, SW
1
4 EZ1-846-555-11
SW
ｹ-ﾌﾞﾙ
(ZY1C-SS3961-P-OFF)
CABLE, SW
1
5 EZ4-184-378-02
ﾊﾟﾂｷﾝ
(FC-779-1-2)
GASKET (FC-779-1-2)
1/50
6 EZ4-454-711-04
ﾌﾛﾝﾄ ｶﾊﾞ
-
L
COVER (L), FRONT
1
7 EZ4-454-712-03
ﾌﾛﾝﾄ ｶﾊﾞ-
R
COVER (R), FRONT
1
8 EZ4-454-955-01
ﾍﾞｱﾘﾝｸﾞ
ﾌﾞﾗｹﾂﾄ
L
BRACKET (L), BEARING
1
9 EZ4-454-955-11
ﾍﾞｱﾘﾝｸﾞ
ﾌﾞﾗｹﾂﾄ
R
BRACKET (R), BEARING
1
10 EZ4-454-965-03
ｶﾊﾞ-
F
COVER (F)
1
11 EZ4-454-970-01
ｶﾊﾞ-
B1
COVER (B1)
1
12 EZ4-454-971-03
ｶﾊﾞ-
B2
COVER (B2)
1
13 EZ4-454-973-02
ﾄﾞｱ ｷ- ﾌﾞﾗｹﾂﾄ
BRACKET, DOOR KEY
1
16 EZ4-454-984-02
ｶﾊﾞ-
T
COVER (T)
1
17 EZ4-454-985-01
ｶﾊﾞ-
B3
COVER (B3)
1
18 EZ4-454-986-03
ｻｲﾄﾞ ｳｴ ｶﾊﾞ-
R
COVER (R), SIDE UPPER
1
19 EZ4-454-986-13
ｻｲﾄﾞ ｳｴ ｶﾊﾞ-
L
COVER (L), SIDE UPPER
1
20 EZ4-454-988-03
ｻｲﾄﾞ ｶﾊﾞ-
R
COVER (R), SIDE
1
21 EZ4-454-988-13
ｻｲﾄﾞ ｶﾊﾞ-
L
COVER (L), SIDE
1
22 EZ4-454-990-03
ｻｲﾄﾞ ｼﾀ ｶﾊﾞ-
R
COVER (R), SIDE LOWER
1
23 EZ4-454-990-12
ｻｲﾄﾞ ｼﾀ ｶﾊﾞ-
L
COVER (L), SIDE LOWER
1
24 EZ4-454-992-03
ﾄﾞｱ
ｱﾝｸﾞﾙ
ANGLE, DOOR
1
25 EZ4-454-993-01
ﾄﾞｱ
DOOR
1
26 EZ4-454-994-01
ﾄﾞｱ
ﾊﾝﾄﾞﾙ
HANDLE, DOOR
1
27 EZ4-454-995-01
ﾄﾞｱ ﾌﾟﾚ-ﾄ
PLATE, DOOR
1
28 EZ4-456-943-01
ｵﾈｼﾞ
ﾂｷ
ﾍﾞｱﾘﾝｸﾞ
(NTSBG19-8)
BEARING (NTSBG19-8)
4
29 EZ4-460-197-01
ﾄﾞｱ ｽｲﾂﾁ ｷ-
(HS9Z-A65)
KEY (HS9Z-A65), DOOR SWITCH
1
30 EZ7-682-561-04
+B 4X8
SCREW +B 4X8
32
31 EZ7-682-561-09
+B 4X8
SCREW +B 4X8
40
32 EZ4-453-872-01
ﾄﾞｱ ｽｲﾂﾁ ｷ-
(HS9Z-A66)
KEY (HS9Z-A66), DOOR SWITCH
1
A-65
A19
外装カバー
Outer cover
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
33 EZ4-459-634-01
ｻﾎﾟ-ﾄ ｶﾊﾞ-
COVER, SUPPORT
1
34 EZ4-469-185-01
ﾗﾂﾁ
ﾌﾞﾗｹﾂﾄ
BRACKET, LATCH
2
35 EZ4-469-186-01
ﾗﾂﾁ
ｳｹ
RETAINER, LATCH
1
36 EZ4-469-187-01
ｷ- ﾌﾞﾗｹﾂﾄ
BRACKET, KEY
1
37 EZ4-469-189-01
ｲﾀ
ﾅﾂﾄ
NUT PLATE
3
38 EZ4-469-190-01
ﾍｲﾒﾝ
ﾗﾂﾁ
(CP-876)
LATCH, FLUSH (CP-876)
1
39 EZ4-469-191-01
ｽﾌﾟﾘﾝｸﾞ
ﾂｷ
ﾁﾖｳﾊﾞﾝ
(B-1146-2)
HINGE, SPRING (B-1146-2)
3
40 EZ7-682-561-04
+B 4X8
SCREW +B 4X8
15
41 EZ7-682-561-09
+B 4X8
SCREW +B 4X8
2
42 EZ7-682-960-01
+PSW 4X6
SCREW +PSW 4X6
4
43 EZ7-683-418-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X6
BOLT,HEXAGON SOCKET 4X6
4
44 EZ4-722-669-21
ｷﾖｳﾘﾖｸ ﾗﾊﾞ- ﾏｸﾞﾈﾂﾄ
(C-200-1)
MAGNET, RUBBER (C-200-1)
2
EZ7-682-261-04
+K 4X8
SCREW +K 4X8
4
EZ7-683-417-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X5
BOLT,HEXAGON SOCKET 4X5
1
EZ7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
12
EZ4-454-981-01
ﾋｼﾞﾖｳ ﾃｲｼ ｼ-ﾙ
SEAL, EXTREME STOP
1
EZ4-455-925-01
ｹｲｺｸ
ﾗﾍﾞﾙ
(
ｶﾐﾅﾘ
) (S)
LABEL (ZIGZAG) (S), WARNING
2
EZ4-455-926-01
ｹｲｺｸ
ﾗﾍﾞﾙ
(
ｶﾐﾅﾘ
) (M)
LABEL (ZIGZAG) (M), WARNING
5
EZ4-455-927-01
ｹｲｺｸ
ﾗﾍﾞﾙ
(PE)
LABEL (PE), WARNING
1
EZ4-455-928-01
ｹｲｺｸ
ﾗﾍﾞﾙ
(
ﾁﾕｳｲ
) (M)
LABEL (CAUTION) (M), WARNING
1
EZ4-455-992-01
ｹｲｺｸ
ﾗﾍﾞﾙ
(
ﾚ-ｻﾞ-
2) (M)
LABEL (LASER 2) (M), WARNING
1
EZ4-455-994-01
ｹｲｺｸ
ﾗﾍﾞﾙ
(
ｹｶﾞ
ﾌｸｺﾞｳ
)
LABEL (HURT), WARNING
2
EZ4-455-995-01
ｹｲｺｸ
ﾗﾍﾞﾙ
(
ﾂﾘｻｹﾞ
ｷﾝｼ
)
LABEL (SUSPENSION
PROHIBITION)
2
EZ4-462-761-01
ｱ-ｽ ﾗﾍﾞﾙ
LABEL, EARTH
5
A-66
