Source Drivers
Figure 6-18 Typical Source Driver Schematic
MultiMove Input and Ouputs
*Tied low, input is from
tristate logic device
which may float during
power ON/reset.
U219 U217 U223 U221
PBD3548/1
PBD3548/1
Source 2 Source 0 Source 6 Source 4
U220 U218 U224 U222
Load
Vcc 24V
Source 0
ON/OFF
eg. Clamps
V Power
*
Device Type 3548/1 Only Shown.
IN
2
1
3
ERR
GND
V+
OUT
Source 0
Gnd Isol
4
5
V Isol
4K7
4K7
Source 3 Source 1Source 7 Source 5
MultiMove Card
Signal Inputs MultiMove X13 Function Destination Device
IN0 Switch - Jog Right 14PL08 8SW2
IN1 Switch - Jog Left 14PL08 8SW1
IN2
IN3 Power On Monitor PCB C - CPL1 PSU
IN4 Switch - Cover Interlock PCB C - CSK6 9SW1
0$&+,1(&21752//(5
08/7,029(
6.24 Technical Reference Manual Chapter Issue 4 May 03
IN5 Switch - Cleaner Home PCB C - CSK5 8SE10
IN6 Sensor - Paper Low 8PL71
IN7 Sensor - Solvent Low 8PL73
IN8
IN9 Config Jumper - Bit 0 MultiMove
Backplane
INA MIU Lane B Read Status M19SK02 N/C
INB MIU Downline Ready M19SK02 N/C
INC MIU Upline Ready M19SK02 N/C
IND MIU Lane A Read Status M19SK01 FMI Lane A
INE MIU Downline Ready M19SK01 FMI Lane A
INF MIU Upline Ready M19SK01 FMI Lane A
Source O/P MultiMove X13 Function Destination Device
0 Screen Clamps Solenoid Bank 16SOL07
1 Cleaner Squeegee Solenoid Bank 16SOL08
2 Cleaner Vac Valve Solenoid Bank 16SOL09
3 Solenoid - Board Clamp Solenoid Bank 16SOL10
4 Solenoid - Board Clamp Solenoid Bank 16SOL14
5 N/C Solenoid Bank
6 N/C Solenoid Bank
7 N/C Solenoid Bank
Totem O/P’s MultiMove X13 Function Destination Device
0 Spare Output
1 Lamp - Beacon, Green 14PL07 Beacon
2 Lamp - Beacon, Amber 14PL07 Beacon
3 Lamp - Beacon, Red 14PL07 Beacon
4 Buzzer 14PL07 Beacon
5 ProFlow Pressure Regulator Control DSK11/14SK07
6 Solenoid - Cleaner Home Clamp Rt/Lft
(Linked at PCB D DSK12)
PCB D DSK12 8SOL19/20
7 Solenoid - Chase Clamp Rt/Lft (Linked at
PCB D DSK13/14)
P1 & P2/P3 & P4 13SOL01/02
Signal Inputs MultiMove X12 Function Destination Device
IN0 Switch - Air Pressure PCB D SK9 8SE11
IN1 Sensor - Screen Present SK01 13SE07
IN2 Switch - Lid Bolt Extended PCB D SK7 9SW8
IN3 Sensor - Paste Cartridge Empty PCB E EPL6 9SE15
IN4 Switch - Paste Cartridge Horizontal 9PL45 9SE13
Signal Inputs MultiMove X13 Function Destination Device
0$&+,1(&21752//(5
08/7,029(
Chapter Issue 4 May 03 Technical Reference Manual 6.25
IN5 Switch - Paste Cartridge Vertical 9PL44 9SE14
IN6 Switch - ProFlow Cassette Low M18PL01 M18SE01
IN7 Link - ProFlow Cassette Fitted M18PL01
IN8 Config. Jumper - Bit 1 M19SK04
IN9 Config. Jumper - Bit 2 M19SK04
INA ProFlow Regulator Fitted M19SK04
INB SPARE M19SK04
INC SPARE M19SK04
IND Vacuum Tooling Sensor M19SK04
INE SPARE M19SK04
INF SPARE M19SK04
Source
Outputs
MultiMove X12 Function Destination Device
0 Solenoid - Table Brake 8PL09 8SOL02
1 Solenoid - External/Vacuum Filtration PCB B BSK8
2 Solenoid - Vacuum Tooling (Option) BPL9 8SOL24
3 Solenoid - ProFlow Paste Present 16SK02 16SOL03
4 SPARE Solenoid Bank 16SOL03
5 Lid Bolt Solenoid Bank 16SOL04
6 Solenoid - Paste Dispenser Solenoid Bank 16SOL05
7 Solenoid - Solvent Tank Pressure Solenoid Bank 16SOL06
Totem Ouputs MultiMove X12 Function Destination Device
0 Belt Motor #01+ (Front Rail) 8SK21 8M03
1 Belt Motor #01- (Front Rail) 8SK21 8M03
2 Belt Motor #04+ (Rear Rail) 8SK23 8M04
3 Belt Motor #04- (Rear Rail) 8SK23 8M03
4 Cartridge Tilt Motor+ 9PL48 9M9
5 Cartridge Tilt Motor- 9PL48 9M9
6 Solenoid - Solvent Valve 8PL76 8SOL25
7 Paper Feed Motor 8PL72 8M5
Signal Inputs MultiMove X12 Function Destination Device
