0$&+,1( &21752//( 5 '8$/67( 33(5'5,9( 6.36 Technical Reference Manual Chapter Issue 4 May 03 S tepper Drive Designations Sig nal Func tion Des tina tio n Sour ce Motor 2A- Front Squeegee S tepper Mot…
0$&+,1(&21752//(5
'8$/67(33(5'5,9(
Chapter Issue 4 May 03 Technical Reference Manual 6.35
Stepper Drive Card
Figure 6-25 Dual Stepper Drive PCB
Fuse F1 -
0.5AT
Fuse F2-
3.15AT
+5V
Regulator
TP4 - Step 2
TP5-0V
TP2 - Step 1
TP3 - Dir 2
TP1 - Dir 1
JP11
JP3
JP4
JP9
JP10
JP5
JP1
JP2
JP7
JP8
JP6
JP14
JP12
JP13
Jumper Links
Slot X3
Slot X4
Slot X5
Slot X6
X
X
X
X
X
X
X
X
X
X
X
X
JP1
JP2
JP3
JP4
JP5
JP6
JP7
JP8
JP9
JP10
JP11
JP12
JP13
JP14
Dual Stepper Card Configuration Table
NOTE
denotes jumper link fitted.
X
CAUTION
ANTI STATIC HANDLING. Standard precautions must be adhered to when handling
electronic cards and configuring and inserting cards into enclosures.
0$&+,1(&21752//(5
'8$/67(33(5'5,9(
6.36 Technical Reference Manual Chapter Issue 4 May 03
Stepper Drive Designations
Signal Function Destination Source
Motor 2A- Front Squeegee Stepper Motor 9M3 Stepper Drive X5
Motor 2A+ Front Squeegee Stepper Motor
Motor 2B- Front Squeegee Stepper Motor
Motor 2B+ Front Squeegee Stepper Motor
Front Sq. Home Switch - Home PCB E - ESK4 MUX PL1
Motor 1A+ Rear Squeegee Stepper Motor 9M4 Stepper Drive X4
Motor 1A- Rear Squeegee Stepper Motor
Motor 1B+ Rear Squeegee Stepper Motor
Motor 1B- Rear Squeegee Stepper Motor
Rear Sq. Home Switch - Home PCB E - ESK4 MUX PL1
Motor 1B- Y Actuator Stepper Motor Stepper Drive X5
Motor 1B+ Y Actuator Stepper Motor
Motor 1A- Y Actuator Stepper Motor
Motor 1A+ Y Actuator Stepper Motor
Y Actuator Home Switch - Home Coarse 9PL35 M19SK09
Y Actuator Home Switch - Home Fine
Motor 2A- Moving Rail Stepper Motor 8M2 Stepper Drive X4
Motor 2A+ Moving Rail Stepper Motor
Motor 2B+ Moving Rail Stepper Motor
Motor 2B- Moving Rail Stepper Motor
Mov. Rail Home Switch - Moving Rail Home 8SE6 MUX PL1
Motor 2B- X Rear Actuator Stepper Motor Stepper Drive X3
Motor 2B+ X Rear Actuator Stepper Motor
Motor 2A- X Rear Actuator Stepper Motor
Motor 2A+ X Rear Actuator Stepper Motor
X Rear Act. Home Switch - Home Coarse 9PL34 M19SK09
X Rear Act. Home Switch - Home Fine 9PL34 M19SK09
Motor 1B+ X Forward Actuator Stepper
Motor
Stepper Drive X3
Motor 1B- X Forward Actuator Stepper
Motor
Motor 1A- X Forward Actuator Stepper
Motor
Motor 1A+ X Forward Actuator Stepper
Motor
X Fwd. Act. Home Switch - Home Coarse 9PL33 M19SK09
X Fwd. Act. Home Switch - Home Fine 9PL35 M19SK09
Motor 1B+ Paste Dispenser Motor Stepper Drive X6
Motor 1B- Paste Dispenser Motor
Motor 1A- Paste Dispenser Motor
0$&+,1(&21752//(5
'8$/67(33(5'5,9(
Chapter Issue 4 May 03 Technical Reference Manual 6.37
Motor 1A+ Paste Dispenser Motor
Paste Disp Home Switch - Paste Disp Home M19SK27
Signal Function Destination Source
