2 Operating safety User Manual - Productivity Lift 2.1 Safety instructions Edition 02/2004 8 – The Productivity Lif t may only be put into or r emain in operation when all of the warning stickers on the Productivity Lift…
User Manual - Productivity Lift 2 Operating safety
Edition 02/2004 2.1 Safety instructions
7
2.1.4 Prescribed use
DANGER
Any use of the product in non-accordance with the regulations is prohibited (see section 2.1.5
“Non-prescribed use”).
The prescribed use of the device is defined as follows:
– The Productivity Lift consists of at least 2 lift units and 2 undefloor conveyors (in this manual
also referred to as SPLC- see 1.1.3 “Terminology for Productivity Lift”) and serves to increase
the throughput of SIPLACE automatic placement machines. Every lift unit has a placement ma-
chine of this type. Several lift units are arranged in series along with the corresponding SPLC,
this enables the parallel arrangement of placement machines although these are physically ar-
ranged in a row.
– The Productivity Lift may only be used for the purposes described in the catalogue and the
technical descriptions i.e. for the transport of bare PCBs and mounted PCBs according to the
PCB and component specifications. Any other use, or use beyond the scope of the description,
is defined as being in non-accordance with the regulations.
– The Productivity Lift may only be used in connection with external devices and components
approved by SIEMENS AG L&A. The Productivity LIft may also only be used with authorised
original spare parts. Any other use, or use beyond the scope of the description is defined as
being in non-accordance with the regulations.
– The Productivity Lift may only be operated under the conditions defined in this user manual for
installation, connection and operation.
– The Productivity Lift may only be connected to the operating voltage, when it properly inte-
grated into the SIPLACE-line as described in this user manual and in the installation manual.
The Productivity Lift may not be used outside of the SIPLACE-line.
– If no additional modules / machines are connected to the lift unit (to the input or output mod-
ules), so that the upper and / or lower transfer opening(s) is (are) freely accessible, then the
designated plate covers and the Eslon covers must be fitted (see installation instructions).
– If a conveyor or another line module is installed in front of the input module or after the output
module, so that the lift’s output opening(s) (transfer opening) are freely accessible, then the
hand protection plate supplied in the accessory package must be fitted (see installation instruc-
tions).
2 Operating safety User Manual - Productivity Lift
2.1 Safety instructions Edition 02/2004
8
– The Productivity Lift may only be put into or remain in operation when all of the warning stickers
on the Productivity Lift (consisting of lift unit and SPLC) are legible and present at the correct
position.
– Proper and safe operation of the product requires the appropriate transportation, the correct
assembly, installation and set up as well as careful operation, maintenance and service by ad-
equately qualified personnel, who are authorised for the work in question through training at
SIEMENS AG L&A.
– „Prescribed use“ of the product also requires observation of all instructions in the Productivity
Lift installation instructions and the Productivity Lift user manual. Precedence is given to the
observation of all instructions in the user manual from the corresponding SIPLACE placement
machine, since the optional line add-on, the Productivity Lift, has a signal connection as well
as a mechanical connection to the placement machines and it is therefore necessary to be fa-
miliar with and observe the interaction of the modules.
– Furthermore, it is necessary to observe the sections concerning interfaces and signal se-
quences in the user manuals of possible connecting modules (e.g. the conveyors).
– The contents of the above named Productivity Lift installation and user manual, as well as the
SIPLACE placement machine user manual and the user manuals of additional connected
modules / machines, must be fully understood and complied to. This ensures that the require-
ments for installation and the switching on of the Productivity Lift and therefore also for the
„prescribed use“ can be taken for granted.
By non-compliance with the „prescribed use“, SIEMENS AG L&A will assume no liability in the
event of any possible damages or injuries and will also not guarantee the flawless and proper
functioning of the components in the Productivity Lift or of the components of those machines ad-
jacent to the lift in the line.
User Manual - Productivity Lift 2 Operating safety
Edition 02/2004 2.1 Safety instructions
9
2.1.5 Non-prescribed use
DANGER
By non-prescribed use of the product there is the danger of severe bodily injury, death or consid-
erable material damage. For this reason, non-prescribed use of the product is prohibited.
By non-compliance with the „prescribed use“, SIEMENS AG L&A will assume no liability in the
event of any possible damages or injuries and will also not guarantee the flawless and proper
functioning of the components.
The following are examples of non-prescribed use of the Productivity Lift and the SIPLACE
placement machine or other adjacent line modules:
– the use of the lift for purposes other than those defined in „prescribed use“. Therefore also the
transporting of PCBs with or without components which are not within the specifications.
– the transportation, installation and connection (electric and pneumatic), as well as the interface
connection to the SIPLACE placement machines and other systems, under circumstances
other than those defined in the installation instructions for installation, connection and opera-
tion.
– electrical connection of the Productivity Lift, when the Productivity Lift or a part thereof (SPLC
or lift unit) is / are presently outside of the SIPLACE line.
– The operation of the Productivity Lift without the hand protection, when a conveyor without a
cover, or without an adequate cover, is connected in such a way that it is possible to intervene
with the transfer openings of the lift.
– the operation of the lift unit when the upper and lower transfer openings are accessible and
without properly fastened covers because for example there are no following or preceding con-
necting modules.
– the operation of the SPLC without the cover.
– the use of unauthorised spare-parts, unauthorised accessories and additional modules.
– the operation and execution of any tasks on the Productivity Lift and the SIPLACE placement
machine by inadequately trained or unqualified personnel.
– the performing of service and maintenance work by personnel not qualified for these tasks or
tasks which are not covered within the scope of the corresponding documentation. These in-
clude tasks in the inner area of the lift without the additional compulsory mechanical securing
device for the Z-lift axle.
– starting of code protected functions of the Productivity Lift by personnel not authorised for
these tasks.
