User Manual - Productivity Lift 2 Operating safety Edition 02/2004 2.2 W a rning signals and warnin g and danger symbols on the Productivity Lift 33 Fig. 2 - 26 SPLC without cover , outlet left Fig. 2 - 27 SPLC without c…
2 Operating safety User Manual - Productivity Lift
2.2 Warning signals and warning and danger symbols on the Productivity Lift Edition 02/2004
32
Fig. 2 - 24 Labelling of the Emergency-stop button on the service side of the lift
2.2.4 Warning symbols on the SPLC
2.2.4.1 Warning sticker W 203
Article-No.: 03009342-01
Sticker positions: on the SPLC, visible after removal of the fastened transport cover:
– 2 labels per transport track, each time on the inside of the transport
assembly.
Amount: 4 per SPLC
Category: WARNING
Fig. 2 - 25 Warning sticker W203, Art-No. 03009342-01
DANGER OF CRUSHING!
Intervention can lead to injuries on the arms and the hands.
Operate the SPLC only in the designated operating state and
not without its cover. (see also 2.2.3.3 Warning sticker W
203).
User Manual - Productivity Lift 2 Operating safety
Edition 02/2004 2.2 Warning signals and warning and danger symbols on the Productivity Lift
33
Fig. 2 - 26 SPLC without cover, outlet left
Fig. 2 - 27 SPLC without cover, outlet right
See Fig. 2 - 8 warning
symbol on the lower trans-
fer opening of the lift.
See Fig. 2 - 8 warning
sticker on the on the lower
transfer opening of the lift
2 Operating safety User Manual - Productivity Lift
2.2 Warning signals and warning and danger symbols on the Productivity Lift Edition 02/2004
34
Fig. 2 - 28 SPLC without cover, inlet right
Fig. 2 - 29 SPLC without cover, inlet right
See Fig. 2 - 7 warning
sticker on the on the lower
transfer opening of the lift.
See Fig. 2 - 7 warning
sticker on the on the lower
transfer opening of the lift.
