2 Operating safety User Manual - Productivity Lift
2.4 ESD regulations Edition 02/2004
38
2.4 ESD regulations
Comply to the instructions for the ESD regulations as are provided in the placement machine’s
user manual.
2.5 Fitting the transport locks
WARNING
The transport locks displayed as follows are a necessary safety mechanism for the machine.
When the lift is delivered, the vertical position of the "top conveyor" and the shuttle conveyor are
secured with the corresponding transport lock (see Fig. 2 - 32 und Fig. 2 - 33). The locks may only
be removed after the lift has been installed and directly before the unit is switched on for the first
time.
If a Productivity Lift which is to be relocated is presently installed in the line or to the SIPLACE
placement machine, then the transport locks must be fitted before the machine is moved as will
now be shown. Follow the instructions as described in the installation instructions for dismantling
and relocation of the lift. Before the Productivity Lift is switched back on, the transport locks must
be removed and fitted into the designated storage location in the interior of the lift. All tools must
also be removed from the lift area before the machine is first switched on.
Further information about the transport locks is available in the current installation instructions for
the Productivity Lift (Art.-Nr.00191967-02 / Edition 05/2004).
User Manual - Productivity Lift 2 Operating safety
Edition 02/2004 2.5 Fitting the transport locks
39
2.5.1 Fitting the transport locks for "top conveyor"
Fig. 2 - 32 Press transport lock U-rail onto the piston rod of „top conveyor“
2.5.2 Fitting the transport locks to the shuttle conveyor
Fig. 2 - 33 Fit the transport lock (clamping piece) from above against the shuttle conveyor
Locking of the „Top con-
veyor“ via transport lock
„U-rail“
BEFORE all intervention into the interior of the lift
and BEFORE relocation / transportation of the lift:
„top conveyor“ must be in the lowest posi-
tion.
Check the U-rail is securely fitted!
Locking of the Shuttle
Transport via transport
lock „clamping piece“.
BEFORE relocation/ transportation of
the lift unit:
Shuttle-conveyor must be DOWN:
Check the clamping piece is securely fit-
ted!
2 Operating safety User Manual - Productivity Lift
2.6 Signal lamps Edition 02/2004
40
Fig. 2 - 34 Fit the transport lock (clamping piece) from below against the shuttle conveyor
2.6 Signal lamps
The machine is equipped with a green and a white signal lamp. The following functions are allo-
cated to the lamps:
Green - lit : Unit is running in automatic mode.
White - lit : Unit has an error
Locking of the Shuttle Trans-
port via mounting transport
lock „clamping piece“.
BEFORE all intervention into the lift inte-
rior, when the shuttle conveyor is up
Shuttle-conveyor in UPPER position:
Check the clamping piece is securely fit-
ted!
