User Manual - Productivity Lift Soko 00166631-01 / 12031477 9 Technical Data
Software version V 43.140 Edition April 2006 9.2 Electrical and pneumatic connection
89
Machine type: Input module, Cluster module, Cross module
Length - LiftL1 540 mm
WidthB 1045 mm
High H 1200 mm with TH1 930 mm
ShuttleH1 760 mm
Weight - Lift 212 kg
Width adjustment - Shuttle transport stepper motor
Tab. 9.2 - 1 Technical Data - Input module, Cluster module, Cross module
Machine type: Output module
Length - LiftL1 540 mm
WidthB 1045 mm
High H 1200 mm with TH1 930 mm
ShuttleH1 760 mm
Weight - Lift 212 kg
Width adjustment - Shuttle transport stepper motor
Tab. 9.2 - 2 Technical Data - Output module
Underfloor conveyor for SIPLACE - short for S20 - S27 and F4 to F5 HM
Length lower beltL2 1590 mm
Total module lengthL3 2135 mm
Total unit lengthL4 2675 mm
Weight 90 kg
Width adjustment stepper motor
Tab. 9.2 - 3 Technical Data - Underfloor conveyor for SIPLACE - short
9 Technical Data User Manual - Productivity Lift Soko 00166631-01 / 12031477
9.2 Electrical and pneumatic connection Software version V 43.140 Edition April 2006
90
Underfloor conveyor for SIPLACE - long for HS50, HS60 and FH Series
Length lower beltL2 2385 mm
Total module lengthL3 2925 mm
Total unit lengthL4 3465 mm
Weight 120 kg
Width adjustment stepper motor
Tab. 9.2 - 4 Technical Data - Underfloor conveyor for SIPLACE - long
All machine types
Transport high - aboveTH1 930 mm ± 30 mm
Transport high - belowTH2 170 mm ± 30 mm
PCB width single transport 50 - 217 mm
PCB width double transport 50 - 460 mm
PCB length 50 - 460 mm
PCB edging during transport 3mm
Interface inlet Siemens, SMEMA
Interface outlet Siemens, SMEMA
Automatic tracking none, at inlet or at outlet
Power supply 230V / 50Hz or 110V / 60Hz AC
Power input 0,4 kW
Secondary voltage 24V DC
Fuse protection 1x 6,3A
Compressed air supply 5 bar and 10 l/min.
Control unit CAN/MM101 and CAN/MS1
Operation via control desk CAN/P50
Tab. 9.2 - 5 Technical Data - All machine types
User Manual - Productivity Lift 10 Interface description
Edition 02/2004
91
10 Interface description
The machines are equipped with interfaces according to the Siemens and the SMEMA definitions.
NOTE
Detailed information about the interfaces are available in the Productivity Lift installation instruc-
tions / Article-No. 00191967-02 / Edition 05/2004).
