Powerflow_zh | Re v. 4a Ersa Gm bH 500 / 561 9 | 9.3 9.3.1 视 [Y ] [Z] A B 1 Bow-type handle in sulated, GN - 564 - 25 - 160 6GR-GN564 x 2 Tube, Ø 64 mm, very flex ibl e 6SKL -NW6 4 x

100%1 / 561
Powerflow_zh | Rev. 4a
Ersa GmbH
499 / 561
9 |
187: EM155-00-00-00b
A
B
1
Cover cap, black, Ø = 12,7 mm
6ABKA12H3658
x
183: EM155-00-00-00c
A
B
1
Monitor holder
6MONIHALTER
x
1 1 1 1 1
Powerflow_zh | Rev. 4a
Ersa GmbH
500 / 561
9 |
9.3
9.3.1
视 [Y] [Z]
A
B
1
Bow-type handle insulated, GN-564-25-160
6GR-GN564
x
2
Tube, Ø 64 mm, very flexible
6SKL-NW64
x
Powerflow_zh | Rev. 4a
Ersa GmbH
501 / 561
9 |
A
B
3
Catch bolt, with counternut
6RBGN617-6-AK
x
4
Flange bushing BP 25 10 x 15 x 10
6BUFL10X15X10
x
