Powerflow_zh | Rev. 4a
Ersa GmbH
521 / 561
9 |
9.5.2
201: EM100-42-02-00a
[Z]
202: EM100-42-02-00b
A
B
1
Grease nipple, H2/M 6x1 451 113/1
6SCHMNI6X1
x
2
Bearing for spindles B7007C.T.P4S.UL
94633
x
3
Slide bar, S-black, length 750 mm
101124
x
4
Z 轴升降丝杆，PF Spindle
87677A
x
4
Spindle set, complete with spindle and nut
284773
x
4
Spindle nut, complete
284786
x
Powerflow_zh | Rev. 4a
Ersa GmbH
522 / 561
9 |
[X]
203: EM100-42-02-00c
A
B
1
Chain 12.7 x 4.88 1202, bulk stock
6KE1202
x
2
Chain joint
6KES1202
x
3
Slide bar, S-black, length 480 mm
101146
x
4
Chain wheel
177020
x
5
Motor, Dunker, BG65x75CI/PLG52 250:1
225293
x
Powerflow_zh | Rev. 4a
Ersa GmbH
523 / 561
9 |
[Y]
204: EM100-42-02-00d
A
B
1
Reversing Pulley With Bearing
6IN249-0
x
2
Sensor
70598
x
