Installation Manual, Station Software Version 605.03 SP3 12/2012 Edition
11 of 46
4 Requirements
4.1 SIPLACE X-Series, D-Series and CA-Series Software Components
4.1.1 Station
The station uses the following operating system configuration
• Station computer: Microsoft Windows XP Professional
(including Service Pack 2 and most recent hotfixes)
• Machine controller: Microsoft Windows embedded XP (SP2)
4.1.2 Machine Components
The following versions of other machine components are required for the station software to function
correctly:
Station computer
SIPLACE Vision
Machine controller
SIPLACE Pro
Version 605.03 SP3 Version 414 Version 605.03 SP3 Version 8.0
Version 9.3
*)
*) SIPLACE Pro Version 9.3 is required if the type 30 component camera is used.
CAUTION
The functional statuses of the station computer, vision, machine controller and SIPLACE Pro
software must be compatible.
Installation Manual, Station Software Version 605.03 SP3 12/2012 Edition
12 of 46
4.1.3 Embedded Software
You will find the used eSW versions listed in the eSW_Firmware_Files.txt file in the Documentation
directory on the installation CD.
The hardware status of a subsystem is identified by the 3rd digit in the file name.
The example below shows the file name of the BIOS for the main axes of the X-Series:
File name Hardware status
A0
300200.bhx A 363
A0
400309.bhx A 364
Installation Manual, Station Software Version 605.03 SP3 12/2012 Edition
13 of 46
4.2 SIPLACE X-Series and SIPLACE D3 Hardware Components
NOTICE
The hardware configuration of the station computer and the optional Vision computer can
only be combined with a particular hardware configuration for the machine controller. See
the following table for details.
Station computer
Machine controller Vision computer
(wit 3D coplanarity sensor
option)
SMP16-CPU086
SMP16-CPU076
SMP16-CPU086
SMP16-CPU086
SIMATIC Box PC 627
SIMATIC Box PC 627 SIMATIC Box PC 627
Table 4-1: Possible combinations of station computer and Vision computer with the machine controller
4.2.1 Station Computer
Name
SMP16-CPU086
CPU / clock frequency
P M / 1.6 GHz
RAM
768 MB
Hard disk
40 GB
External DVD drive
No
Serial interfaces
2
USB interfaces and external USB hub
Yes
Network
1 x 10/100Base-T
2 x 10Base-T
6-port hub
Table 4-2: Station computer hardware (previous configuration of SIPLACE X-series and SIPLACE D3)
Name
SIMATIC Box PC 627
CPU / clock frequency
Pentium M / 2 GHz
RAM
1 GB
Hard disk
40 GB
External DVD drive
Yes
Serial interfaces
1
USB interfaces
and external USB hub
Yes
Network
2x 100 MBit
Table 4-3: Station computer hardware (current configuration of SIPLACE X-series and SIPLACE D3)
