INFINITY
MACHINE PROGRAMMING
STAGE 6B - VACUUM TOOLING
User Manual 1.39
The following window and menu bar is displayed:
29. Select Continue (F1). The message ‘Table at Contact Height. Check
Tooling Clearance’ is displayed.
30. Select Raise Head (F7).
31. Raise the printhead using two button control.
32. Fit the head prop.
33. Press Confirm (F1).
34. Check that the setup of the tooling is adequate for the board, adjust as
necessary.
NOTE
If adjustment is required, this can be carried out at Transport Height.
35. Select Lower Head (F2).
36. Remove the head prop.
37. Select Confirm (F1).
38. Lower the printhead using two button control.
39. Close the front printhead cover.
40. Press the System button.
Contact Height Warning
WARNING Check for obstructions between
the Rails and the Screen
Continue
Open
Cover
Exit
Continue
Open
Cover
Exit
Vision
Height
Raise
Head
Exit
Confirm
Lower
Head
Lower
Head
Confirm Cancel
INFINITY
MACHINE PROGRAMMING
STAGE 6B - VACUUM TOOLING
1.40 User Manual
41. Select Exit (F8).
The following window and menu bar is displayed:
42. Select Continue (F1).
43. Select Auto Board (F1).
44. Remove the board from the rails.
45. Select Continue (F1).
46. Go to Stage 7.
Vision
Height
Raise
Head
Exit
Leaving Generic Tooling
WARNING You are about to return
to the Setup Page
Clear all tooling setup
equipment before proceeding
Continue Cancel
Continue Cancel
Auto
Board
Manual
Board
Continue Head
INFINITY
MACHINE PROGRAMMING
STAGE 6C - DEDICATED TOOLING
User Manual 1.41
STAGE 6C - DEDICATED TOOLING
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
CAUTION
BOARD CLAMPS.
Care must be taken to ensure that the board clamps are
not damaged when removing or replacing tooling.
NOTE
Ensure that Generic Tooling is set to Enabled in Set Prefs.
1. Select Change Tooling (F6). The print carriage moves to the front of the
printer.
The Change Tooling Parameters window is displayed:
NOTE
If the remote board stop is fitted the Board Stop X and Board Stop Y
parameters are replaced by Remote Board Stop X.
2. Setting up the board stop position is automatically done using the board
dimensions previously set in the product file. If they need adjustment to re-
position the board stop for any reason, ie any routing on the board edge or
a badly positioned image on the stencil, this can be done now. If adjustment
is necessary continue with Step 3. If adjustment is not necessary go to Step
8.
3. Select Adjust (F1).
4. Use the Next and Previous keys (F4 - F5) to highlight each parameter.
5. Use the Incr. and Decr. keys (F6 - F7), or the forward slash key (/) on the
keyboard, to change the parameter value.
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Change Tooling Parameters
BOARD WIDTH
BOARD STOP X
BOARD STOP Y
UNDER CLEARANCE
216.0
125.0
142.6
19.0
mm
mm
mm
mm
Adjust
Raise
Head
Remove
Cleaner
Board
Stop
Full
Width
Load
Width
Generic
Toolin g
Exit
Save Next Previous Incr. Decr. Exit
Save Next Previous Incr. Decr. Exit
