INFINITY
MACHINE PROGRAMMING
STAGE 6D - MULTIFLEX TOOLING
1.52 User Manual
20. Remove the head prop.
21. Select Confirm (F1).
22. Lower the printhead using two button control.
23. Close the front printhead cover.
24. Press the System button.
25. Select Board Width (F5). The message ‘Checking for a board on the
belts’ is displayed. Whilst the rear rail is moving the following message ‘Rail
Moving...’ is displayed.
26. Select Generic Tooling (F7).
The following window and menu bar is displayed:
NOTE
If contaminated squeegees are fitted, these should be replaced at this point.
27. Select Continue (F1). The print carriage travels to the rear of the machine
Confirm Cancel
Adjust
Raise
Head
Remove
Cleaner
Board
Stop
Board
Width
Load
Width
Generic
Toolin g
Exit
Adjust
Raise
Head
Remove
Cleaner
Board
Stop
Full
Width
Load
Width
Generic
Tooling
Exit
Generic Tooling Warning
WARNING Paste may drip into the machine
Remove Squeegees NOW
Continue
Open
Cover
Exit
INFINITY
MACHINE PROGRAMMING
STAGE 6D - MULTIFLEX TOOLING
User Manual 1.53
and the following message is displayed ‘Table at Home Height’.
28. Select Transprt Height (F3). The message ‘Table at Transport Height’ is
displayed.
29. Place a board on the input sensor of the upline conveyor of the machine.
30. Select Load (F1).
31. Select Auto Board (F1).
32. Select Vision Height (F3). The message ‘Table at Vision Height. Check
Tooling Clearance’ is displayed.
33. Select Contact Height (F3).
The following window and menu bar is displayed:
34. Select Continue (F1). The message ‘Table at Contact Height. Check
Tooling Clearance’ is displayed.
Continue
Open
Cover
Exit
Load
Transprt
Height
Board
Clamps
Change
Screen
Raise
Head
Exit
Load
Vision
Height
Home
Height
Board
Clamps
Change
Screen
Raise
Head
Exit
Auto
Board
Manual
Board
Unload
Vision
Height
Home
Height
Board
Clamps
Change
Screen
Raise
Head
Exit
Contact
Height
Trans pr t
Height
Change
Screen
Raise
Head
Exit
Contact Height Warning
WARNING Check for obstructions between
the Rails and the Screen
Continue
Open
Cover
Exit
Continue
Open
Cover
Exit
INFINITY
MACHINE PROGRAMMING
STAGE 6D - MULTIFLEX TOOLING
1.54 User Manual
35. Select Raise Head (F7).
36. Raise the printhead using two button control.
37. Fit the head prop.
38. Press Confirm (F1).
39. Check that the setup of the tooling is adequate for the board, adjust as
necessary.
NOTE
If adjustment is required, this can be carried out at Transport Height.
40. Select Lower Head (F2).
41. Remove the head prop.
42. Select Confirm (F1).
43. Lower the printhead using two button control.
44. Close the front printhead cover.
45. Press the System button.
46. Select Exit (F8).
The following window and menu bar is displayed:
Vision
Height
Raise
Head
Exit
Confirm
Lower
Head
Lower
Head
Confirm Cancel
Vision
Height
Raise
Head
Exit
Leaving Generic Tooling
WARNING You are about to return
to the Setup Page
Clear all tooling setup
equipment before proceeding
Continue Cancel
