INFINITY
MACHINE PROGRAMMING
STAGE 6C - DEDICATED TOOLING
1.44 User Manual
15. If required, slide additional magnetic pins beneath the plate assembly to fully
support it when printing wide boards.
16. Select Lower Head (F2).
The following window and menu bar is displayed:
17. Remove the head prop.
18. Select Confirm (F1).
19. Lower the printhead using two button control.
Adjust
Lower
Head
Board
Clamps
Set
Stop
Hazardous Operation
The head is about to be lowered
Remove the Head Prop and confirm that
everyone is standing clear.
Confirm Cancel
Confirm Cancel
INFINITY
MACHINE PROGRAMMING
STAGE 6C - DEDICATED TOOLING
User Manual 1.45
20. Close the front printhead cover.
21. Press the System button.
22. Select Board Width (F5). The message ‘Checking for a board on the
belts’ is displayed. Whilst the rear rail is moving the following message ‘Rail
Moving...’ is displayed.
23. Select Generic Tooling (F7).
The following window and menu bar is displayed:
NOTE
If contaminated squeegees are fitted, these should be replaced at this point.
24. Select Continue (F1). The print carriage travels to the rear of the machine
and the following message is displayed ‘Table at Home Height’.
25. Select Transprt Height (F3). The message ‘Table at Transport Height’ is
displayed.
26. Place a board on the input sensor of the upline conveyor of the machine.
27. Select Load (F1).
28. Select Auto Board (F1).
Adjust
Raise
Head
Remove
Cleaner
Board
Stop
Board
Width
Load
Width
Generic
Toolin g
Exit
Adjust
Raise
Head
Remove
Cleaner
Board
Stop
Full
Width
Load
Width
Generic
Tooling
Exit
Generic Tooling Warning
WARNING Paste may drip into the machine
Remove Squeegees NOW
Continue
Open
Cover
Exit
Continue
Open
Cover
Exit
Load
Transprt
Height
Board
Clamps
Change
Screen
Raise
Head
Exit
Load
Vision
Height
Home
Height
Board
Clamps
Change
Screen
Raise
Head
Exit
Auto
Board
Manual
Board
INFINITY
MACHINE PROGRAMMING
STAGE 6C - DEDICATED TOOLING
1.46 User Manual
29. Select Vision Height (F3). The message ‘Table at Vision Height. Check
Tooling Clearance’ is displayed.
30. Select Contact Height (F3).
The following window and menu bar is displayed:
31. Select Continue (F1). The message ‘Table at Contact Height. Check
Tooling Clearance’ is displayed.
32. Select Raise Head (F7).
33. Raise the printhead using two button control.
34. Fit the head prop.
35. Press Confirm (F1).
36. Check that the setup of the tooling is adequate for the board, adjust as
necessary.
NOTE
If adjustment is required, this can be carried out at Transport Height.
37. Select Lower Head (F2).
38. Remove the head prop.
Unload
Vision
Height
Home
Height
Board
Clamps
Change
Screen
Raise
Head
Exit
Contact
Height
Trans pr t
Height
Change
Screen
Raise
Head
Exit
Contact Height Warning
WARNING Check for obstructions between
the Rails and the Screen
Continue
Open
Cover
Exit
Continue
Open
Cover
Exit
Vision
Height
Raise
Head
Exit
Confirm
Lower
Head
Lower
Head
