INFINITY
MACHINE PROGRAMMING
STAGE 6E - FORMFLEX TOOLING
User Manual 1.71
41. Wait until the pneumatic indicator on the front cover displays green.
42. Select Exit (F8).
The following window and menu bar is displayed:
43. Select Continue (F1).
44. Select Auto Board (F1).
45. Remove the board from the downline conveyor.
46. Select Continue (F1).
47. Select Change Screen (F5).
48. Raise the front printhead cover and remove the screen.
Vision
Height
Raise
Head
Exit
Leaving Generic Tooling
WARNING You are about to return
to the Setup Page
Clear all tooling setup
equipment before proceeding
Continue Cancel
Continue Cancel
Auto
Board
Manual
Board
Continue Head
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Toolin g
Change
Language
Exit
INFINITY
MACHINE PROGRAMMING
STAGE 6E - FORMFLEX TOOLING
1.72 User Manual
49. Remove the universal set plate from the screen.
50. Ensuring correct orientation, refit the screen.
51. Lower the front printhead cover.
52. Press the System button.
53. Go to Stage 7.
INFINITY
MACHINE PROGRAMMING
STAGE 6F - AUTOFLEX TOOLING
User Manual 1.73
STAGE 6F - AUTOFLEX TOOLING
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
CAUTION
BOARD CLAMPS.
Care must be taken to ensure that the board clamps are
not damaged when removing or replacing tooling.
NOTE
Ensure that Generic Tooling is set to Enabled in Set Prefs.
1. Select Change Tooling (F6). The print carriage moves to the front of the
printer.
The Change Tooling Parameters window is displayed:
NOTE
If the remote board stop is fitted the Board Stop X and Board Stop Y
parameters are replaced by Remote Board Stop X.
2. Select Adjust (F1).
3. Setting up the board stop position is automatically done using the board
dimensions previously set in the product file. If they need adjustment to re-
position the board stop for any reason, ie any routing on the board edge or
a badly positioned image on the stencil, this can be done now. If adjustment
is necessary continue with Step 4. If adjustment is not necessary go to Step
7.
4. Use the Next and Previous keys (F4 - F5) to highlight each parameter.
5. Use the Incr. and Decr. keys (F6 - F7), or the forward slash key (/) on the
keyboard, to change the parameter value.
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Change Tooling Parameters
BOARD WIDTH
BOARD STOP X
BOARD STOP Y
UNDER CLEARANCE
216.0
125.0
142.6
19.0
mm
mm
mm
mm
Adjust
Raise
Head
Remove
Cleaner
Board
Stop
Full
Width
Load
Width
Generic
Toolin g
Exit
Change
Autoflex
Save Next Previous Incr. Decr. Exit
Change
Autoflex
Save Next Previous Incr. Decr. Exit
