INFINITY
MACHINE PROGRAMMING
STAGE 6E - FORMFLEX TOOLING
1.72 User Manual
49. Remove the universal set plate from the screen.
50. Ensuring correct orientation, refit the screen.
51. Lower the front printhead cover.
52. Press the System button.
53. Go to Stage 7.
INFINITY
MACHINE PROGRAMMING
STAGE 6F - AUTOFLEX TOOLING
User Manual 1.73
STAGE 6F - AUTOFLEX TOOLING
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
CAUTION
BOARD CLAMPS.
Care must be taken to ensure that the board clamps are
not damaged when removing or replacing tooling.
NOTE
Ensure that Generic Tooling is set to Enabled in Set Prefs.
1. Select Change Tooling (F6). The print carriage moves to the front of the
printer.
The Change Tooling Parameters window is displayed:
NOTE
If the remote board stop is fitted the Board Stop X and Board Stop Y
parameters are replaced by Remote Board Stop X.
2. Select Adjust (F1).
3. Setting up the board stop position is automatically done using the board
dimensions previously set in the product file. If they need adjustment to re-
position the board stop for any reason, ie any routing on the board edge or
a badly positioned image on the stencil, this can be done now. If adjustment
is necessary continue with Step 4. If adjustment is not necessary go to Step
7.
4. Use the Next and Previous keys (F4 - F5) to highlight each parameter.
5. Use the Incr. and Decr. keys (F6 - F7), or the forward slash key (/) on the
keyboard, to change the parameter value.
Mode
Load
Data
Edit
Data
Setup
Squeegee
Change
Screen
Change
Tooling
Change
Language
Exit
Change Tooling Parameters
BOARD WIDTH
BOARD STOP X
BOARD STOP Y
UNDER CLEARANCE
216.0
125.0
142.6
19.0
mm
mm
mm
mm
Adjust
Raise
Head
Remove
Cleaner
Board
Stop
Full
Width
Load
Width
Generic
Toolin g
Exit
Change
Autoflex
Save Next Previous Incr. Decr. Exit
Change
Autoflex
Save Next Previous Incr. Decr. Exit
INFINITY
MACHINE PROGRAMMING
STAGE 6F - AUTOFLEX TOOLING
1.74 User Manual
6. Select Save (F2). The message ‘Saving fiducial data - Please wait Board
data file saved’ is displayed.
7. Select Change Autoflex (F1).
The Autoflex Matrix window is displayed:
The Autoflex pin matrix has already been setup for this product from the
board dimensions.
8. Use the Left, Right, Up and Down keys (F4 - F7), to select the pin positions
required for editing.
9. Use the Lower and Raise keys (F1 - F2), to select or deselect the pins.
10. Select Exit (F8).
Change
Autoflex
Save Next Previous Incr. Decr. Exit
Change
Autoflex
Save Next Previous Incr. Decr. Exit
Autoflex Matrix
14
13
12
11
10
9
8
7
6
5
4
3
2
1
AB CD EF GH I J K L MN
---------------
---------------
---------------
---------------
---------------
---------------
---------------
---------------
---------------
---------------
---------------
---------------
---------------
---------------
O
Lower Raise Reset Left Right Up Down
Exit
Lower Raise Reset Left Right Up Down
Exit
Lower Raise Reset Left Right Up Down
Exit
