1.2 "CHECK" Windows
Check Code
Display Section A Display Section B
050301 Recognition Data Please check recognition nozzle data and carry out data trans again.
Missing
050302 Recognition Data Please check comp recog lighting data and carry out data trans
Missing again.
050303 Recognition Data Please check recog camera mag data and carry out data trans
Missing again.
050304 Recognition Data Please check recog camera offset data and carry out data trans
Missing again.
050305 Recognition Data Please check recog camera gain level data and carry out data trans
Missing again.
050306 Recognition Data Please check recog nozzle gain level data and carry out data trans
Missing again.
050307 Recognition Data Please check comp recog data and carry out data trans again.
Missing
050308 Recognition Data Please check recog execution mode data and carry out data trans
Missing again.
070101 Front Safety Door Close the safety door and zero all device with the [ZERO] button.
070201 Rotary Wheel Pull on the rotary wheel handle.
070301 Front Area Sensor Remove foreign substance.
070401 Unavailable Data Input available feeder No. in current program.
070402 Unavailable Data Input available placement step in current program.
090101 Disengaged PCB Set P.C.B. on the X/Y table.
090201 Chute Lower Limit Move the X/Y chute down.
090301 Feeder Carriage Separate both feeder carriages and zero all devices with the [ZERO]
Collision button.
090401 Cam Phase Check the cam positioner.
090402 Cam Phase Re-adjust or repair the cam shaft if necessary.
090501 Out Of Limit Zero all device with the [ZERO] button.
090601 Linear Measure Press the [POWER OFF] button once and press the [POWER
Alarm ON] button.
090701 Out Of Feeder Axis Zero all device in manual mode or with the [ZERO] button.
Stationary Position
090702 Out Of Feeder Axis Check the feeder.
Stationary Position
090703 Out Of Feeder Axis Check feeder motor 1 & 2.
Stationary Position
090704 Out Of Feeder Axis Please check area around feeder carriage located at its home
Stationary Position position #1.
090705 Out Of Feeder Axis Please check area around feeder carriage located at its home
Stationary Position position #2.
090801 Rotary Turret Origin Adjust rotary turret angle to 0° or 360°.
0307-004 2-7 AGS01ETRP
Check Code Display Section A Display Section B
090901 Furnace Signal Check the furnace signal.
090a01 Oil Cooler Alarm Check the cooling oil.
090b01 Cooling FAN Alarm Check the cooling FAN.
091001 Recognition Ready Wait until recognition unit is ready to work.
0b0111 Feeder Carriage Not Press the [F1 READY] button to set feeder carriage #1 in ready
Ready Switch mode.
0b0116 Feeder Carriage Not Press the [F2 READY] button to set feeder carriage #2 in ready
Ready Switch mode.
0b0211 Operation Area Feeder Close saf. guard at crg. home pos. 1.
Axis Safety Guard
0b0216 Operation Area Feeder Close saf. guard at crg. home pos. 2.
Axis Safety Guard
0b0301 Operation Area Feeder Open saf. guard at crg. home pos.
Axis Safety Guard
0d0101 Out Of Origin Zero X/Y chute width.
0d0102 Out Of Origin Zero L conveyor width.
0d0103 Out Of Origin Zero R conveyor width.
0d0104 Out Of Origin Zero conveyor width.
0d0105 Out Of Origin Zero all devices with the [ZERO] button.
0d0106 Out Of Origin Zero PCB support pins up/down.
0d0107 Out Of Origin Zero PCB locate lever.
0d0108 Out Of Origin Zero X/Y table axis.
0d0109 Out Of Origin Zero camera X/Y axis.
0d0201 Feeder Axis Servo Restore Load Power again, or Check F1saf.guard if open/close
Down
0d0202 Feeder Axis Servo Restore Load Power again, or Check F2saf.guard if open/close
Down
1.2 "CHECK" Windows
0307-005 2-8 AGS01ETRP
1.3 Machine Information
1.3.1 "Machine Information" Window
••
••
• Window Layout
Various machine information is displayed while the machine is running.
While the "Machine Information" window is active, the machine
keeps on running.
Fig. 4B2-1 Example of "Machine Information"
••
••
• Window Composition
*1 Machine Information
The machine information is displayed.
Refer to "1.3.2 List of Check Messages" for details.
*5
*4
*1
*2
*3
1.3 Machine lnformation
0111-003 2-9 AGS01ETRP
