D-25
E0012 : Splash cover opened.
Error code
E0012
Message
Splash cover opened.
What was
detected
There was an input on the safety switch of the splash cover.
During what
operation it
occurred
During spindle rotation or while the X-, Y-, Z-, θ- and elevator-axis, and the
upper and lower arm is operation. The cover does not open during the
spindle rotation.
State after
detection
The Z-axis retreats to the upper end and the spindle stops.
The axis of the X-, Y-, θ-, upper arm, lower arm and elevator comes to an
immediate stop.
Phenomenon Probable causes Remedy Reference
What to do
The error also
occurs while the
cover is closed.
Thesafetyswitchis
defective.
Replace the safety
switch.
Contact your
nearest DISCO
Service Office.
The sensor line is
broken.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Close the splash cover.
(2) Cancel the alarm.
(3) Press the <START> button to resume the operation or press the <EXIT>
button to discontinue the operation.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-26
E0014 : Temperature in the electrical box has increased.
Error code
E0014
Message
Temperature in the electrical box has increased.
What was
detected
Temperature increase in the electrical box was detected.
During what
operation it
occurred
At any time.
State after
detection
The Z-axis retreats to the upper end. The other axes come to a stop.
The cutting operation is temporarily halted.
Phenomenon Probable causes Remedy Reference
What to do
The fan in the
electrical box is
stopped.
The fuse (F1, F2) is
blown.
Contact your
nearest DISCO
Service Office.
Failure of the fan. Contact your
nearest DISCO
Service Office.
The error occurs
although the fuse
(F1, F2) is normal.
The thermal sensor
lineisbroken.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm.
(2) Turn OFF the machine power.
(3) Turn OFF the circuit breaker.
(4) Check whether the fuse (F1, F2) in the electrical box is not blown.
(5) Wait more than one minute after turning OFF the power, and then turn
ON the circuit breaker.
(6) Turn ON the machine power.
(7) Make sure that the fan of the electrical box rotates properly.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
D-27
E0015 : Water case overflow error.
Error code
E0015
Message
Water case overflow error.
What was
detected
There was an input to the overflow sensor because the water level in the
water case exceeds the prescribed water level.
During what
operation it
occurred
While the wheel coolant water is ON and during spinner cleaning.
State after
detection
The Z-axis retreats to the upper end. The spindle stops rotating. The X-, Y-
and θ-axes immediately stop. Cleaning operation stops, if the error occurs
during spinner cleaning.
Phenomenon Probable causes Remedy Reference
What to do
Thedrainageinthe
water case is poor.
The wastes strainer
of the drain is
clogged.
Clean the drain
wastes strainer.
The error occurs
regardless of the
water level in the
water case.
The overflow sensor
is defective.
Replace the sensor.
The overflow sensor
line is defective.
Contact your
nearest DISCO
Service Office.
Recovery
(1) Cancel the alarm.
(2) Clean the wastes strainer in the water case.
(3) Turn ON the wheel coolant water only and check whether the water
drains properly.
(4) Press the <START> button to resume the operation or press the <EXIT>
button to discontinue the operation.
Maintenance level Maintenance personnel level Hazard level
Measuring equipment used Tools Replacement parts Protective gear
