E-33 Operation flow The procedure for cleani ng the spindle consists of the following steps. 1-3-1 Removing the blade and flange/hub mount 1-3-2 Removing the wheel cov er 1-3-3 Cleaning the spindle main bod y 1-3-4 Compl…
E-32
Component name
Spindle front lid
Air outlet
Taper section
Seal ring
Interval of spindle cleaning
The proper interval of spindle cleaning differs depending on the frequency in
use of the machine, or the type of the blade or workpiece used.
If you change the frequency of the machine usage or the type of the blade or
workpiece, check how much the main sections are soiled at least once a day,
and then decide the interval of cleaning.
Criteria of judgment
Outlet of air curtain
Can you see the clearance for outlet of air curtain clearly?
- Make sure that the clearance which works as the outlet of air curtain and is
located at the root of the taper section is not blocked with contamination.
Spindle front lid
Air outlet
Seal ring
Other
Is there no discoloration in the taper section and its surroundings?
- Check whether there is discoloration due to rust or water stain.
E-33
Operation flow
The procedure for cleaning the spindle consists of the following steps.
1-3-1 Removing the blade and flange/hub mount
1-3-2 Removing the wheel cover
1-3-3 Cleaning the spindle main body
1-3-4 Completion of spindle cleaning
E-34
1-3-1. Removing the blade and flange/hub mount
Procedures for removing the blade and flange/hub mount
Step No.
Do This
1
Press the <System Initial> button to effect system initialization.
2
Remove the blade.
For the procedures for removing the blade;
See the section B-6, [Blade Maintenance] of the Operation
Manual.
3
Remove the flange or hub mount.
For the procedures for removing the blade;
See the section B-2 of this manual, [Flange/Hub Mount
Replacement].
Continued in the next section.
