6 Uninstalling Installation Guide SIPLACE Setup Center 6.3 Uninstalling the Database Edition 03/2005 EN 50 → Cli ck Next if you ac cept all th e infor mation e ntered so far . → Cli ck Done . 6.2.2 S te p 2 Clean u p the…
Installation Guide SIPLACE Setup Center 6 Uninstalling
Edition 03/2005 EN 6.1 Backup Configuration Files
49
6 Uninstalling
6.1 Backup Configuration Files
Copy all .xml files from the "\Program Files\Siemens SIPLACE\Setup Center" directory to a save
location.
6
It is recommended that the unsupported tool Configuration backup and recovery is used to
back up the SIPLACE Setup Center configuration before uninstalling the software.
6
6.2 Uninstalling the Software
Uninstalling SIPLACE Setup Center deletes all SIPLACE Setup Center software components
from the system except for the SIPLACE Setup Center database.
6
The SIPLACE Setup Center database is not automatically uninstalled in order to prevent possible
data loss.
6
6.2.1 Step 1
Uninstall SIPLACE Setup Center via the Control Panel. 6
You require the uninstall window in Windows for uninstalling. 6
→Click Start in the Windows start menu.
→Click Settings.
→Click Control Panel.
→Double-click Add / Remove Programs.
A list appears with the names of the software packages installed on the computer.
6
→Select SIPLACE Setup Center.
→Click the Change/Remove components button.
→In the Confirm File Deletion dialog box, click Yes ifyouwishtoproceedorNo if you wish to
cancel the uninstall process.
→Select Remove to remove all installed features.
→Click Next to continue.
→In the Confirm File Deletion dialog box,click OK if you wish to proceed or Cancel if you wish
to cancel the uninstall process.
→Click Next and you get a summary of all components to be deleted.
6 Uninstalling Installation Guide SIPLACE Setup Center
6.3 Uninstalling the Database Edition 03/2005 EN
50
→Click Next if you accept all the information entered so far.
→Click Done.
6.2.2 Step 2
Clean up the disk and make sure that there are no more program files. 6
→Check the path Program Files\Siemens SIPLACE\SIPLACE Setup Center.
→If you will find additional files, please delete them (except for thedatabase files withextensions
.mdf and .ldf).
6.3 Uninstalling the Database
ThedatabasecanbeuninstalledwiththeMicrosoftSQL Server 2000 Enterprise Manager. 6
→Expand the node Microsoft SQL Servers
→Expand the node SQL Server group
→Expand the node of the database server instance on which the SIPLACE Setup Center data-
base was installed to.
→Expand the node Microsoft SQL Servers
→Expand the node Databases
→Right click the node SIPLACESetupCenter and select Delete.
→Confirm the deletion of the database.
6
→Go back to the node of the database server instance.
→Expand the node "Management"
→Expand the node "SQL Server Agent"
→Expand the node "Jobs"
→Mark all entries starting with "SIPLACESetupCenter" and delete them.
→Confirm the deletion of the maintenance jobs.
→Go back to the node of the database server instance.
→Expand the node Security
→Expand the node Logins
→Mark all entries starting with SIPLACESetupCenter and delete them.
→Confirm the deletion of the logins.
The database is completely deleted now.
6
The ServerManager is an unsupported tool that is able to create, empty and delete the SIPLACE
Setup Center database. The password for the user 'sa' is required.
6
Installation Guide SIPLACE Setup Center 6 Uninstalling
Edition 03/2005 EN 6.3 Uninstalling the Database
51
It is recommended to use the ServerManager for the deletion of the database as it executes the
steps mentioned above automatically.
6
Warning
All data will be lost when erasing or dropping the database with the ServerManager. Use with cau-
tion. 6
6.3.1 On MSDE Installations
→Uninstall the MSDE instance used for Setup Center.
→Remove the database files manually.
6
