SIPLACE HF Seri es Detailed Circuit Diagra ms Folder 09/2 005 US Ed ition 0 - 7 0.2 S tructure of the T echnical Numberi ng System Document number A docu ment nu mber con sists of an item nu mber , p roduct statu s, docu…
SIPLACE HF Series Detailed Circuit Diagrams Folder
09/2005 US Edition
0 - 6
0.1.25 Elektromechanische Antriebe / Operating devices
0.1.26 Sicherungen und Sicherungsschalter / Fuses and fuse-switches
0.1.27 Leuchtmelder und Signaleinrichtungen / Lamps and signalling devices
0.1.28 Verstärker / Amplifiers
Nr. / No. Schaltzeichen / Symbol Beschreibung Description
07-15-01
Elektromechanischer Antrieb, allgemein
Relaisspule, allgemein
Operating device, general symbol
07-15-21
Elektromechanischer Antrieb eines
Thermorelais
Actuating device of a thermal relay
Nr. / No. Schaltzeichen / Symbol Beschreibung Description
07-21-01 Sicherung, allgemein Fuse, general symbol
Nr. / No. Schaltzeichen / Symbol Beschreibung Description
08-10-01
Lampe, allgemein
Leuchtmelder, allgemein
RD rot
YE gelb
GN grün
BU blau
WH weiß
Lamp, general symbol
Signal lamp, general symbol
RD = red
YE = yellow
GN = green
BU = blue
WH = white
08-10-02 Leuchtmelder, blinkend Signal lamp, flashing type
Nr. / No. Schaltzeichen / Symbol Beschreibung Description
10-15-01
Verstärker, allgemein
dargestellt mit Ein- und Ausgang
Anmerkung:
Die Spitze des Dreiecks muß in die
Übertragungsrichtung zeigen.
Amplifier, general symbol
Repeater, general symbol
shown with input and output
Note:
The triangle is pointed in the direc-
tion of transmission.
10-15-02
Verstärker, allgemein
dargestellt mit Ein- und Ausgang
Anmerkung:
Die Spitze des Dreiecks muß in die
Übertragungsrichtung zeigen.
Amplifier, general symbol
Repeater, general symbol
shown with input and output
Note:
The triangle is pointed in the direc-
tion of transmission.
SIPLACE HF Series Detailed Circuit Diagrams Folder
09/2005 US Edition
0 - 7
0.2 Structure of the Technical Numbering System
Document number
A document number consists of an item number, product status, document status, document type, language and for-
mat.
Item number
An item number consists of master number and function status
Function status (FS) = versions relevant to function
All documents pertaining to an item number have the same functions status. The versions of a product relevant to func-
tion are determined by the totality of the features describing the function and documented in the corresponding docu-
mentation.
Product status (PS)
The versions of a product not relevant to function are determined by the totality of the remaining features (no features
with relevance to function) and documented in the corresponding documentation.
Document status (DS)
The status of the contents of a technical document.
Document type
Language
Format
A Installation diagram, electrical B Construction specifications, electrical
E
Adjustment specifications, testing and inspection
instructions, setting specifications
F Movement diagram, general functions drawing
G Machine identification plate K Terminal diagram, cable diagram, wires list
L Circuit Diagram M Assembly diagram, installation diagram, mechanical
Document number
Item number
Example 00324139 - 02 01 04 Z D 3
Pattern
NNNNNNNN
-
NN NN NN
AAN
Main number S FS PS DS DT L F
Separator = - for standard part
Separator = S for service part
Function status as per SN 10370, Part 1
Product status as per SN 10370, Part 1
Document status as per SN 10370, Part 1
Document type
Language
Format
N = Numerical counting position
A = Alphabetic counting position
N Master pattern, layout, inscription P Program documentation
R Product description S Parts list
T Parts drawing U Documentation overview
V Construction specifications, mechanical W Hydraulics diagram
X Pneumatics diagram Z Assembly, mechanical
D German E English
F French I Italian
N Dutch S Spanish
X German/English Y German/Italian
0A0 1 A1
2A2 3 A3
4A4
SIPLACE HF Series Detailed Circuit Diagrams Folder
09/2005 US Edition
1 - i
1 Block diagrams
90010130-010401LD3 SIPLACE HF/basic module (Sh. 1 of 6) 1 - 1
90010130-010401LD3 SIPLACE HF/basic module (Sh. 2 of 6) 1 - 2
90010130-010401LD3 SIPLACE HF/basic module (Sh. 3 of 6) 1 - 3
90010130-010401LD3 SIPLACE HF/basic module (Sh. 4 of 6) 1 - 4
90010130-010401LD3 SIPLACE HF/basic module (Sh. 5 of 6) 1 - 5
90010130-010401LD3 SIPLACE HF/basic module (Sh. 6 of 6) 1 - 6
90010133-010501LD3 SIPLACE HF/3 basic module (Sh. 1 of 7) 1 - 7
90010133-010501LD3 SIPLACE HF/3 basic module (Sh. 2 of 7) 1 - 8
90010133-010501LD3 SIPLACE HF/3 basic module (Sh. 3 of 7) 1 - 9
90010133-010501LD3 SIPLACE HF/3 basic module (Sh. 4 of 7) 1 - 10
90010133-010501LD3 SIPLACE HF/3 basic module (Sh. 5 of 7) 1 - 11
90010133-010501LD3 SIPLACE HF/3 basic module (Sh. 6 of 7) 1 - 12
90010133-010501LD3 SIPLACE HF/3 basic module (Sh. 7 of 7) 1 - 13
00119625-010301LD3 Wiring for PCB single conveyor (Sh. 1 of 4) 1 - 14
00119625-010301LD3 Wiring for PCB single conveyor (Sh. 2 of 4) 1 - 15
00119625-010301LD3 Wiring for PCB single conveyor (Sh. 3 of 4) 1 - 16
00119625-010301LD3 Wiring for PCB single conveyor (Sh. 4 of 4) 1 - 17
00119627-010301LD3 Wiring for PCB dual conveyor (Sh. 1 of 6) 1 - 18
00119627-010301LD3 Wiring for PCB dual conveyor (Sh. 2 of 6) 1 - 19
00119627-010301LD3 Wiring for PCB dual conveyor (Sh. 3 of 6) 1 - 20
00119627-010301LD3 Wiring for PCB dual conveyor (Sh. 4 of 6) 1 - 21
00119627-010301LD3 Wiring for PCB dual conveyor (Sh. 5 of 6) 1 - 22
00119627-010301LD3 Wiring for PCB dual conveyor (Sh. 6 of 6) 1 - 23
BEWE_HF-010201FD3 CO trolley docking unit, location 1 (Sh. 1 of 4) 1 - 24
BEWE_HF-010201FD3 CO trolley docking unit, location 2 (Sh. 2 of 4) 1 - 25
BEWE_HF-010201FD3 CO trolley docking unit, location 3 (Sh. 3 of 4) 1 - 26
BEWE_HF-010201FD3 CO trolley docking unit, location 4 (Sh. 4 of 4) 1 - 27
03021017-040101FD3 Cable harness, CO trolley dock. unit 1 - 28
03021249-010201FD3 Cable harness, CO trolley 1 - 29
03020668-010302LD4 1-wire-HUB 1 - 30
03041473-010101LD3 1-wire hub CAT5 1 - 31
MTC2_NH Block diagram, EMERGENCY STOP 1 - 32
MTC2_ODU ODU connector, MTC2 - SIPLACE 1 - 33
