Table of Contents
Introduction ................................................................................................01
1. What are Keysight Technologies accessories? ..............................01
2. Types of accessories ..................................................................... 01
3. The Benefits of Keysight accessories ............................................02
4. ISO 9000 quality management ...................................................... 02
Tips for Selecting Appropriate Accessories ..........................................03
1. Selection by measurement application .........................................03
2. Compatibility with measurement instruments .............................. 03
3. Frequency, DC bias, and operating temperature/humidity ..........04
4. DUT (device under test) dimensions ..............................................04
5. Open & short repeatability and proportional error ....................... 04
6. Furnished accessories ....................................................................04
7. Terminal adapters ...........................................................................05
Accessories Catalog .................................................................................06
Applicable frequency ranges .............................................................06
Accessories organization ................................................................... 07
Up to 120 MHz (4-Terminal Pair) ............................................................08
Lead Components ............................................................................09
16047A Test fixture .....................................................................09
16047E Test fixture ..................................................................... 10
SMD ........................................................................................... 11
16034E Test fixture ..................................................................... 11
16034G Test fixture .................................................................... 12
16034H Test fixture .................................................................... 13
16334A Tweezers contact test fixture ....................................... 14
Other Components .......................................................................... 15
16089A Large Kelvin clip leads .................................................. 15
16089B Medium Kelvin clip leads .............................................. 15
16089C Kelvin IC clip leads ........................................................ 16
Port/Cable Extension ...................................................................... 17
16048A Test leads ...................................................................... 17
16048D Test leads ...................................................................... 17
16048E Test leads ....................................................................... 18
16048G Test leads ...................................................................... 19
16048H Test leads ...................................................................... 19
Probes ................................................................................................ 20
42941A Impedance probe kit .....................................................20
DC Bias Accessories ........................................................................21
16065A 200 Vdc external voltage bias fixture .......................... 21
16065C 40 Vdc external voltage bias adapter .......................... 21
Material .............................................................................................. 22
16451B Dielectric test fixture .....................................................22
16452A Liquid dielectric test fixture ..........................................26
i | Keysight | Accessories Catalog for Impedance Measurements - Catalog
Up to 3 GHz (7 mm) ..................................................................................28
Lead Components ............................................................................29
16092A Spring clip fixture ..........................................................29
SMD ....................................................................................................30
16192A Parallel electrode SMD test fixture ..............................30
16194A High temperature component test fixture ...................32
16196A Parallel electrode SMD test fixture ..............................34
16196B Parallel electrode SMD test fixture .............................. 37
16196C Parallel electrode SMD test fixture ..............................39
16196D Parallel electrode SMD test fixture .............................. 41
16197A Bottom electrode SMD test fixture ...............................43
16198A Bottom electrode SMD test fixture ..............................46
DC Bias Accessories ........................................................................ 48
16200B external DC bias adapter .............................................. 48
Material .............................................................................................. 49
16453A Delectric material test fixture .......................................49
16454A magnetic material test fixture ......................................50
Other Accessories ..................................................................................... 52
16190B Performance test kit ............................................................. 52
16380A Standard capacitor set .........................................................53
16380C Standard capacitor set .........................................................54
42030A Four-Terminal pair standard resistor set .............................55
42090A Open termination ..................................................................56
42091A Short termination ..................................................................56
Index ............................................................................................................ 57
Keysight Web Resources .........................................................................60
Table of Contents continued
ii | Keysight | Accessories Catalog for Impedance Measurements - Catalog
When a device under test (DUT) is measured, a test fixture must be used to connect the instrument to the DUT.
A test fixture is an interface specifically designed to connect the instrument and the contact tips of the DUT.
1. What are Keysight Technologies accessories?
Keysight Technologies offers a variety of accessories suitable for many applications. They are designed to
make measurements simple and reliable. For example, a mechanically and electrically precise test fixture is
required to measure the impedance of SMD components. For this measurement, Keysight offers dedicated
SMD fixtures for impedance measurement instruments that minimize the measurement errors. Also,
specially designed fixtures for other specific applications (such as DC bias test, dielectric material test, and
others.) are available. Keysight accessories facilitate a shorter time-to-market with increased confidence by
providing accurate and repeatable measurements.
2. Types of accessories
Keysight accessories can be divided into the following five categories:
Test fixtures
A test fixture is used to hold the electronic components or materials (physically and electrically) for the
measurements. Keysight offers various kinds of 4-Terminal Pair test fixtures and 7 mm test fixtures. Some of
them connect directly to the measurement instrument, while others require adapters.
Test leads
Test leads are used to extend the measurement ports from the UNKNOWN terminals of the instrument to
the DUT. Using a flexible test lead, a DUT that cannot be held with test fixtures can be measured regardless
of its size or shape. The test leads can also be used as cable extensions when the test sample is located
away from the measurement instrument.
Probes
Probes are helpful in measuring components which are already connected to PC boards or have one
terminal grounded.
Adapters
Adapters are used to adapt the dedicated circuits between the instrument and the test fixtures. The 42942A
is a terminal conversion adapter that can convert a 4-Terminal Pair configuration to a 7 mm configuration.
The 16065C is an external DC bias adapter that can apply DC bias to the DUT from an external DC bias
source.
Others
Also available are DC bias accessories and performance test equipment.
Introduction
