42030A Four-Terminal pair
standard resistor set
Terminal connector: 4-Terminal pair, BNC
Dimensions (approx.):
94 (W) x 31 (H) x 67 (D) [mm] (resistors)
Weight (approx.): 3.7 kg (including case
and 9 resistors)
Other Accessories continued
Description: The 42030A is a standard resistor set consisting of nine precision resistor
standards which range from 1 mΩ to 100 kΩ. These resistors are primarily used for
performance tests of Keysight’s 4-Terminal Pair LCR meters and impedance analyzers.
Refer to the instrument’s operation/service manual for the method of using these
standards.
Applicable instrument: E4980A/AL, E4981A, E4990A
Furnished accessories:
Description P/N Qty.
42031A (1 mΩ) N/A 1
42032A (10 mΩ) N/A 1
42033A (100 mΩ) N/A 1
42034A (1 Ω) N/A 1
42035A (10 Ω) N/A 1
42036A (100 Ω) N/A 1
42037A (1 kΩ) N/A 1
42038A (10 kΩ) N/A 1
42039A (100 kΩ) N/A 1
Calibration report N/A 1
Carrying case 42030-60100 1
Operating and service manual 42030-90001 1
Model DC resistance
42031A 1 mΩ ± 0.2%
42032A 10 mΩ ± 0.2%
42033A 100 mΩ ± 0.2%
42034A 1 Ω ± 0.2%
42035A 10 Ω ± 0.1%
42036A 100 Ω ± 0.1%
42037A 1 kΩ ± 0.1%
42038A 10 kΩ ± 0.1%
42039A 100 kΩ ± 0.1%
55 | Keysight | Accessories Catalog for Impedance Measurements - Catalog
42090A Open termination
Terminal connector: 4-Terminal Pair, BNC
Dimensions (approx.):
94(W) x 31(H) x 67(D) [mm]
Weight (approx.): 120 g
Other Accessories continued
Description: The 42090A is an open termination and is primarily used for performance
tests of Keysight’s 4-Terminal Pair LCR meters and impedance analyzers. Refer to the
instrument’s operation/service manual for the method of using this standard.
Applicable instrument: E4980A/AL, E4981A, E4990A
42091A Short termination
Terminal connector: 4-Terminal Pair, BNC
Dimensions (approx.):
94(W) x 31(H) x 67(D) [mm]
Weight (approx.): 120 g
Description: The 42091A is a short termination and is primarily used for performance
tests of Keysight’s 4-Terminal Pair LCR meters and impedance analyzers. Refer to the
instrument’s operation/service manual for the method of using this standard.
Applicable Instrument: E4980A/AL, E4981A, E4990A
56 | Keysight | Accessories Catalog for Impedance Measurements - Catalog
Index
Model number Name Applicable measurement instrument (s) Page (s)
16034E SMD/Chip test fixture
E4980A/AL, E4981A, E4990A, E5061B-3L3/3L4/3L5 (w/Opt. 005)
11
16034G SMD/Chip test fixture, small refer to 16034E 12
16034H SMD/Chip test fixture, general refer to 16034E 13
16047A Axial and radial test fixture
E4980A/AL, E4981A, E4990A
9
16047E Axial and radial test fixture, 120 MHz refer to 16034E 10
16048A One meter test leads, BNC E4980A/AL, E4981A 17
16048D Two meter test leads, BNC E4980A/AL, E4981A 17
16048E Four meter test leads, BNC E4980A/AL 18
16048G One meter test leads, BNC, 120 MHz E4990A 19
16048H Two meter test leads, BNC, 120 MHz E4990A 19
16065A Ext. Voltage bias with safety cover
(≤ 200 vdc)
E4980A/AL, E4981A, E4990A 21
16065C External bias adapter (≤ 40 vdc) E4981A, E4980AL 21
16089A /B/C Kelvin clip leads E4980A/AL, E4981A, E4990A 15–16
16092A RF spring clip : axial, radial and SMD E4982A, E4990A + 42942A*, E4991B, E5061B-3L3/3L4/3L5 (w/Opt. 005)) +
16201A
29
16190B Performance test kit E4982A, E4990A-120*, E4991B 52
16192A Parallel electrode SMD test fixture
E4982A, E4990A + 42942A*, E4991B, E5061B-3L3/3L4/3L5 (w/Opt. 005) +
16201A
30–31
16194A High temperature component test fixture refer to 16192A 32–33
16196A/B/C/D Parallel electrode SMD test fixture refer to 16192A 34–42
16197A Bottom electrode SMD test fixture refer to 16192A 43–45
16198A Bottom electrode SMD test fixture E4982A, E4991B, E5061B-3L3/3L4/3L5 (w/Opt. 005) + 16201A 46–47
16200B External DC bias adapter E4982A, E4990A + 42942A*, E4991B, E5061B-3L3/3L4/3L5 (w/Opt. 005) +
16201A
48
16334A SMD/chip tweezers E4980A/AL, E4981A, E4990A 14
16380A C Standards set E4980A/AL, E4981A, E4990A 53
16380C C Standards set E4980A/AL, E4981A, E4990A 54
16451B Dielectric material test fixture E4980A/AL, E4981A, E4990A 22–25
16452A Liquid test fixture E4980A/AL, E4990A 26–27
16453A Dielectric material test fixture E4991B (w/Option 002) 49
16454A Magnetic material test fixture E4990A + 42942A*, E4991B (w/Option 002) 50–51
42030A Four-Terminal pair standard resistor set E4980A/AL, E4981A, E4990A 55
42090A Open termination E4980A/AL, E4981A, E4990A 56
42091A Short termination E4980A/AL, E4981A, E4990A 56
42941A Impedance probe kit E4990A* 20
42942A Four-Terminal pair to 7 mm E4990A* 5
* Option E4990A-120 is required
57 | Keysight | Accessories Catalog for Impedance Measurements - Catalog
