Index continued
Test fixture selection by SMD size
* Applicable SMD size [code in mm / (EIA code in inch)]*
5
Classi-
fication
Test fixture
type
Model
number
Electrode
type
Maximum
usable
frequency
Minimum
L x W x H
(mm)
Maximum
L x W x H
(mm)
LF,
4TP*
1
SMD, General 16034E Parallel 40 GHz • • • • • • • 0.1 x 0.5 x 0.5 8 x 10 x 10
SMD, General 16034G Parallel 120 MHz • • • • • 0.1 x 0.3 x 0.3 5 x 1.6 x 1.6
SMD, General 16034H Parallel 120 MHz • • • • • • 0.1 x 0.6 x 0.6 5 x 15 x 3
SMD,
Tweezers*
3
16334A Parallel 15 MHz • • • • • • • See Note 7 L < 10
RF,
7 mm*
2
SMD/Lead*
4
16092A Parallel 500 MHz • • • • • • • See Note 6 L < 18
SMD, General 16192A Parallel 2 GHz • • • • • • • • L > 1 L < 20
SMD/Lead*
4
16194A Bottom 2 GHz • • • • • • L > 2 L < 15
SMD, Coaxial 16196A Parallel 3 GHz • 1608 size only
SMD, Coaxial 16196B Parallel 3 GHz • 1005 size only
SMD, Coaxial 16196C Parallel 3 GHz • 0603 size only
SMD, Coaxial 19196D Parallel 3 GHz • 0402 size only
SMD, General 16197A Bottom 3 GHz • • • • • 1005 to 3225 sizes only
SMD, General 16197A-001 Bottom 3 GHz • • • • • • 0603 to 3225 sizes only
SMD, General 16198A Bottom 3 GHz • • 0201 to 0402 sizes only
Notes:
1. LF, 4TP denotes test fixtures for use with four-terminal pair type LCR meters and LF impedance analyzers in low freuqncy region (< 120 MHz).
2. RF, 7 mm denotes test fixtures for use with RF impedance measureemnt instruments which have 7 mm coaxial test port.
3. Tweezers type test fixture with 1 meter test leads.
4. Test fixture for measuring SMD and leaded components.
5. Check marks in the table denote the application DUT sizes.
6. Applicable to SMD components with thickness > 0.65 mm. Not suitable for smaller SMD than 1608 type.
7. Minimum SMD size is not specified. Not recommended for smaller than 1608 type because contact repeatability degrades with the reduction of
device size.
0201 / (008005)
0402 / (01005)
0603 / (0201)
1005 / (0402)
1608 / (0603)
2012 / (0805)
3216 / (1206)
3225 / (1210)
4520 / (1808)
4532 / (1812)
5750 / (2220)
58 | Keysight | Accessories Catalog for Impedance Measurements - Catalog
Index continued
Accessories vs. instruments matrix
Simplify and improve your measurements with Keysight’s test accessories
Selecting a test fixture is as important as selecting the right instrument. Keysight
offers a wide range of accessories for axial, radial, and SMD/Chip devices. In addition,
a variety of test leads are available to simplify remote testing and systems applications.
External test fixtures with safety covers are also available.
You will improve your measurement results with the proper test fixture.
– More reliable and repeatable measurement
– Higher through-put
– Fewer handling errors
– Tighter test limits
– Better measurement accuracy
Note: Refer to the accessory descriptions for frequency and operational limits.
1. 3.5-mm (M) to 7-mm adapter is required
2. 42942A is required.
3. Compatible when used in conjunction with 16201A.
4. E4991B-002 is required
5. E4980AL only
For additional product information and literature, visit our Accessories
Web site: www.keysight.com/find/impedance-accessory
E4980A/AL
E4981A
E4982A
E4990A Option 120
E4990A Option 010/020/030/050
E4991B
E5061B Option 3L3/3L4/3L5 w/005
Table 3. Test accessories/fixtures
16034E SMD/chip test fixture DC-40 MHz • • • • •
16034G SMD/chip test fixture, small DC-120 MHz • • • • •
16034H SMD/chip test fixture, for Array-type DC-120 MHz • • • • •
16047A Axial and radial test fixture DC-13 MHz • • • •
16047E Axial and radial test fixture DC-120 MHz • • • • •
16048A One meter test leads, BNC DC-30 MHz • •
16048D Two meter test leads, BNC DC-30 MHz • •
16048E Four meter test leads, BNC DC-2 MHz •
16048G One meter test leads, BNC DC-120 MHz • •
16048H Two meter test leads, BNC DC-120 MHz • •
16065A Ext. voltage bias with safety cover (≤ 200 Vdc) 50 Hz-2 MHz • • • •
16065C External bias adapter (≤ 40 Vdc) 100 Hz-1 MHz •
5
•
16089A/B/C Kelvin clip leads 5 Hz-100 kHz • • • •
16092A RF spring clip: axial, radial and SMD DC-500 MHz •
1
•
2
• •
3
16192A Parallel electrode SMD test fixture DC-2 GHz •
1
•
2
• •
3
16194A High temperature component test fixture DC-2 GHz •
1
•
2
• •
3
16196A/B/C/D Parallel electrode SMD test fixture DC-3 GHz •
1
•
2
• •
3
16197A Bottom electrode SMD test fixture DC-3 GHz •
1
•
2
• •
3
16198A Bottom electrode SMD test fixture DC-3 GHz •
1
•
•
3
16200B External DC bias adapter 1 MHz-1 GHz •
1
•
2
• •
3
16201A N-type to 7 mm terminal adapter 5 Hz to 3 GHz •
16334A SMD/chip tweezers test fixture DC-15 MHz • • • •
16451B Dielectric material test fixture DC-30 MHz • • • •
16452A Liquid test fixture 20 Hz-30 MHz • • •
16453A Dielectric material test fixture 1 MHz-1 GHz •
4
16454A Magnetic material test fixture 1 kHz-1 GHz •
2
•
4
42941A Impedance probe kit DC-120 MHz •
42942A Four-terminal pair to 7-mm adapter DC-120 MHz •
