Table of Contents 4 www.asm-smt.com Removing the Tape (Teardown if Foil Torn) .. 21 Display of Error and Warning States .. 22 Display of Error and Warning States .. 23 Splicing .. 25 Required Tools and Materials …
Table of Contents
3
www.asm-smt.com
Table Of Contents
Operating the Feeder Module.. 5
Important Note for ASM Setup Center.. 5
Front side.. 6
Rear side.. 7
Operator panel.. 8
Overview of the Menus.. 9
Feeder Setup and Log On.. 10
Feeder Log Off and Removal.. 11
Preparing the Tape Material.. 12
Inserting the Tape.. 13
Inserting the Tape.. 14
Setting the Pickup Position.. 15
Setting the Pitch.. 16
Setting the Transport Speed.. 17
Triggering a Scan Request.. 18
Emptying the Foil Container.. 19
Removing the Tape (Teardown).. 20
Table of Contents
4
www.asm-smt.com
Removing the Tape (Teardown if Foil Torn).. 21
Display of Error and Warning States.. 22
Display of Error and Warning States.. 23
Splicing.. 25
Required Tools and Materials.. 25
Preparing the Old End Tape.. 27
Preparing the New Tape.. 28
Splicing Narrow Tapes.. 29
Splicing a Wide Tape.. 31
Splicing with the Multi-frame Tape Splice Gripper.. 32
Checking the Splicing Point.. 35
Operating the Feeder Module - Important Note for ASM Setup Center
5
www.asm-smt.com
1 Operating the Feeder Module1.1 Important Note for ASM Setup Center
This document describes the most frequent procedures used to operate your 24-100mm X SmartFeeder.
NOTICE
ASM Setup Center
If you are also using ASM Setup Center, the procedures you follow may differ from those described in this docu-
ment.
For this reason, make sure you read and follow the detailed instructions in the ASM Setup Center User Guide.
The following procedures are affected by these differences:
– Feeder module setup and tear down.
– Feeder module setup verification.
– Feeder module refill.
