Measurement Application Software

Description

For E5080B ENA

For E5081A ENA-X

Additional Information

Automatic fixture removal

S96007B

Time domain analysis

S96010B

Probe and fixture leakage

calibration

S96008B

Enhanced time domain

analysis with TDR

S96011B

Includes all capabilities of

S96010B.

Real-time S-parameter and

power measurement

uncertainty

S96015B

Displays the measurement

uncertainty dynamically (real-time)

on the measurement trace.

Basic pulsed-RF

measurements lite for

E5080B

S96024B

N/A

Requires E5080B option 021/022.

Subset of S96025B.

Basic pulsed-RF

measurements for E5080B

S96025B

N/A

Requires E5080B option 021/022.

Basic pulsed-RF

measurements lite for

E5081A up to 20 GHz

N/A

S960240B

Subset of S960250B.

Basic pulsed-RF

measurements lite for

E5081A up to 44 GHz

N/A

S960241B

Subset of S960251B.

Basic pulsed-RF

measurements for E5081A

up to 20 GHz

N/A

S960250B

Basic pulsed-RF

measurements for E5081A

up to 44 GHz

N/A

S960251B

Add mechanical noise

tuner control for noise

figure/parameter

measurements

N/A

S96027B

Provides ability to control Maury

Microwave's LXI or Focus

Microwaves’ CCMT impedance

tuners.

Requires E5081A option

0K1/0K2/0N1/0N2 and application

software S96029B.

Noise figure measurements

with vector correction

S96029B

Standard receivers are used on

E5080B. Option 0K1/0K2/0N1/0N2

are required to enable high gain

setting on E5081A.

IQ data bandwidth up to

1.5 GHz

N/A

S96050B

Requires either S960704/707B or

S960904/907B for E5081A.

E5080B is not supported.

IQ data bandwidth up to 4

GHz

N/A

S96051B

Requires either S960704/707B or

S960904/907B for E5081A.

E5080B is not supported.

Impedance analysis

S96041B

N/A

Provides impedance analysis of

small-sized Surface Mount Devices

(SMD) up to 10 GHz. Requires

16198A option 010 test fixture

and

85052DH02 mechanical cal kit.

Description

For E5080B ENA

For E5081A ENA-X

Additional Information

Modulation distortion up to

20 GHz

N/A

S960704B

Requires a supported vector signal

generator. Requires S96083B for

frequency converter

measurements.

Modulation distortion up to

44 GHz

N/A

S960707B

Requires a supported vector signal

generator. Requires S96083B for

frequency converter

measurements.

Scalar mixer/converter

measurements

S96082B

Provides SMC measurement class.

Vector and scalar

mixer/converter

measurements

S96083B

Provides SMC + phase

measurement class and vector

mixer characterization.

Embedded-LO capability

S96084B

Gain-compression

measurements

S96086B

Intermodulation distortion

measurements

2, 4

S96087B

4-port VNA with the internal second

source (E5080B-4x2 or E5081A-

4xx) is recommended.

Source phase control

S96088B

Requires the internal second

source (E5080B-4x2 or E5081A-

4xx).

Differential and I/Q device

measurements

S96089B

Spectrum analysis for

E5080B

S96090B

N/A

Requires E5080B option 09x.

Spectrum analysis for

E5081A up to 20 GHz

N/A

S960904B

Spectrum analysis for

E5081A up to 44 GHz

N/A

S960907B

Active hot parameters,

restricted to 50 GHz

S96111B

Requires the internal second

source (E5080B-4x2 or E5081A-

4xx).

True-mode stimulus

S96460B

Requires the internal second source

(E5080B-4x2 or E5081A-4xx).

Multiport calibration

assistant

S96552B

Provides a tool to flexibly define cal

sets of multiport measurements.

Requires one ECal module.

Vector network analyzer

(VNA) simulator – Standard

S94050B

Runs on your PC and simulates

standard S-parameter

measurement class of Keysight’s

VNAs.

Vector network analyzer

(VNA) simulator -

Advanced

S94051B

Runs on your PC and simulates

VNA functions including advanced

features of S96xxxB software

Device measurement

expert (DMX)

S94601B

Assists the users in setting up

measurements automatically with

customizable templates.

Limit assistant

S94602B

Allows to acquire the data from the

VNA, and easily generate limit

masks for production tests.

Description

For E5080B ENA

For E5081A ENA-X

Additional Information

Automated measurement

expert (AMX)

S94701A, S94702A,

KS8400A

S94701A, S94702A,

KS8400A

A smart software solution for

automated multiport S-parameter

measurements with the VNA and

E5092A

. Order each software model

and install in a PC or the analyzer.

DisplayPort DP cable

compliance test software

S94DPPCB

7,8

S94DPPCB

Performs automated compliance

tests of DisplayPort cable

assemblies using 4-port VNA.

USB Type-C interconnects

compliance test software

S94USBCB

7,8

N/A

Performs automated compliance

tests of USB Type-C interconnects

(e.g., cable assemblies,

connectors, or raw cables) using 4-

port E5080B.

Automotive cable test

software

AE6910L, AE2010L

N/A

Automotive Ethernet and SerDes

cable, connector, and harness

conformance. Automated VNA

setup and compliance

measurements with pass/fail

reporting using 4-port E5080B.

1. The S96xxxB software has six license types, please refer to “Keysight Software Licensing Options Provide Flexibility and

Support” for more detail.

2. Provides Frequency Offset Mode (FOM) to independently set the frequency of internal source(s) and receivers, and to configure

external sources using External Device Configuration.

3. The 16198A option 010 is connected with the E5080B’s options up to 20 GHz with either Type-N or 3.5-mm connectors. It offers

optional fixtures to mount 0402 mm (0402 mm / 01005 inch) and 0201 (0201 mm / 008005 inch) devices with option 200 and

100 respectively.

4. The most common method to use S96087B is to use a 4-port VNA with the internal dual source, with each built-in source

generating one tone. An external combiner (for example, hybrid power dividers 87302C, 87303C, or 87304C) is required to

combine the tones.

5. Features of S96007B and S96552B are not supported with the S94051B.

6. A 4-port ECal module (e.g., N4431D or N4433D) is recommended for multiport measurements.

7. Requires S96011B, KS8400B PathWave Test Automation, and KS8104B HTML5 Result Listener Plugin.

8. Supports L8990M-0LZ 20-port switch matrix to configure a multiport test system which eliminates the need for reconnections of

test cables with DUT.

9. E5081A ENA-X is not recommended for USB Type-C low-speed signal test which requires measurements from 300 kHz.

Automatic Fixture Removal (S96007B)

Many devices do not have coaxial connectors and are put in fixtures in order to measure them in a

coaxial environment. Accurately removing the effects of the fixture is required to get a good measurement

of the Device Under Test (DUT). This application adds a powerful application wizard to guide you through

characterizing a fixture and removing it from the measurement. Devices can be single-ended or

differential. Files can be saved in a variety of formats for later use in ENA, PNA, PXI VNA, Streamline

Series VNA, ADS, and PLTS.

Probe and Fixture Leakage Calibration (S95008B)

The software provides a process designed to address and correct crosstalk and leakage errors within the

measurement system. As measurement systems operate at high frequencies, the potential for crosstalk

increases, impacting the accuracy of measurements. With on-wafer measurement setups, probes and

components are placed very close to each other, resulting in crosstalk through physical coupling.
