50
85052D economy: DC to 26.5 GHz. Includes:
•
00902-60003 3.5 mm (m) fixed load
•
00902-60004 3.5 mm (f) fixed load
•
85052-60006 3.5 mm (m) short
•
85052-60007 3.5 mm (f) short
•
85052-60008 3.5 mm (m) open
•
85052-60009 3.5 mm (f) open
•
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
•
85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
•
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
85052DH02 economy with data-based calibration standards: DC to 26.5 GHz. Includes:
•
5972-3342 USB flash drive
•
00902-60003 3.5 mm (m) fixed load
•
00902-60004 3.5 mm (f) fixed load
•
85052-60006 3.5 mm (m) short
•
85052-60007 3.5 mm (f) short
•
85052-60008 3.5 mm (m) open
•
85052-60009 3.5 mm (f) open
•
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
•
85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
•
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Electronic calibration kits
85093D RF ECal, DC or 300 kHz to 9 GHz, 2-ports. Includes:
•
Option 003: 300 kHz to 9 GHz
•
Option 0DC: DC to 9 GHz
•
Option 00A: Add 3.5 mm adapters
•
Option 00F: Both 3.5 mm connectors are female on module
•
Option 00M: Both 3.5 mm connectors are male on module
•
Option M0F: One female and one male connector, both 3.5 mm
51
85093D-xxx mixed-connector options
Port A Option
Port B Option
Connector Type
Female
Male
Connector Type
Female
Male
3.5 mm
101
102
Type-N
203
204
7-16
205
206
4.3-10
207
208
N4431D Microwave ECal: DC to 13.5 GHz, 4 ports. Includes:
•
Option 0DC: DC to 13.5 GHz (mandatory)
•
Option 010: 3.5 mm female connector on four ports on module
•
Option 020: Type-N female connector on four ports on module
N4431D-xxx mixed-connector options
Connector Type
Port A Option
Port B Option
Port C Option
Port D Option
Four 3.5 mm (f)
010
Four Type-N 50 Ω (f)
020
3.5 mm (f)
101
201
301
401
3.5 mm (m)
102
202
302
402
Type-N 50 Ω (f)
103
203
303
403
Type-N 50 Ω (m)
104
204
304
404
7-16 (f)
1
105
205
305
405
7-16 (m)
1
106
206
306
406
4.3-10 (f)
2
107
207
307
407
4.3-10 (m)
2
108
208
308
408
1. Limits ECal module high frequency to 7.5 GHz.
2. Limits ECal module high frequency to 7.5 GHz.
N4433D Microwave ECal: DC or 300 kHz to 26.5 GHz, 4 ports. Includes:
•
Option 0DC: DC to 26.5 GHz
•
Option 003: 300 kHz to 26.5 GHz
•
Option 010: 3.5 mm female connector on four ports on module
N4433D-xxx mixed-connector options
Connector Type
Port A Option
Port B Option
Port C Option
Port D Option
Four 3.5 mm (f)
010
3.5 mm (f)
101
201
301
401
3.5 mm (m)
102
202
302
402
52
N4691D Microwave ECal, DC or 300 kHz to 26.5 GHz, 2-ports. Includes:
•
Option F0F: Both 3.5 mm connectors are female
•
Option M0F: One female and one male connector, both 3.5 mm
•
Option M0M: Both 3.5 mm connectors are male
•
Option 0DC: DC to 26.5 GHz
•
Option 003: 300 kHz to 26.5 GHz
•
Option 00A adds:
o
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
o
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
N755xA Economy ECal, 2-ports. Includes:
•
N7550A DC to 4 GHz, 2-ports
•
N7551A DC to 6.5 GHz, 2-ports
•
N7552A DC to 9 GHz, 2-ports
•
N7553A DC to 14 GHz, 2-ports
•
N7554A DC to 18 GHz, 2-ports
•
N7555A DC to 26.5 GHz, 2-ports
•
Option 3FF: Both 3.5 mm connectors are female
•
Option 3MF: One female and one male connector, both 3.5 mm
•
Option 3MM: Both 3.5 mm connectors are male
•
Option 150: Plastic storage box
•
N7550X-151: 3.5 mm or 2.92 mm torque wrench
