CalPod Calibration Refresh Modules (8553xB/4xB)
CalPod calibration refresh modules allow in-situ calibration refreshes to be performed at the push of a
button without removing the DUT or re-connecting calibration standards. CalPods are designed for any
measurement situation where it is desirable to ensure that a valid calibration is present before recording
measurement data. For example, they are useful for removing environmental effects such as cable
movement and thermal-based changes of cables, connectors, and adapters, as well as connector and
switch-matrix repeatability errors. The modules are especially useful in temperature, or thermal-vacuum
chamber testing. CalPod modules are equipped with 2.92 mm connectors.
•
85530B 20 GHz ambient-temperature CalPod
•
85531B 20 GHz temperature-compensated CalPod
•
85532B 20 GHz thermal-vacuum compatible CalPod
•
85540B 40 GHz ambient-temperature CalPod
•
85541B 40 GHz temperature-compensated CalPod
•
85542B 40 GHz thermal-vacuum compatible CalPod
•
85523B CalPod controller (provides control for up to 4 CalPods)
•
85556A CalPod drive-cable splitter (allows control for up to 12 CalPods)
•
85554A CalPod drive cable extension (10-meter cascadable extension cable)
66
E5081A, E5080B and E5071C Comparison
Switching from the E5071C to the E5081A or E5080B simplifies complex measurements with integrated
functionality and applications. You also get reliability and repeatability from best-in-class performance in
dynamic range, trace noise, speed, and frequency range.
Features
E5081A ENA-X
E5080B ENA
E5071C ENA
Frequency range
10 MHz to 20/44 GHz
(option 2x5, 2x6, 2N7, 4x5,
4x6, 4N7)
9 kHz to 4.5/6.5/9/14/18/20
GHz (option 2x0, 4x0, 4x2,
without bias tees)
100 kHz to 26.5/32/44/53
GHz (option 2x0, 4x0, 4x2,
without bias tees)
9 kHz to 4.5/6.5/8.5 GHz
(Option 2x0, 4x0, without
bias tees)
100 kHz to 4.5/6.5/8.5 GHz
(Option 2x5, 4x5, with bias
tees)
300 kHz to 14/20 GHz (with
bias tees)
Test port connectors
3.5 mm (m) (20 GHz)
2.4 mm (m) (44 GHz)
Type-N (f) (4.5/6.5/8.5 GHz)
3.5 mm (m) (14/20 GHz)
Type-N (f) (4.5/6.5/8.5 GHz)
3.5 mm (m) (14/20 GHz)
High stability
timebase
Optional (Option 1E5)
Optional (Option 1E5)
Optional (Option 1E5)
GPIB interface
Optional (Option 172)
Optional (Option 172)
Standard
Analog DC output
(DC sources)
Optional (Option 175)
Optional (Option 175)
No
Internal bias tees
No
Optional (Option 120, 140.
Up to 20 GHz)
Standard (Option 2x5, 4x5.
Up to 20 GHz)
Data storage
Removable SSD (standard)
Removable SSD (standard)
Built-in HDD (standard.
Option 019)
Removable HDD (Option
017)
Pulse modulator
hardware
Optional
Optional (Option 021/022)
No
Spectrum analysis
hardware
Optional
Optional (Option 09x)
No
Internal second
source
Optional (Option 4xx)
Optional (Option 4x2)
No
Configurable test set
Standard
No
No
Low noise receivers
for noise figure
measurements
Optional
No
No
Modulation distortion
analysis (EVM, ACP)
S960704B, S960707B
No
No
Frequency offset
mode / scalar
calibrated mixer
measurements
S96082B
S96082B
Option 008
Time domain analysis
S96010B
S96010B
Option 010
Enhanced time
domain analysis with
TDR
S96011B
S96011B
Option TDR
67
Confidently Covered by Keysight Services
Prevent delays caused by technical questions and reduce system downtime due to instrument
maintenance and repairs with Keysight Services. Keysight Services are here to support your test needs
with expert technical support, instrument repair and calibration, software support, training, alternative
acquisition program options, and more.
A KeysightCare agreement provides dedicated, proactive support through a single point of contact for
instruments, software, and solutions. KeysightCare covers an extensive group of instruments,
application software, and solutions and ensures optimal uptime, faster response, faster access to experts,
and faster resolution.
Keysight Services
Offering
Benefits
KeysightCare
KeysightCare provides elevated support for Keysight instruments and software, with
access to technical support experts that respond within a specified time and ensure
committed repair and calibration turnaround times (TAT). KeysightCare offers
multiple service agreement tiers, including KeysightCare Assured, Enhanced, and
Application Software Support. See the KeysightCare data sheet for details.
KeysightCare Assured
KeysightCare Assured goes beyond basic warranty with repair services that include
committed TAT and unlimited access to technical experts.
KeysightCare Enhanced
KeysightCare Enhanced includes all the benefits of KeysightCare Assured plus
Keysight’s accurate and reliable Calibration Services, accelerated, and committed
TAT, and technical response.
Keysight Support Portal
& Knowledge Center
All KeysightCare tiers include access to the Keysight Support Portal where you can
manage support and service resources related to your assets such as service
requests, and status, or browse the Knowledge Center.
Education Services
Build confidence and gain new skills to make accurate measurements, with flexible
Education Services developed by Keysight experts. Including Start-up Assistance.
Alternative Acquisition Options
KeysightAccess
Reduce budget challenges with a leased-based subscription service, that offers low
monthly payments, enabling you to get the instruments, software, and technical
support you want for your test needs.
