5 Spectrum Analysis Hard ware Options ( E5 080B Only) Choose one of spect rum analysis options for the E50 80B (Option 09x). The fre quency of Option 09x must match with the operat ion frequency of the t est set. S96090B…
4
Option Number
Description
Test Port Connectors
E5080B-4K2
4-port test set, 9 kHz to 20 GHz with second source
3.5 mm (m)
E5080B-4L2
4-port test set, 100 kHz to 26.5 GHz with second source
3.5 mm (m)
E5080B-4M2
4-port test set, 100 kHz to 32 GHz with second source
2.4 mm (m)
E5080B-4N2
4-port test set, 100 kHz to 44 GHz with second source
2.4 mm (m)
E5080B-4P2
4-port test set, 100 kHz to 53 GHz with second source
1
1.85 mm (m)
1. Frequency is settable up to 54 GHz.
E5081A ENA-X
Option Number
Description
Test Port Connectors
2-Port Options
E5081A-2K5
2-port, 10 MHz to 20 GHz
3.5 mm (m)
E5081A-2K6
2-port, 10 MHz to 20 GHz, upconverter for modulation distortion
3.5 mm (m)
E5081A-2N5
2-port, 10 MHz to 44 GHz
2.4 mm (m)
E5081A-2N6
2-port, 10 MHz to 44 GHz, upconverter for modulation distortion
2.4 mm (m)
E5081A-2N7
1
2-port, 10 MHz to 44 GHz, upconverter for modulation distortion, limited
2.4 mm (m)
4-Port Options
E5081A-4K5
4-port, 10 MHz to 20 GHz
3.5 mm (m)
E5081A-4K6
4-port, 10 MHz to 20 GHz, upconverter for modulation distortion
3.5 mm (m)
E5081A-4N5
4-port, 10 MHz to 44 GHz
2.4 mm (m)
E5081A-4N6
4-port, 10 MHz to 44 GHz, upconverter for modulation distortion
2.4 mm (m)
E5081A-4N7
1
4-port, 10 MHz to 44 GHz, upconverter for modulation distortion, limited
2.4 mm (m)
1. Option 2N7/4N7 is a bandwidth limited version of Option 2N6/4N6. See Table 55 of the E5081A Data Sheet for more details.
5
Spectrum Analysis Hardware Options (E5080B Only)
Choose one of spectrum analysis options for the E5080B (Option 09x). The frequency of Option 09x must
match with the operation frequency of the test set. S96090B application software is required for spectrum
analysis using the Option 09x.
Spectrum analysis on E5081A is enabled with S960904B or S960907B software. There is no required
spectrum analysis hardware option on the E5081A.
Option Number
Description
Additional Information
E5080B-090
Spectrum analysis hardware, 9 kHz to 4.5 GHz
E5080B-091
Spectrum analysis hardware, 9 kHz to 6.5 GHz
E5080B-092
Spectrum analysis hardware, 9 kHz to 9 GHz
E5080B-093
Spectrum analysis hardware, 9 kHz to 14 GHz
E5080B-094
1
Spectrum analysis hardware, 9 kHz to 20 GHz
E5080B-095
Spectrum analysis hardware, 100 kHz to 26.5 GHz
E5080B-096
Spectrum analysis hardware, 100 kHz to 32 GHz
E5080B-097
Spectrum analysis hardware, 100 kHz to 44 GHz
E5080B-098
Spectrum analysis hardware, 100 kHz to 53 GHz
1. Order Option 094 for 18 GHz options (opt.2H0/4H0/4H2). The maximum frequency of spectrum analysis is limited at 18 GHz.
Internal Bias Tees Options (E5080B Only)
Broadband internal bias tees are integrated for each test port. Order E5080B Option 120 for 2-port
options and order Option 140 for 4-port options
1
. DC power can be provided via BNC female connectors
on the rear panel of the analyzer for the operation of active components under test such as Tower
Mounted Amplifiers (TMAs). Internal bias tees up to 20 GHz are available on the E5080B.
Internal bias tees options are not available with E5081A ENA-X.
Option Number
Description
Additional Information
E5080B-120
Add internal bias tees for 2-port E5080B
Available with 4.5/6.5/9/14/20 GHz options only
E5080B-140
Add internal bias tees for 4-port E5080B
Available with 4.5/6.5/9/14/20 GHz options only
1. Internal bias tees options cannot be combined with 14 or 18 GHz options with Type-N connectors.
6
Hardware Options
Description
For E5080B ENA
For E5081A ENA-X
Additional Information
Add pulse modulator to
internal 1st source
E5080B-021
1
N/A
Adds the internal pulse modulators to the
E5080B’s first source.
Add pulse modulator to
internal 2nd source
E5080B-022
1
N/A
Adds the internal pulse modulators to the
E5080B’s second source.
Vector signal analysis
hardware
E5080B-190
2
N/A
Adds vector signal analysis capability to the
E5080B’s spectrum analysis hardware
(option 09x). The maximum bandwidth is
29 MHz.
Equipped with Type-N
connectors
E5080B-1NC
N/A
Adds Type-N connectors for 14 and 18 GHz
options (opt.2D0/4D0/4D2/2H0/4H0/4H2).
Cannot be combined with internal bias tees
options (opt.120 or 140).
Add noise receiver to port
1, 50 MHz to 20 GHz
N/A
E5081A-0K1
3
Adds the low-noise receiver to E5081A’s
port 1 to provide wideband noise figure and
noise-power measurements up to 20 GHz.
Add noise receiver to port
2, 50 MHz to 20 GHz
N/A
E5081A-0K2
3
Adds the low-noise receiver to E5081A’s
port 2 to provide wideband noise figure and
noise-power measurements up to 20 GHz.
Add noise receiver to port
1, 50 MHz to 44 GHz
N/A
E5081A-0N1
3
Adds the low-noise receiver to E5081A’s
port 1 to provide wideband noise figure and
noise-power measurements up to 44 GHz.
Add noise receiver to port
2, 50 MHz to 44 GHz
N/A
E5081A-0N2
3
Adds the low-noise receiver to E5081A’s
port 2 to provide wideband noise figure and
noise-power measurements up to 44 GHz.
Add high stability time
base
E5080B-1E5
E5081A-1E5
Improves specification of frequency
accuracy within ± 0.45 ppm.
Add GPIB interface
E5080B-172
E5081A-172
Add analog input and
output
E5080B-175
E5081A-175
Provides two DC sources and four input
ports for DC measurements.
1. S96024B or S96025B application software is required for pulsed-RF measurements.
2. E5080B’s spectrum analysis hardware (opt.09x), S96090B application software and PathWave Vector Signal Analysis (89600
VSA) software are required for vector signal analysis using the E5080B option 190.
3. S96029B application software is needed for all noise figure measurements.
