ENA and ENA-X Configurations
This section describes standard configurations, options, accessories, upgrade kits and compatible
peripherals for the Keysight E5080B ENA and E5081A ENA-X Vector Network Analyzers (VNA). The
instruments are equipped with an Online Help system available within the instrument in English only. All
ENA and ENA-X documentation is available on the product page: www.keysight.com/find/ena.
Test Set Options
Choose one of the frequency and test set options for the analyzer. Option 2xx indicates two test ports and
option 4xx indicates four test ports. To add options to a product, order the corresponding item number
(E5080B- or E5081A-xxx).
E5080B ENA
Option Number
Description
Test Port Connectors
2-Port Options
E5080B-240
2-port test set, 9 kHz to 4.5 GHz
Type-N (f)
E5080B-260
2-port test set, 9 kHz to 6.5 GHz
Type-N (f)
E5080B-290
2-port test set, 9 kHz to 9 GHz
Type-N (f)
E5080B-2D0
2-port test set, 9 kHz to 14 GHz
Type-N (f), 3.5 mm (m)
E5080B-2H0
2-port test set, 9 kHz to 18 GHz
Type-N (f), 3.5 mm (m)
E5080B-2K0
2-port test set, 9 kHz to 20 GHz
3.5 mm (m)
E5080B-2L0
2-port test set, 100 kHz to 26.5 GHz
3.5 mm (m)
E5080B-2M0
2-port test set, 100 kHz to 32 GHz
2.4 mm (m)
E5080B-2N0
2-port test set, 100 kHz to 44 GHz
2.4 mm (m)
E5080B-2P0
2-port test set, 100 kHz to 53 GHz
1
1.85 mm (m)
4-Port Options
E5080B-440
4-port test set, 9 kHz to 4.5 GHz
Type-N (f)
E5080B-460
4-port test set, 9 kHz to 6.5 GHz
Type-N (f)
E5080B-490
4-port test set, 9 kHz to 9 GHz
Type-N (f)
E5080B-4D0
4-port test set, 9 kHz to 14 GHz
Type-N (f), 3.5 mm (m)
E5080B-4H0
4-port test set, 9 kHz to 18 GHz
Type-N (f), 3.5 mm (m)
E5080B-4K0
4-port test set, 9 kHz to 20 GHz
3.5 mm (m)
E5080B-4L0
4-port test set, 100 kHz to 26.5 GHz
3.5 mm (m)
E5080B-4M0
4-port test set, 100 kHz to 32 GHz
2.4 mm (m)
E5080B-4N0
4-port test set, 100 kHz to 44 GHz
2.4 mm (m)
E5080B-4P0
4-port test set, 100 kHz to 53 GHz
1
1.85 mm (m)
4-Port Options with Internal Second Source
E5080B-442
4-port test set, 9 kHz to 4.5 GHz with second source
Type-N (f)
E5080B-462
4-port test set, 9 kHz to 6.5 GHz with second source
Type-N (f)
E5080B-492
4-port test set, 9 kHz to 9 GHz with second source
Type-N (f)
E5080B-4D2
4-port test set, 9 kHz to 14 GHz with second source
Type-N (f), 3.5 mm (m)
E5080B-4H2
4-port test set, 9 kHz to 18 GHz with second source
Type-N (f), 3.5 mm (m)
4
Option Number
Description
Test Port Connectors
E5080B-4K2
4-port test set, 9 kHz to 20 GHz with second source
3.5 mm (m)
E5080B-4L2
4-port test set, 100 kHz to 26.5 GHz with second source
3.5 mm (m)
E5080B-4M2
4-port test set, 100 kHz to 32 GHz with second source
2.4 mm (m)
E5080B-4N2
4-port test set, 100 kHz to 44 GHz with second source
2.4 mm (m)
E5080B-4P2
4-port test set, 100 kHz to 53 GHz with second source
1
1.85 mm (m)
1. Frequency is settable up to 54 GHz.
E5081A ENA-X
Option Number
Description
Test Port Connectors
2-Port Options
E5081A-2K5
2-port, 10 MHz to 20 GHz
3.5 mm (m)
E5081A-2K6
2-port, 10 MHz to 20 GHz, upconverter for modulation distortion
3.5 mm (m)
E5081A-2N5
2-port, 10 MHz to 44 GHz
2.4 mm (m)
E5081A-2N6
2-port, 10 MHz to 44 GHz, upconverter for modulation distortion
2.4 mm (m)
E5081A-2N7
1
2-port, 10 MHz to 44 GHz, upconverter for modulation distortion, limited
2.4 mm (m)
4-Port Options
E5081A-4K5
4-port, 10 MHz to 20 GHz
3.5 mm (m)
E5081A-4K6
4-port, 10 MHz to 20 GHz, upconverter for modulation distortion
3.5 mm (m)
E5081A-4N5
4-port, 10 MHz to 44 GHz
2.4 mm (m)
E5081A-4N6
4-port, 10 MHz to 44 GHz, upconverter for modulation distortion
2.4 mm (m)
E5081A-4N7
1
4-port, 10 MHz to 44 GHz, upconverter for modulation distortion, limited
2.4 mm (m)
1. Option 2N7/4N7 is a bandwidth limited version of Option 2N6/4N6. See Table 55 of the E5081A Data Sheet for more details.
5
Spectrum Analysis Hardware Options (E5080B Only)
Choose one of spectrum analysis options for the E5080B (Option 09x). The frequency of Option 09x must
match with the operation frequency of the test set. S96090B application software is required for spectrum
analysis using the Option 09x.
Spectrum analysis on E5081A is enabled with S960904B or S960907B software. There is no required
spectrum analysis hardware option on the E5081A.
Option Number
Description
Additional Information
E5080B-090
Spectrum analysis hardware, 9 kHz to 4.5 GHz
E5080B-091
Spectrum analysis hardware, 9 kHz to 6.5 GHz
E5080B-092
Spectrum analysis hardware, 9 kHz to 9 GHz
E5080B-093
Spectrum analysis hardware, 9 kHz to 14 GHz
E5080B-094
1
Spectrum analysis hardware, 9 kHz to 20 GHz
E5080B-095
Spectrum analysis hardware, 100 kHz to 26.5 GHz
E5080B-096
Spectrum analysis hardware, 100 kHz to 32 GHz
E5080B-097
Spectrum analysis hardware, 100 kHz to 44 GHz
E5080B-098
Spectrum analysis hardware, 100 kHz to 53 GHz
1. Order Option 094 for 18 GHz options (opt.2H0/4H0/4H2). The maximum frequency of spectrum analysis is limited at 18 GHz.
Internal Bias Tees Options (E5080B Only)
Broadband internal bias tees are integrated for each test port. Order E5080B Option 120 for 2-port
options and order Option 140 for 4-port options
1
. DC power can be provided via BNC female connectors
on the rear panel of the analyzer for the operation of active components under test such as Tower
Mounted Amplifiers (TMAs). Internal bias tees up to 20 GHz are available on the E5080B.
Internal bias tees options are not available with E5081A ENA-X.
Option Number
Description
Additional Information
E5080B-120
Add internal bias tees for 2-port E5080B
Available with 4.5/6.5/9/14/20 GHz options only
E5080B-140
Add internal bias tees for 4-port E5080B
Available with 4.5/6.5/9/14/20 GHz options only
1. Internal bias tees options cannot be combined with 14 or 18 GHz options with Type-N connectors.
