61 For D evices with 4.3 - 10 C on nectors Electronic calibrat ion kits 8509 4 D RF ECal, DC or 300 kHz to 9 GHz , 4.3 - 10 , 2- p orts. Inc ludes: • Option 003: 300 kHz to 9 G Hz • Option 0DC: DC to 9 G Hz • Option 00A:…
60
85050D economy: DC to 18 GHz. Includes:
•
85050-60006 7 mm fixed broadband load
•
85050-80007 7 mm short
•
85050-80010 7 mm open
Electronic calibration kits
85091D RF ECal, DC or 300 kHz to 9 GHz, 7 mm, 2-ports. Includes:
•
Option 003: 300 kHz to 9 GHz
•
Option 0DC: DC to 9 GHz
N4696D Microwave ECal, DC or 300 kHz to 18 GHz, 7 mm, 2-ports. Includes:
•
Option 0DC: DC to 18 GHz
•
Option 003: 300 kHz to 18 GHz
Cables
•
85132E single, flexible: 3.5 mm (f)
1
to 7 mm, 97.2 cm, 38.25 inches
•
85132F set, flexible: two 3.5 mm (f)
1
to 7 mm cables, 62.9 cm each, 24.75 inches each, p/n 85132-
•
60004
•
85135E single, flexible: 2.4 mm (f) to 7 mm, 96 cm, 38 inches
•
85135F set, flexible: two 2.4 mm (f) to 7 mm cables, 53 cm each, 21 inches each, p/n 85135-60002
1. Special rugged female connector specifically for connecting to the network analyzer test port but does not mate with a standard
male connector.
61
For Devices with 4.3-10 Connectors
Electronic calibration kits
85094D RF ECal, DC or 300 kHz to 9 GHz, 4.3-10, 2-ports. Includes:
•
Option 003: 300 kHz to 9 GHz
•
Option 0DC: DC to 9 GHz
•
Option 00A: Add two 4.3-10 adapters (one male-male, one female-female)
•
Option 00F: Both 4.3-10 connectors are female on module
•
Option 00M: Both 4.3-10 connectors are male on module
•
Option M0F: One female and one male connector, both 4.3-10
85094D-xxx mixed-connector options
Port A Option
Port B Option
Connector Type
Female
Connector Type
Female
Connector
Type
Female
4.3-10
107
108
Type-N
203
204
7-16
205
206
3.5 mm
201
202
62
For Devices with 7-16 Connectors
Electronic calibration kits
85098D RF ECal, DC or 300 kHz to 7.5 GHz, 7-16, 2-ports. Includes:
•
Option 003: 300 kHz to 7.5 GHz
•
Option 0DC: DC to 7.5 GHz
•
Option 00A: Add two 7-16 adapters (one male-male, one female-female)
•
Option 00F: Both 7-16 connectors are female on module
•
Option 00M: Both 7-16 connectors are male on module
•
Option M0F: One female and one male connector, both 7-16
85098D-xxx mixed-connector options
Port A Option
Port B Option
Connector Type
Female
Male
Connector Type
Female
Male
7-16
105
106
Type-N
203
204
4.3-10
207
208
3.5 mm
201
202
For Devices with Waveguide
Mechanical calibration kits
X-Band
X11644A standard, WR-90: 8.2 to 12.4 GHz. Includes:
•
00896-60008 X-band standard section
•
00910-60003 X-band termination
•
11644-20018 X-band short
•
11644-20021 X-band shim
•
X281C adapter (included in calibration kit): WR-90 to 7 mm
