3 ENA and ENA -X Configurati ons This section describes standard configu rations, options, ac cessories, upgrade kits and c ompatible peripherals for the K eysight E5080B ENA and E508 1A ENA - X V ector N etwork A naly z…
2
Table of Contents
ENA and ENA-X Configurations ................................................................................................................... 3
E5081A ENA-X with Configurable Test Set ................................................................................................ 10
Block Diagrams ........................................................................................................................................... 12
Measurement Application Software ............................................................................................................ 18
Keysight Software Licensing Options Provide Flexibility and Support ....................................................... 38
Upgrade Your System ................................................................................................................................. 39
E5092A Configurable Multiport Test Set ..................................................................................................... 39
Measurement Accessories .......................................................................................................................... 41
E5081A, E5080B and E5071C Comparison ............................................................................................... 66
Literature Information .................................................................................................................................. 69
Web Resources ........................................................................................................................................... 69
3
ENA and ENA-X Configurations
This section describes standard configurations, options, accessories, upgrade kits and compatible
peripherals for the Keysight E5080B ENA and E5081A ENA-X Vector Network Analyzers (VNA). The
instruments are equipped with an Online Help system available within the instrument in English only. All
ENA and ENA-X documentation is available on the product page: www.keysight.com/find/ena.
Test Set Options
Choose one of the frequency and test set options for the analyzer. Option 2xx indicates two test ports and
option 4xx indicates four test ports. To add options to a product, order the corresponding item number
(E5080B- or E5081A-xxx).
E5080B ENA
Option Number
Description
Test Port Connectors
2-Port Options
E5080B-240
2-port test set, 9 kHz to 4.5 GHz
Type-N (f)
E5080B-260
2-port test set, 9 kHz to 6.5 GHz
Type-N (f)
E5080B-290
2-port test set, 9 kHz to 9 GHz
Type-N (f)
E5080B-2D0
2-port test set, 9 kHz to 14 GHz
Type-N (f), 3.5 mm (m)
E5080B-2H0
2-port test set, 9 kHz to 18 GHz
Type-N (f), 3.5 mm (m)
E5080B-2K0
2-port test set, 9 kHz to 20 GHz
3.5 mm (m)
E5080B-2L0
2-port test set, 100 kHz to 26.5 GHz
3.5 mm (m)
E5080B-2M0
2-port test set, 100 kHz to 32 GHz
2.4 mm (m)
E5080B-2N0
2-port test set, 100 kHz to 44 GHz
2.4 mm (m)
E5080B-2P0
2-port test set, 100 kHz to 53 GHz
1
1.85 mm (m)
4-Port Options
E5080B-440
4-port test set, 9 kHz to 4.5 GHz
Type-N (f)
E5080B-460
4-port test set, 9 kHz to 6.5 GHz
Type-N (f)
E5080B-490
4-port test set, 9 kHz to 9 GHz
Type-N (f)
E5080B-4D0
4-port test set, 9 kHz to 14 GHz
Type-N (f), 3.5 mm (m)
E5080B-4H0
4-port test set, 9 kHz to 18 GHz
Type-N (f), 3.5 mm (m)
E5080B-4K0
4-port test set, 9 kHz to 20 GHz
3.5 mm (m)
E5080B-4L0
4-port test set, 100 kHz to 26.5 GHz
3.5 mm (m)
E5080B-4M0
4-port test set, 100 kHz to 32 GHz
2.4 mm (m)
E5080B-4N0
4-port test set, 100 kHz to 44 GHz
2.4 mm (m)
E5080B-4P0
4-port test set, 100 kHz to 53 GHz
1
1.85 mm (m)
4-Port Options with Internal Second Source
E5080B-442
4-port test set, 9 kHz to 4.5 GHz with second source
Type-N (f)
E5080B-462
4-port test set, 9 kHz to 6.5 GHz with second source
Type-N (f)
E5080B-492
4-port test set, 9 kHz to 9 GHz with second source
Type-N (f)
E5080B-4D2
4-port test set, 9 kHz to 14 GHz with second source
Type-N (f), 3.5 mm (m)
E5080B-4H2
4-port test set, 9 kHz to 18 GHz with second source
Type-N (f), 3.5 mm (m)
4
Option Number
Description
Test Port Connectors
E5080B-4K2
4-port test set, 9 kHz to 20 GHz with second source
3.5 mm (m)
E5080B-4L2
4-port test set, 100 kHz to 26.5 GHz with second source
3.5 mm (m)
E5080B-4M2
4-port test set, 100 kHz to 32 GHz with second source
2.4 mm (m)
E5080B-4N2
4-port test set, 100 kHz to 44 GHz with second source
2.4 mm (m)
E5080B-4P2
4-port test set, 100 kHz to 53 GHz with second source
1
1.85 mm (m)
1. Frequency is settable up to 54 GHz.
E5081A ENA-X
Option Number
Description
Test Port Connectors
2-Port Options
E5081A-2K5
2-port, 10 MHz to 20 GHz
3.5 mm (m)
E5081A-2K6
2-port, 10 MHz to 20 GHz, upconverter for modulation distortion
3.5 mm (m)
E5081A-2N5
2-port, 10 MHz to 44 GHz
2.4 mm (m)
E5081A-2N6
2-port, 10 MHz to 44 GHz, upconverter for modulation distortion
2.4 mm (m)
E5081A-2N7
1
2-port, 10 MHz to 44 GHz, upconverter for modulation distortion, limited
2.4 mm (m)
4-Port Options
E5081A-4K5
4-port, 10 MHz to 20 GHz
3.5 mm (m)
E5081A-4K6
4-port, 10 MHz to 20 GHz, upconverter for modulation distortion
3.5 mm (m)
E5081A-4N5
4-port, 10 MHz to 44 GHz
2.4 mm (m)
E5081A-4N6
4-port, 10 MHz to 44 GHz, upconverter for modulation distortion
2.4 mm (m)
E5081A-4N7
1
4-port, 10 MHz to 44 GHz, upconverter for modulation distortion, limited
2.4 mm (m)
1. Option 2N7/4N7 is a bandwidth limited version of Option 2N6/4N6. See Table 55 of the E5081A Data Sheet for more details.
