37
Automotive cable and interconnect test software
(AE6910L, AE2010L)
Automotive cable, connector, and harness conformance software for Automotive Ethernet and SerDes
standards. Supports cables, connectors, adapters, and harness assemblies for OPEN Alliance and IEEE
Automotive Ethernet, including 10BASE-T1S, 100BASE-T1, and 1000BASE-T1 (UTP and STP), as well
as TC9 channel and component requirements for fully shielded 1000BASE-T1 and 2.5/5/10GBASE-T1 in
accordance with IEEE 802.3cg, 802.3bw, 802.3bp, and 802.3ch (AE6910L). Supports Automotive SerDes
cable and channel validation for MIPI A-PHY, ASA, and OpenGMSL, including cables, connectors,
adapters, and harnesses (AE2010L).
Automatically configures the VNA, executes compliance test sequences, and generates reports including
insertion loss, return loss, crosstalk, and mode conversion measurements with pass/fail results.
Requirements: Requires a 4-port E5080B VNA and ECal. See the data sheet for other supported VNA
models and ECals. Requires AE6800C, KS8400B PathWave Test Automation and S96010B time domain
analysis. Refer to Automotive Ethernet Channel Testing (3121-1480) and Automotive SerDes Channel
Testing (3121-1417) for additional information.
PathWave Vector Signal Analysis (89600 VSA) Software
PathWave Vector Signal Analysis (89600 VSA) software is a comprehensive set of tools for demodulation
and vector signal analysis. Supporting E5080B’s Option 09x/190 or E5081A, the software provides the
flexibility and sophisticated measurement tools essential to find and fix signal problems. The multi-
channel measurement capability can configure, execute and display multiple measurements
simultaneously to characterize numerous signals. Powerful display tools enable comparisons and
correlation of results from different measurements.
VSA IQ data link feature in either S96090B/S960904B/S960907B spectrum analysis software or
S960704B/707B modulation distortion analysis software is required to enable vector signal analysis using
the ENA/ENA-X.
Refer to www.keysight.com/find/89600 to learn more about 89600 VSA software.
38
Keysight Software Licensing Options Provide
Flexibility and Support
Projects ramp up and down, teams grow and shrink, and projects move location. In such a dynamic
environment, you need flexible licensing options that allow you to balance your project’s requirements.
Whether your software will be a staple for years to come or you have a short-term need for a leading-
edge measurement application, Keysight’s licensing puts you in charge.
Choose Your Term. Choose Your Type. Keep Control of
Your Budget.
•
Select a node-locked, transportable, USB portable or floating license type, depending on how much
flexibility you need.
•
Select a subscription or perpetual license term, depending on how long you need to use the
software.
•
Each license is sold with a KeysightCare software support subscription which provides technical
support with ensured response time, proactive software updates and enhancements.
Choose a license term and type that best suits your requirements from the table below.
License term
1
License Term
Options
Perpetual
Perpetual licenses can be used indefinitely.
Subscription
Licenses can be used through the term of the subscription (6, 12, 24, or 36 month)
License type
License Type
Descriptions
Node locked
License can be used on one specified instrument/computer.
Transportable
License can be used on one instrument/computer at a time but may be transferred to another
using Keysight Software Manager (internet connection required).
USB portable
License can be used on one instrument/computer at a time but can be transferred to another
using a certified USB dongle (available for additional purchase, Keysight part number
E8900-D10).
Floating
Networked instruments/computers can access a license from a server one at a time. Multiple
licenses may be purchased for concurrent usage. Three types of floating license are available:
Single Site: 1-mile radius from the server
Single Region
1
: Americas, Europe, Asia
Worldwide (export restriction identified in End User License Agreement (EULA))
1. For S96xxxB software, the fixed-perpetual with a 12/24/36/60-months, support subscription is the only license type that can be
ordered as part of the instrument and installed. The other license types for S96xxxB software must be ordered separately and
installed from the web after the receipt of the instrument.
2. Americas (North, Central, and South America, Canada); Europe (European Continent, Middle Eastern Europe, Africa, India);
Asia (North and South Asia Pacific Countries, China, Taiwan, Japan).
39
KeysightCare Software Support Subscription Provides
Peace of Mind Amid Evolving Technologies
•
Ensure your software is always current with the latest enhancements and measurement standards.
•
Gain additional insight into your measurement problems with live access to our team of technical
experts.
•
Stay on schedule with fast turnaround times and priority escalations when you need support
KeysightCare software support subscription
Subscription
Descriptions
KeysightCare
software support
Perpetual licenses are sold with a 12 (default), 24, 36, or 60-month software support
subscription. Support subscriptions may be renewed for a fee after that.
Software subscription licenses include a software support subscription through the term of the
license.
Upgrade Your System
Upgrade kits are available to add options after initial purchase. To upgrade your VNA, order the
corresponding item number. To add application software on ENA or ENA-X, order the appropriate
standalone model numbers (S96xxxB).
A complete list of E5080B upgrade kits is available on our Web site: www.keysight.com/find/e5080b-
upgrades
A complete list of E5081A upgrade kits is available on our Web site: www.keysight.com/find/e5081a-
upgrades
