User manual SIPLACE D4 6 Station extensions From software version SR.605.xx 07/2008 EN Edition 6.7 Magnetic pin support 239 6.7 Magnetic pin support Item no. 001 19680-xx Magnetic pin support Wide boards tend to deflect …
6 Station extensions User manual SIPLACE D4
6.6 Long board From software version SR.605.xx 07/2008 EN Edition
238
6.6 Long board
Item no. 00119427-xx Long board option, single conveyor
Item no. 00119428-xx Long board option, dual conveyor
a
Item no. 00119631-xx Conveyor width 242/508 mm (Wide board), D1/D2/D3/D4
The following PCB formats can be placed on D4 machines:
6
6
We can supply the Long board option as a retrofit kit for placing PCBs that are over 368 mm long.
If the Long board option is installed, then the following PCB formats can be processed:
6
6
The retrofit kit consists of the following parts:
– Complete mechanism: stopper, sensors, cables and assembly parts
– Optional CD for enabling the function on the SIPLACE Pro computer
– Retrofit instructions
More detailed information can be found in the Long board retrofit instructions, item no. 00193888-
01.
a) When ordering for the dual conveyor, also quote the item number 00119428-xx in addition to the item number
00119427-xx.
Single conveyor (standard width) 50 x 50 mm² to 368 x 460 mm²
Single conveyor, Wide board 50 x 50 mm² to 368 x 508 mm²
Dual conveyor (standard width) 50 x 50 mm² to 368 x 216 mm²
Dual conveyor, Wide board 50 x 50 mm² to 368 x 242 mm²
Dual conveyor in Single conveyor mode 50 x 50 mm² to 368 x 380 mm²
Single conveyor, Long board (standard width) 50 x 110 mm² to 610 x 460 mm²
Single conveyor, Wide board, Long board 50 x 110 mm² to 610 x 508 mm²
Dual conveyor, Long board (standard width) 50 x 120 mm² to 610 x 216 mm²
Dual conveyor, Wide board, Long board 50 x 120 mm² to 610 x 242 mm²
Dual conveyor in Single conveyor mode, Long board (stan-
dard width)
50 x 120 mm² to 610 x 380 mm²
User manual SIPLACE D4 6 Station extensions
From software version SR.605.xx 07/2008 EN Edition 6.7 Magnetic pin support
239
6.7 Magnetic pin support
Item no. 00119680-xx Magnetic pin support
Wide boards tend to deflect during placement such that, under certain circumstances, the compo-
nents can no longer be placed with the desired accuracy. Highly curved PCBs also affect the
placement accuracy. This problem can be easily rectified by fitting magnetic pin supports on the
lifting table.
6
Fig. 6.7 - 1 Magnetic pin support
6 Station extensions User manual SIPLACE D4
6.8 Component sensor for the C&P12 head From software version SR.605.xx 07/2008 EN Edition
240
6.8 Component sensor for the C&P12 head
Item no. 00118021-xx Component sensor for the 12-segment C&P head
6
Fig. 6.8 - 1 12-segment Collect&Place head with component sensor
(1) 12-segment Collect&Place head
(2) Component sensor
